EN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled Hot Rolled Alloy 617 Plate
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 617 / UNS N06617 / 2.4663 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Bars | Grade | 617 / UNS N06617 |
|---|---|---|---|
| Thickness | 0.6 - 20.0mm | Size | 1219*2438 1500*6000mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 |
| Highlight | Hot Rolled Nickel Alloy Plate,4ft*8ft Nickel Alloy Plate,5ft*20ft Nickel Alloy Plate |
||
Product Description
EN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled & Hot Rolled Alloy 617 Plate
Products Description
| Product Name | Alloy 617 Plate UNS N06617 / EN 2.4663 Plate | |
| Technology | Hot rolled , Cold rolled | |
| Grade | Inconel 600, Inconel 601, Inconel 625, Inconel 617, Inconel 690, Inconel 718, Inconel X-750 | |
|
Incoloy A-286, Incoloy 800, Incoloy 800H, Incoloy 800HT
Incoloy 825, Incoloy 901, Incoloy 925, Incoloy 926
|
||
| Monel 400, Monel K-500 | ||
| Hastelloy C22, Hastelloy C-276, Hastelloy B-2, Hastelloy B-3, Hastelloy X | ||
| Specifications | ASTM, UNS, JIS, EN, AFNOR | |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc | |
| Processing Service |
Machining : Turning / Milling / Planing / Drilling / Boring / Grinding / Gear Cutting / CNC Machining
Deformation processing : Bending / Cutting / Rolling / Stamping
|
|
| Delivery time | 10-30 days subject to the clients' requirement and quantity | |
| Package | clients' requirement and Standard export sea-worthy packing | |
| MOQ | 1 ton | |
ALLOY 617 CR SHEETS, INCONEL ALLOY 617 SLATTING SHEETS, NICKEL ALLOY 617 COLD ROLLED PLATES, INCONEL UNS N06617 POLISHED COLD DRAWN PLATES
ALLOY 617 SHEETS, ASTM B168 ALLOY 617 PLATES, ASTM B168 ALLOY 617 CR SHEETS, GRADE 617 INCONEL MILL FINISH PLATES, INOX 2.4663 617 INCONEL ALLOY CR SHEET, INCONEL DIN 2.4663 POLISHED COLD DRAWN PLATE
INCONEL ALLOY 617 SHEETS, PLATES & COILS SPECIFICATION
| Inconel Alloy 617 Sheets & Plates Standard | ASTM B168/ ASME SB168 |
| Trade name | Inconel Alloy 617 Sheets & Plates |
| 617 Alloy Sheets & Plates Dimensions | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Inconel 617 Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 4000mm, 2500mm, 3000mm, 3500mm, etc |
| ASTM B168 617 Inconel Alloy Sheets & Plates Length | 4000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| 617 Inconel Sheets & Plates Thickness | 0.3 mm to 120 mm |
| Inconel 617 Sheets & Plates Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Alloy 617 Sheets & Plates Surface Finishing | Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc. |
| Payment Terms | Paypal, Western Union, T/T (Telegraphic Transfer or Wire Transfer), L/C or Trade Assurance 30% deposit & balance before shipping |
| Free Sample | Yes if we have in stock |
| Value Added Services | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| SB168 Inconel Alloy 617 Sheets & Plates Origin & Mills | Japanese, Indian, USA, Korean, European, Russian, Ukraine (Strictly No China) |
| Inspection and Test Reports | EN 10204 3.1, Mill Test Certificates, Chemical Reports, PMI Test Reports, Mechanical Reports, Third Party Inspection, NABL Approved Lab, Visual Inspection, Destructive Test and Non Destructive Test Reports |
| Marking |
|
| Outside Finish | Finish as per customer Requirements |
| Delivery Condition | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn |
| Packing of Inconel 617 Sheets & Plates | Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests |
| Specials | Sizes and Specifications other than above can be on request |
| Inconel UNS N06617 Sheets & Plates Application & uses |
|
ASTM B168 617 INCONEL ALLOY SHEETS, PLATES & COILS
| Products | Size | |
| ASTM B168 617 Inconel Alloy Perforated Sheet | ASTM B168 617 Inconel Alloy Plates | Sizes 3.0–10.0 mm |
| ASTM B168 617 Inconel Alloy Sheet | ASTM B168 617 Inconel Alloy Chequered Plate | |
| ASTM B168 617 Inconel Alloy Metal Sheet | ASTM B168 617 Inconel Alloy Polished Texture Sheet | |
| ASTM B168 617 Inconel Alloy Cut to Size | ASTM B168 617 Inconel Alloy Circle | |
| ASTM B168 617 Inconel Alloy Discs | ASTM B168 617 Inconel Alloy Blank | |
| ASTM B168 617 Inconel Alloy Shims | ASTM B168 617 Inconel Alloy Polished Plates | |
| ASTM B168 617 Inconel Alloy Coils | ASTM B168 617 Inconel Alloy Foils | |
| ASTM B168 617 Inconel Alloy Hot Rolled Plates | ASTM B168 617 Inconel Alloy Cold Rolled Plates | |
| ASTM B168 617 Inconel Alloy Strips | ASTM B168 617 Inconel Alloy Roof Sheets | |
ASTM B168 617 INCONEL ALLOY SHEETS & PLATES EQUIVALENT GRADES
| STANDARD | WERKSTOFF NR. | UNS |
| Inconel 617 | 2.4663 | N06617 |
GRADE 617 INCONEL ALLOY SHEETS & PLATES CHEMICAL COMPOSITION
| Grade | C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| Inconel 617 | 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
ASME SB168 INCONEL ALLOY 617 SHEETS & PLATES MECHANICAL PROPERTIES
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 617 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
