AISI310S / TP310S Stainless Steel Plate Seamless Welded Pipe Tube EN 1.4845 SS Pipe
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 310S |
| Minimum Order Quantity | 500 kgs |
| Price | 4650-5760 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Pipe | Grade | 310S |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Industrial | Packing | Wooden Box Or PP Bag |
| Highlight | Welded Stainless Steel Pipe,EN 1.4845 Stainless Steel Pipe,Seamless Stainless Steel Pipe |
||
Product Description
AISI310S / TP310S Stainless Steel Plate Seamless & Welded Pipe Tube EN 1.4845 SS Pipe
| Product Name | 310S Stainless Steel Pipe Ss Pipe |
| Fabrication Standard | ASTM A213/269/312/789 |
| Material Grade | TP304 TP316 TP310S SS32750 TP321 TP347L 2507 S32205 254SMo |
| Out Diameter | 1/8" - 24" |
| Wall Thickness | 1.25mm - 80mm |
| Length | <= 18 Mtr |
| Surface | anealling and pickles surface, polishing |
| Package | by piece, in bundles, with external pvc wrapped, wood crated |
| Minimum Order Quantiy | 1 Metric Tons |
| Our Advantage | 1.regular sizes in stock over 2000 tons for immediate delivery |
| 2.small quantity with factory rate | |
| 3.quality certificate as per EN10204 3.1b issued by manufacturer | |
| 4.expert technical and export/import document consultant and support | |
| 5.on-time response by email, skype, website and online messages |
Corrosion Resistance
310 / 310S stainless steel (1.4845) has excellent corrosion resistance at normal temperatures but is primarily designed to perform at high temperatures. In these high-temperature environments, 310 / 310S (1.4845) maintains very good corrosion resistance and also has exceptional resistance to; oxidizing and carburizing atmospheres and other forms of hot corrosion, up to a maximum dry air service temperature of 1100ºC. Other corrosive compounds such as water and sulphur compounds will significantly reduce the maximum service temperature.
Typical Analysis
| 310S | Cr% | Ni% | C% | Si% | Mn% | P% | S% | Mo% | Cu% | Fe% |
| MIN | 24.0 | 19.0 | - | - | - | - | - | - | - | - |
| MAX | 26.0 | 22.0 | 0.08 | 0.75 | 2.0 | 0.045 | 0.03 | 0.75 | 0.5 | Bal |
Mechanical Properties
The properties quoted below are guideline figures only and should not be used for any design purposes
| Temperature ºC | 100 | 500 | 800 | 1000 | 1100 |
| UTS (Nmm²) | 600 | 475 | 215 | 85 | 45 |
| 0.2% (Nmm²) | 265 | 175 | 110 | ||
| Elongation % | 41 | 35 | 30 | 54 | 57 |
Related Specs & Trade Names
1.4845, Grade 310, Alloy 310S, AISI 310S, TYPE 310, UNS S31008, UNS S31000, X8CrNi25-21, EN10095, ASTM A276, 310H, 310 Stainless, T.310, 310S, 310, ss310, 310ss
Design Features – Stainless Steel 310S/310H
- Oxidation resistance up to 1650°F for continuous service and up to 1500°F where cyclic heating is involved.
- General purpose corrosion resistance.
- Non-magnetic except when cold worked.
- May be susceptible to chloride stress corrosion cracking.
- Used where field working is employed.
Typical Applications – Stainless Steel 310S/310H
- Heat exchanger and heat recuperator tubing
- Molten salt applications
- Sulfur-bearing gas atmospheres
