310S / 310H Stainless Steel Pipe, Valves, Fittings, Flanges ASTM DIN EN JIS GB Standard
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 310S |
| Minimum Order Quantity | 500 kgs |
| Price | 4650-5760 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Pipe | Grade | 310S |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Industrial | Packing | Wooden Box Or PP Bag |
| Highlight | 310H Stainless Steel Pipe,ASTM Stainless Steel Pipe |
||
Product Description
310S / 310H Stainless Steel Pipe, Valves, Fittings, Flanges ASTM DIN EN JIS GB Standard
| Product Name | 310S Stainless Steel Pipe Ss Pipe |
| Fabrication Standard | ASTM A213/269/312/789 |
| Material Grade | TP304 TP316 TP310S SS32750 TP321 TP347L 2507 S32205 254SMo |
| Out Diameter | 1/8" - 24" |
| Wall Thickness | 1.25mm - 80mm |
| Length | <= 18 Mtr |
| Surface | anealling and pickles surface, polishing |
| Package | by piece, in bundles, with external pvc wrapped, wood crated |
| Minimum Order Quantiy | 1 Metric Tons |
| Our Advantage | 1.regular sizes in stock over 2000 tons for immediate delivery |
| 2.small quantity with factory rate | |
| 3.quality certificate as per EN10204 3.1b issued by manufacturer | |
| 4.expert technical and export/import document consultant and support | |
| 5.on-time response by email, skype, website and online messages |
310s stainless seamless steel pipe
310S stainless steel is a low carbon austenitic stainless steel. Known for its ability to withstand high temperature applications, Type 310S, which is a lower carbon version of Type 310. 310S Stainless steel Pipes are often used at cryogenic temperatures,with good corrosion resistance to increase high-temperature properties and is also used at temperatures up to 1040 degrees Celsius intermittently. It also offers users an array of benefits including: Good aqueous corrosion resistance,excellent good corrosion resistance to increase high-temperature properties,and toughness down to cryogenic temperatures. Due to its relatively high chromium and nickel content it is superior in most environments to 304 or 309 stainless.
310s stainless seamless steel pipe Specification :
Products: 310s stainless seamless steel pipe
Materials: 310s
Standard: ASTM A554 A511 A814 A249 A312 A213 JIS G3459 JIS 3463
OD:10-600mm
Thickness: 0.3-12mm
Length:1-6m
Surface treatment: 180#,240#,320# hairline, 400#,600# mirror polish
310s stainless seamless steel pipe Application
1.General industries:petroleum,food,chemical,paper,fertilizer,fabric,aviation and nuclear
2.Decoration field:handrail,railing,staircase,weldmesh,screen,door,window,balcony,fence,bench, furniture.
3.Fluid,gas and oil transport
4.Pressure and heat transmission
5.Construction and ornament
6.Boiler heat exchangers.
310s stainless seamless steel pipe Chemical Properties
| Chemical Properties | |||||||||||
| UNS | ASTM | EN | JIS | C% | Mn% | P% | S% | Si% | Cr% | Ni% | Mo% |
| S31008 | 310S | 1.4845 | SUS310S | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤1.50 | 24.0-26.0 | 19.0-22.0 | - |
310s stainless seamless steel pipe Mechanical Properties
| Grade | Tensile Strength ksi (min.) |
Yield Strength 0.2% Offset ksi (min.) |
Elongation - % in 50 mm (min.) |
Hardness (Brinell) MAX |
Hardness (Rockwell B) MAX |
| 310S | 75 | 30 | 40 | 217 | 95 |
310s Stainless Steel Pipe Sizes
| 1/8" IPS(.405" O.D.) | 3 1/2" IPS( 4.000" O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4" IPS(.540" O.D.) | 4" IPS(4.500" O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8" IPS(.675" O.D.) | 5" IPS( 5.563" O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2" IPS(.840" O.D.) | 6" IPS(6.625" O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4" IPS(1.050" O.D.) | 8 ” IPS(8.625" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1" IPS:(1.315′ O.D.) | 10" IPS(10.750" O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4" IPS(1.660" O.D.) | 12" IPS(12.750" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2" IPS(1.900" O.D.) | 14" IPS(14.000" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2" IPS(2.375" O.D.) | 16" IPS(16.000" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2" IPS(2.875" O.D.) | 18" IPS (18.000" O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3" IPS( 3.500" O.D.) | |
| SCH 5, 10, 40, 80, 160, XXH |
SS 310S SEAMLESS PIPE SIZES
| Pipe Type | NB Sizes | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
|---|---|---|---|---|---|---|
| ASTM A312 TP 310S Stainless Steel Seamless Pipe | 1/8″ | |||||
| ASTM A312 TP 310S Stainless Steel Seamless Pipe | 1/4″ | |||||
| ASTM A312 TP 310S Stainless Steel Seamless Pipe | 3/8″ | |||||
| ASTM A312 TP 310S Stainless Steel Seamless Pipe | 1/2″ | |||||
| ASTM A312 TP 310S Stainless Steel Seamless Pipe | 3/4″ | |||||
| ASTM A312 TP 310S Stainless Steel Seamless Pipe | 1″ | |||||
| ASTM A312 TP 310S Stainless Steel Seamless Pipe | 1 1/4″ | |||||
| ASTM A312 TP 310S Stainless Steel Seamless Pipe | 1 1/2″ | |||||
| ASTM A312 TP 310S Stainless Steel Seamless Pipe | 2″ | |||||
| ASTM A312 TP 310S Stainless Steel Seamless Pipe | 2 1/2″ | |||||
| ASTM A312 TP 310S Stainless Steel Seamless Pipe | 3″ | |||||
| ASTM A312 TP 310S Stainless Steel Seamless Pipe | 4″ | |||||
| ASTM A312 TP 310S Stainless Steel Seamless Pipe | 5″ | |||||
| ASTM A312 TP 310S Stainless Steel Seamless Pipe | 6″ |
