Alloy 904L (N08904) Stainless Steel ASTM A312 904L Stainless Steel Seamless Pipes Welded Pipe
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 904L |
| Minimum Order Quantity | 500 kgs |
| Price | 4650-5760 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Pipe | Grade | 904L |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Industrial | Packing | Wooden Box Or PP Bag |
| Highlight | ASTM A312 Stainless Steel Seamless Pipes,Alloy 904L Stainless Steel Seamless Pipes,N08904 Stainless Steel Seamless Pipes |
||
Product Description
Hot Rolled Stainless Steel Pipe TP904L SS Pipe Diameter 6mm 8mm 10mm 12mm 14mm 16mm 18mm
| Technical Data Sheet of Stainless Steel Pipe & Tube | |
| Product Name |
AISI 904L (UNS N08904, DIN 1.4539) Stainless Steel Seamless Pipes & Tubes |
| Equivalent Materials | AISI 904L, UNS N08904, DIN 1.4539, AISI 904L, SUS 890L, NAS 255, 00Cr20Ni25Mo4.5Cu, X1NiCrMoCu25-20-5 |
| Type | Seamless |
| Shape | Square / Rectangular / Round |
| Standard | GB,AISI,ASTM,DIN,EN,JIS ASTM A240/ASME SA-240,ASTM A276,ASTM A182/ASME SA-182,ASTM A312/ASMES A312 ASTM B625/ASME B625,ASTM B673/ASME B673 |
| Available Grades | Stainless steel 301 / 302 / 303 / 304 / 304L / 310S / 316L / 316Ti / 316LN / 317L / 904L / 2205 / 2507 / 321 / 32760 / 253MA / 254SMo / 410 / 420 / 430 / Custom465 / XM-19 / S31803 / S32750 / S32205 / F50 / F60 / F55 / F60 / F61 / F65. Nitronic 30 / Nitronic 32 / Nitronic 33 / Nitronic 40 / Nitronic 50 / Nitronic 60 etc. |
| Monel 400 / Monel K-500 | |
| Inconel 600 / Inconel 601 / Inconel 625 / Inconel 617 / Inconel 690 / Inconel 718 / Inconel X-750 / Inconel 713C / Inconel 713LC | |
| Incoloy A-286 / Incoloy 800 / Incoloy 800H / Incoloy 800HT | |
| Incoloy 825 / Incoloy 901 / Incoloy 925 / Incoloy 926 | |
| Nimonic 75 / Nimonic 80A / Nimonic 90 / Nimonic 105 / Nimonic C263 / L-605 | |
| Hastelloy B / Hastelloy B-2 / Hastelloy B-3 / Hastelloy C / Hastelloy C-276 / Hastelloy C-22 | |
| Hastelloy C-4 / Hastelloy C-2000 / Hastelloy G-35 / Hastelloy X / Hastelloy N | |
| PH stainless steel 15-5PH / 17-4PH / 17-7PH | |
| Out diameter | Seamless Pipe 6MM - 1174MM or customized |
| Thickness | Seamless Pipe 1mm - 80mm or customized |
| Max Length | Seamless Pipe 12000mm or customized |
| Finish | 2B, Pickling, Polished, Brushed, Sandblast, BA, EP |
| Packing | waterproof polybag, wooden box, end cap, wooden crame/pallet |
| Inspection | TUV,SGS,BV,ABS,LR and so on |
| Application | Chemical, Pharmaceutical & Bio-Medical, Petrochemical & Refinery, Environmental, Food Processing, Aviation, Chemical Fertilizer, Sewage Disposal, Desalination, Waste Incineration etc. |
| Processing Service | Machining : Turning / Milling / Planing / Drilling / Boring / Grinding / Gear Cutting / CNC Machining |
| Deformation processing : Bending / Cutting / Rolling / Stamping | |
| Welded | |
| Forged | |
| Delivery Time | 7-40 days |
| Trade Term | FOB CIF CFR CIP DAP DDP EXW |
| Payment | T/T, L/C,D/A,D/P, Western Union,MoneyGram,According to customer requirements payments for offline orders. |
| Transportation | By air, by sea, by train, by truck |
| Sample | Free |
| Warranty | Trade assurance after sales service |
Stainless Steel 904L (UNS N08904) is a super austenitic alloy that offers moderate to high corrosion resistance and ability to sustain in a wide range of process conditions. Stainless Steel 904L is the combination of high chromium 4.5% and nickel 25% content. Addition to these, grade 904L contains traces of molybdenum and copper which offers excellent corrosion resistance. The material shows high molybdenum and low carbon content. Copper present in the alloy dramatically increases resistance to strong reducing acids. Addition of the aluminium allows for the formation of a continuous, homogenous self-repairing subscale.
Equivalent Grades Of SS 904L Pipes And Tubes
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Stainless Steel 904L Pipe And Tubes Chemical Properties
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
|---|---|---|---|---|---|---|---|---|---|
| SS 904L | 0.020 max | 2.00 max | 1.00 max | 0.040 max | 0.030 max | 19.00 – 23.00 | 4.00 – 5.00 max | 23.00 – 28.00 | 1.00 – 2.00 |
Stainless Steel 904L Pipe / Tubes Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35 % |
