Diameter 1/4" - 20" Stainless Steel Pipe Tube TP316L SS Pipes Custom Cutting any Length
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | TP316L |
| Minimum Order Quantity | 500 kgs |
| Price | 4650-5760 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Pipe | Grade | TP316L |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Industrial | Packing | Wooden Box Or PP Bag |
| Highlight | TP316L Stainless Steel Pipe,Custom Cutting Stainless Steel Pipe |
||
Product Description
Diameter 1/4" - 20" Stainless Steel Pipe Tube TP316L SS Pipes Custom Cutting any Length
| Product Name | Stainless Steel Pipe |
| Standard | JIS, AISI, ASTM, GB, DIN |
| Outer Diameter | 6mm-530mm (1/8"-20") or as the customers' requirements |
| Length | 1000-6000mm or as the customers' requirements |
| Grade | TP201, TP304, TP304L, TP310S, TP316, TP316L, TP317L, TP321, TP309S, TP410, TP420, TP430, TP904L |
| Thickness | 1mm-60mm |
| Type | weld |
| Surface | NO.1/NO.4/8K/HL/BA/2B |
| manufacture | Hot Rolled/Cold Rolled |
| Application | Construction field, ships building industry, petroleum & chemical industries, war and electricity industries, food processing and medical industry, boiler heat ex-changer, machinery and hardware fields ,etc. |
| Packing | Weaving bag, non-woven fabric, seaworthy bundle,wooden case if required |
| Delivery time | Within 7 - 10 working days, according to customers' quantity |
| Payment | L/C or T/T |
| MOQ | 1 Ton |
| Quality | High Quality.SGS inspection is accepted if needed |
| Productivity | 1000 Tons/Month |
Specification of Stainless Steel 316/316L Seamless Pipes
- Specifications : ASTM A312 / A213
- Outside Diameter : 6.00 mm OD up to 914.4 mm OD, Sizes up to 24" NB available Ex-stock, OD Size available Ex-stock
- Thickness : 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
- Size : 1/2" NB - 24" NB
- Type : Seamless
- Form: Round Pipes, Square Pipes, Rectangular Pipes.
- Length : Single Random, Double Random & Required Length
- End : Plain End, Beveled End, Treaded
Equivalent Grades of Stainless Steel 316/316L Seamless Pipes
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 316 | S31600 | 316S31 | 58H, 58J | 1.4401 | X5CrNiMo17-12-2 | 2347 | SUS 316 |
| 316L | S31603 | 316S11 | - | 1.4404 | X2CrNiMo17-12-2 | 2348 | SUS 316L |
Chemical Composition of Stainless Steel 316/316L Seamless Pipes
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 316 | min. max. |
- 0.08 |
- 2.0 |
- 0.75 |
- 0.045 |
- 0.03 |
16.0 18.0 |
2.00 3.00 |
10.0 14.0 |
- 0.10 |
| 316L | min. max. |
- 0.03 |
- 2.0 |
- 0.75 |
- 0.045 |
- 0.03 |
16.0 18.0 |
2.00 3.00 |
10.0 14.0 |
- 0.10 |
ASME SA312 SS 316/316L Electro Fusion Seamless Pipe Mechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 316 | 515 | 205 | 40 | 95 | 217 |
| 316L | 485 | 170 | 40 | 95 | 217 |
Other Types of Stainless Steel 316/316L Seamless Pipes
| Stainless Steel 1.4401 Electro Fusion Seamless Pipes | ASTM A358 TP316 Stainless Steel Seamless Pipes |
| Stainless Steel TP 316 Seamless Hollow Pipes | 316/316L Stainless Steel Seamless Pipes Supplier |
| A358 SS S31600 Seamless Pipes Exporter | Stainless Steel S31600 Seamless Pipes Dealer |
| Stainless Steel 316/316L Seamless Pipes Exporter in China | 316/316L Stainless Steel Seamless Pipes Supplier |
| Austenitic Stainless Steel 316/316L Seamless Pipes | 316/316L Stainless Steel Seamless Pipes Stockist |
| Stainless Steel 1.4401 Seamless Pipes | Stainless Steel S31600 Seamless Piping |
| Stainless Steel S31600 Seamless Pipes Dealer | Stainless Steel 1.4401 Seamless Pipe Stockist |
| Stainless Steel SUS 316/316L Polished Seamless Pipes | ASME SA358 TP316 Stainless Steel SeamlessPipes |
| Stainless Steel 1.4401 Seamless Pipes Supplier in China | S31600 Stainless Steel Seamless Pipes Supplier |
