317LMN / S31726 Stainless Steel Sheet Cold Rolled 2B Surface With EN 10204-3.1 Certificated
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 317LMN |
| Minimum Order Quantity | 500 kgs |
| Price | 3300 - 3480 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 317LMN |
|---|---|---|---|
| Standard | ASTM EN JIS GB | Size | 1219*2438mm 1500*3000mm |
| Thickness | 0.5 - 3.0mm | Type | Cold Rolled |
| Service | Cutting, Surface Treatment | Application | Auto Exhaust Pipe |
| Packing | Wooden Pallets | ||
| Highlight | 2B Surface Stainless Steel Sheet,EN 10204-3.1 Stainless Steel Sheet,Cold Rolled Stainless Steel Sheet |
||
Product Description
317LMN / S31726 Stainless Steel Sheet Cold Rolled 2B Surface With EN 10204-3.1 Certificated
Products Specification
|
Product Name
|
317LMN Stainless Steel Sheets
|
|
Material Type
|
Ferrite stainless steel, magnetic; Austenitic stainless steel, Non-magnetic.
|
|
Grade
|
300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347
|
|
200series:201,202,202cu,204
|
|
|
400series:409,409L,410,420,430,431,439,440,441,444
|
|
|
Others:2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc
|
|
|
Duplex stainless steel:S22053,S25073,S22253,S31803,S32205,S32304
|
|
|
Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo
|
|
|
Technology
|
Cold Rolled /Hot Rolled
|
|
Length
|
2000/2438/2500/3000/3048 mm
|
|
Width
|
1000/1219/1250/1500 mm
|
|
Thickness
|
0.4-3mm(cold Rolled), 3-200mm(hot Rolled)
|
|
|
BA, 2B, NO.1,2D, 4K, 6K, 8K, NO.4, HL, SB, Embossed,perforated etc.
|
|
Leveling: improve flatness, esp. for items with high flatness request.
|
|
|
Skin-Pass: improve flatness, higher brightness
|
|
|
Other Choices
|
Cutting:Laser cutting, help the customer to cut the required size
|
|
Protection
|
1. Inter paper available
|
|
2. PVC protecting film available
|
|
|
Price Item
|
FOB,CIF,DDU,FCA,EXW ,.etc
|
|
Quality Assurance
|
1.Provide MTC (Mill Test).
2.Accept the inspection by the third party agent
|
1.4439, X2CrNiMoN17-13-5, AISI 317LMN - specification and destination
Type 1.4439 is a derivative and better austenitic variant of the 316 and 317 steel grades, having higher Nickel, Molybdenum and Nitrogen content, which significantly increases the product's resistance to pitting and crevice corrosion in Cl environments.
Stal finds its application in the chemical, energy, cryogenic, petrochemical, pulp and paper industries as well as in food contact with chlorides and the effects of high temperatures.
It shows a better yield point up to 400 ℃ compared to 1.4438, 1.4436, 1.4435 and 1.4432.
It is used for the production of special pumps, installations, radiators, apparatus, heat exchangers or tanks for chemicals - sulfuric, formic, nitric, acetic or sodium hydroxide in the form of bars, forgings, sheets and pipes.
The process of heat treatment - supersaturation is carried out at 1020 - 1120 ℃
| EN | 1.4439 - X2CrNiMoN17-13-5 - X 2 CrNiMoN 17-13-5 | ||||||||
| <0.03 | <2.0 | <1.0 | <0.045 | <0.015 | 16.5 - 18.5 | 12.5 - 14.5 | 4.0 - 5.0 | 0.12 - 0.22 | |
| EN | 1.4434 - X2CrNiMoN18-12-4 - X 2 CrNiMoN 18-12-4 | ||||||||
| <0.03 | <2.0 | <1.0 | <0.045 | <0.015 | 16.5 - 19.5 | 10.5 - 15.0 | 3.0 - 4.0 | 0.1 - 0.2 | |
| ASTM | UNS S31726 - AISI 317LMN | ||||||||
| <0.03 | <2.0 | <1.0 | <0.045 | <0.030 | 17.0 - 20.0 | 13.5 - 17.5 | 4.0 - 5.0 | 0.1 - 0.2 | |
| AFNOR | Z3CND18-14-05Az - Z 3 CND 18-14-05 Az | ||||||||
| <0.03 | <2.0 | <0.75 | <0.035 | <0.010 | 17.0 - 19.0 | 13.0 - 15.0 | 4.0 - 5.0 | 0.12 - 0.20 | |
Mechanical and physical properties of 1.4439, X2CrNiMoN17-13-5:
- Tensile strength, Rm: 580 - 800 MPa
- Yield point, Rp0,2: >280 MPa
- Elongation, A: >35%
- Impact resistance, KV20℃: >100 J
- Hardness: <250 HB
- Heat conductivity, λ: 14 W * m-1 * K-1
- Heat capacity, cp20℃: 500 J * kg-1 * K-1
- Modulus of elasticity, E: 200 GPa
- Specific resistance, Ω: 0.85 mkOhm * m
Mechanical properties at elevated temperatures
- Yield point, Rp0,2
- temp. 100℃ = >225 MPa
- temp. 200℃ = >185 MPa
- temp. 300℃ = >165 MPa
- temp. 400℃ = >150 MPa
- Linear Expansion Factor, α
- temp. 100℃ = 16,0 x 10-6 K-1
- temp. 200℃ = 16,5 x 10-6 K-1
- temp. 300℃ = 17,0 x 10-6 K-1
- temp. 400℃ = 17,5 x 10-6 K-1
- temp. 500℃ = 18,0 x 10-6 K-1
- Modulus of elasticity, E
- temp. 100℃ = 194 GPa
- temp. 200℃ = 186 GPa
- temp. 300℃ = 179 GPa
- temp. 400℃ = 172 GPa
- temp. 500℃ = 165 GPa
In the aforementioned grades we offer:
- Hot-rolled and cold-rolled sheets 1.4439, AISI 317LMN, X2CrNiMoN17-13-5
- Peeled and drawn bars 1.4439, AISI 317LMN, X2CrNiMoN17-13-5
- Forgings and forged bars 1.4439, X2CrNiMoN17-13-5
- Seamless and seamed tubes 1.4439, AISI 317LMN, X2CrNiMoN17-13-5
