Alloy 317LMN Austentitic Stainless Steel Plate ASTM A240/240M SS Plate Sheet
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 317LMN |
| Minimum Order Quantity | 500 kgs |
| Price | 3300 - 3480 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 317LMN |
|---|---|---|---|
| Standard | ASTM EN JIS GB | Size | 1219*2438mm 1500*3000mm |
| Thickness | 0.5 - 3.0mm | Type | Cold Rolled |
| Service | Cutting, Surface Treatment | Application | Auto Exhaust Pipe |
| Packing | Wooden Pallets | ||
| Highlight | Alloy 317LMN Stainless Steel Plate,Austentitic Stainless Steel Plate,ASTM A240 Stainless Steel Plate |
||
Product Description
Alloy 317LMN Austentitic Stainless Steel Plate ASTM A240/240M SS Plate Sheet
Products Specification
|
Product Name
|
317LMN Stainless Steel Sheets
|
|
Material Type
|
Ferrite stainless steel, magnetic; Austenitic stainless steel, Non-magnetic.
|
|
Grade
|
300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347
|
|
200series:201,202,202cu,204
|
|
|
400series:409,409L,410,420,430,431,439,440,441,444
|
|
|
Others:2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc
|
|
|
Duplex stainless steel:S22053,S25073,S22253,S31803,S32205,S32304
|
|
|
Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo
|
|
|
Technology
|
Cold Rolled /Hot Rolled
|
|
Length
|
2000/2438/2500/3000/3048 mm
|
|
Width
|
1000/1219/1250/1500 mm
|
|
Thickness
|
0.4-3mm(cold Rolled), 3-200mm(hot Rolled)
|
|
|
BA, 2B, NO.1,2D, 4K, 6K, 8K, NO.4, HL, SB, Embossed,perforated etc.
|
|
Leveling: improve flatness, esp. for items with high flatness request.
|
|
|
Skin-Pass: improve flatness, higher brightness
|
|
|
Other Choices
|
Cutting:Laser cutting, help the customer to cut the required size
|
|
Protection
|
1. Inter paper available
|
|
2. PVC protecting film available
|
|
|
Price Item
|
FOB,CIF,DDU,FCA,EXW ,.etc
|
|
Quality Assurance
|
1.Provide MTC (Mill Test).
2.Accept the inspection by the third party agent
|
317LMN Stainless Steel Composition
UNS S31726 is an austenitic alloy composed of iron (Fe), chromium (Cr), nickel (Ni), molybdenum (Mo) and nitrogen (N). The chemical composition of this alloy is typically expressed as follows: Fe 25.5-28%, Cr 18-20%, Ni 10-14%, Mo 3-4% and N 0.13-0.38%. The higher levels of chromium, molybdenum and nitrogen make this alloy so resistant to corrosion and oxidation.
| Element | Content (%) |
|---|---|
| Iron, Fe | Balance |
| Chromium, Cr | 17 – 20 |
| Nickel, Ni | 13.5 – 17.5 |
| Molybdenum, Mo | 4-5 |
| Manganese, Mn | 2 |
| Silicon, Si | 0.75 |
| Nitrogen, N | 0.10 – 0.20 |
| Phosphorus, P | 0.045 |
| Sulfur, S | 0.03 |
| Carbon, C | 0.03 |
317LMN Stainless Steel Physical Properties
| Density LBM/in^3 |
Coefficient of Thermal Expansion (min/in)-°F |
Thermal Conductivity BTU/ft^2-hr-°F-in | Specific Heat BTU/lbm -°F | Modules of Elasticity (annealed)^2-psi | |
|---|---|---|---|---|---|
| at 68 °F | at 77 – 212°F | at 77 – 1832°F | 68-212°F | at 32 – 212°F | in tension (E) |
| 0.29 | 9.2 | 10.8 | 100.8 | 0.11 | 28 x 10^6 |
317LMN Stainless Steel Mechanical Properties
The tensile strength of 317LMN ss ranges from 70 to 95 ksi. It has a yield strength ranging from 40 to 60 ksi and an elongation range from 15-45%. Its hardness ranges between 150 to 200 HBW on the Rockwell scale. This type of stainless steel also has good fatigue strength with an endurance limit ranging between 11 – 12 ksi.
| Properties | Metric | Imperial |
|---|---|---|
| Ultimate tensile strength | 614 MPa | 89 ksi |
| Yield strength | 317 MPa | 46 ksi |
| Elongation at break | 53% | 53% |
| Reduction in area | 69% | 69% |
| Hardness, Rockwell | 80 | 80 |
317LMN Stainless Steel Equivalent
- X2CrNiMoN17-13-5 (1.4439)
- S31726
- Z3CND18-14-05Az
317LMN Stainless Steel Uses
Because it’s highly resistant to corrosion and oxidation, this type of stainless steel can be used in applications where exposure to extreme temperatures or caustic chemicals is common such as chemical processing plants, paper mills or refineries. It’s also commonly used in power plant scrubber systems since it can withstand high temperatures without succumbing to corrosion or oxidation over time. It’s also used in oil production equipment since it can withstand high pressure without deforming or losing any properties due to its high tensile strength rating.
