ASTM A312 TP316L Stainless Steel Pipe Tube SS Pipe DN10 -DN800 SCH40S in 6m Length
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | TP316L |
| Minimum Order Quantity | 500 kgs |
| Price | 4650-5760 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Pipe | Grade | TP316L |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Industrial | Packing | Wooden Box Or PP Bag |
| Highlight | SCH40S Stainless Steel Pipe,DN10 -DN800 Stainless Steel Pipe,6m Length Stainless Steel Pipe |
||
Product Description
ASTM A312 TP316L Stainless Steel Pipe Tube SS Pipe DN10 -DN800 SCH40S in 6m Length
| Product Name | Stainless Steel Pipe Ss Pipe |
| Fabrication Standard | ASTM A213/269/312/789 |
| Material Grade | TP304 TP316 TP310S SS32750 TP321 TP347L 2507 S32205 254SMo 904L.etc |
| Out Diameter | 1/8" - 24" |
| Wall Thickness | 1.25mm - 80mm |
| Length | <= 18 Mtr |
| Surface | anealling and pickles surface, polishing |
| Package | by piece, in bundles, with external pvc wrapped, wood crated |
| Minimum Order Quantiy | 1 Metric Tons |
| Our Advantage | 1.regular sizes in stock over 2000 tons for immediate delivery |
| 2.small quantity with factory rate | |
| 3.quality certificate as per EN10204 3.1b issued by manufacturer | |
| 4.expert technical and export/import document consultant and support | |
| 5.on-time response by email, skype, website and online messages |
ASTM A312 Tp316l is a grade of tubular products. Oshwin Overseas is a large supplier of all kinds of ASTM A312 Tp316l Pipe Dimensions. We manufacture pipes of different schedules under different diameters. There are ASTM A312 Tp316l Equivalent products in the market as well. But our ASME A312 Tp316l products are unique in that they could be used at subzero temperatures as well. Our Stainless Steel Pipe A312 Tp316l ranges from small to medium sizes. We can also produce custom ASTM A312 Tp316l Seamless pipes as well.
ASTM A312 TP316L Equivalent grades
| GRADE | UNS | WERKSTOFF NR. | JIS | AFNOR | BS | GOST | EN | SS |
| USA | GERMAN | JAPAN | RUSSIAN | BRITISH | RUSSIAN | EUROPE | SWEDISH | |
| TP 316L | S31603 | 1.4404 / 1.4435 | SUS 316L | Z3CND17‐11‐02 / Z3CND18‐14‐03 | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 | 2348 |
ASTM A312 TP316L allowable stress
| SPECIFICATION | SA-312 | SA-312 |
|---|---|---|
| SS Grade | TP316L | TP316L |
| Nominal Composition | 16Cr-12Ni-2Mo | 16Cr-12Ni-2Mo |
| Product Shape | Welded pipe | Seamless & Welded pipe |
| UNS designation | S31603 | S31603 |
| Sizes/ Thickness [mm] | - | - |
| P Number | 8 | 8 |
| Group Number | 1 | 1 |
| Minimum Tensile Strength [MPa] |
485 | 485 |
| Minimum Yield Strength [MPa] |
170 | 170 |
AISI 316L Pipe Chemical Composition
| ASTM A312 | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| TP316L | min. | - | - | - | - | - | 16.0 | 2.0 | 10.0 | - |
| max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.03 | 18.0 | 3.0 | 14.0 | 0.10 | |
SA 312 TP 316L Pipe Standard
| STANDARD | SS 316L |
|---|---|
| ASTM | A312 |
| ASME | SA 312 |
| WERKSTOFF NR. / DIN | 1.4404 / 1.4435 |
| UNS | S31603 |
| JIS | SUS 316L |
| AFNOR | Z3CND17-11-02 / Z3CND18-14-03 |
ASTM A312 TP 316L Stainless Steel Pipe Roughness
| MATERIAL SURFACE | ABSOLUTE ROUGHNESS COEFFICIENT Ε MM |
|---|---|
| Aluminum Alloy, Lead | 0.001 - 0.002 |
| Drawn Copper/ Brass | 0.0015 |
| 316L Stainless Steel | 0.015 |
316L Pipe Hardness
| GRADE | ROCKWELL B HARDNESS (HR B) MAX | BRINELL HARDNESS (HB) MAX |
|---|---|---|
| 316L | 95 | 217 |
ASME SA 312 TP 316L Pipe Mechanical Properties
| ASTM A312 | Tensile Stress (MPa) min | Yield Stress 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| TP316L | 515 | 205 | 40 | 95 | 217 |
Why choose SS 316L Pipe manufacturers instead of a supplier?
- Avoid supplier commission & get lowest price
- All manufacturers provides MTC and MTR test reports with each delivery
- Custom sizes can be produced, depends on the quantity
- 100% exchange and return policy
- Assured High quality material
- Ready sizes to save cost and time
