Alloy 800h / 800HT Nickel Alloy Plate Sheet Width 1000mm 1219mm 1500mm Nickel Alloy

  • Alloy 800h / 800HT Nickel Alloy Plate Sheet Width 1000mm 1219mm 1500mm Nickel Alloy
  • Alloy 800h / 800HT Nickel Alloy Plate Sheet Width 1000mm 1219mm 1500mm Nickel Alloy
  • Alloy 800h / 800HT Nickel Alloy Plate Sheet Width 1000mm 1219mm 1500mm Nickel Alloy
  • Alloy 800h / 800HT Nickel Alloy Plate Sheet Width 1000mm 1219mm 1500mm Nickel Alloy
Place of Origin China
Brand Name DELTA
Certification ISO
Model Number UNS N08810 / 1.4958
Minimum Order Quantity 500 kgs
Price 40-45 USD/Kg
Packaging Details standard packing for export
Delivery Time 5 - 12 days based on the quantity
Payment Terms L/C, T/T, Western Union
Supply Ability 3 Ton per week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Products Nickel Alloy Sheet & Plate Grade UNS N08810
Thickness 0.5 - 30.0mm Standard Size 1000*2000mm 1219*2438mm
Standard ASTM EN Service Cutting
Loading Port Shanghai Port Surface 2B NO.1 NO.4 NO.8
Highlight

1500mm Nickel Alloy

,

800h Nickel Alloy

,

800HT Nickel Alloy
Leave a Message
Product Description

Alloy 800h / 800HT Nickel Alloy Plate Sheet Width 1000mm 1219mm 1500mm Nickel Alloy



Material
Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
Shape
Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet


Grade
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc
Alloy : Alloy 20/28/31
Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g
Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C,
Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602,
Hastelloy C-276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665
Haynes: Haynes 230/556/188
Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20
Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851,
Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 /
UNS N06600 / DIN W. Nr. 2.4816
Incoloy: Incoloy 800/800H/800HT/825/925/926;
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
Monel: Monel 400/K500/R405
Nitronic: Nitronic 40/50/60;
Nimonic: Nimonic 75/80A/90/A263 ;


Specification
Wire: 0.01-10mm
Strip: 0.05*5.0-5.0*250mm
Bar: φ4-50mm;Length 2000-5000mm
Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm


Product
Characteristics
1.According to the preparation process can be divided into deformation superalloys,
casting superalloys and powder metallurgy superalloys.
2.According to the strengthening mode, there are solid solution strengthening type, precipitation
strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc..
Standard
GB,AISI,ASTM,DIN,EN,SUS,UNS etc
Inspection
ISO,SGS,BV and so on.



Alloys 800H/HT  UNS N08810 / UNS N08811 / W.NR. 1.4959

Alloys 800H® and 800HT® are iron-nickel-chromium solid solution strengthened alloys with a nominal chemical composition of 42% iron, 34% nickel, and 22% chromium. These two grades are variations of the base grade 800 and are referred to by the tradenames Incoloy® 800H and Incoloy® 800HT and the universal designation UNS N08810 and N08811, respectively. 800H® and 800HT® share the high-temperature oxidation and carburization resistance of Alloy 800 but have enhanced creep and stress rupture properties.

CHEMICAL COMPOSITION

The base composition of 800H/HT® is identical to the parent Alloy 800. However, in both 800H® and 800HT®, the levels of carbon, aluminum, and titanium are modified for improved creep resistance. The base 800 grade has a carbon range of 0 - 0.10%, while 800H® raises the minimum carbon level to 0.05%. Similarly, the base 800 grade has a combined aluminum and titanium content requirement of 0.30 - 1.20%, while 800HT® raises the minimum Al + Ti level to 0.85% and increases the minimum carbon to 0.06%.

CORROSION RESISTANCE

Both grades share the corrosion resistant characteristics of the base grade Alloy 800, including good general corrosion resistance, as well as good resistance to reducing and oxidizing acids, organic acids, seawater, salts, and particularly excellent resistance to nitric acid. Alloy 800H and 800HT also exhibit excellent corrosion resistance to chloride stress corrosion cracking (SCC). However, alloys 800H and 800HT are not recommended for sulfuric acid service. Additionally, they are susceptible to chromium carbide precipitation along grain boundaries when subjected to temperatures in the range of 1000°F - 1400°F (538°C - 760°C).

ELEVATED TEMPERATURE RESISTANCE

800H and 800HT have outstanding resistance to oxidation, carburization, and sulfidation at temperatures up to 1800°F.


MECHANICAL PROPERTIES

800H and 800HT are typically supplied in a low-strength solution annealed condition. While intended for high-temperature applications, they have excellent toughness down to cryogenic temperatures.


HEAT TREATMENT

Alloys 800H and 800 HT cannot be strengthened by heat treating. They are typically solution annealed at 2050°F - 2150°F (1121°C - 1177°C) followed by rapid cooling. Stress-relieving at 1000°F - 1600°F (538°C - 870°C) may also be performed after cold working to reduce residual stresses and prevent distortion.

WORKABILITY

Alloy 800H and 800HT can be cold worked using common methods and should be in the annealed condition prior to cold working. The large grain size produced in both grades from solution annealing can lead to “orange peel” surface roughening after cold working. Hot-working should be done above 1600°F (871°C).

APPLICATIONS

Alloy 800H® and 800HT® are used at temperatures from 1100°F – 1800°F (593°C – 982°C) where creep and stress rupture failure is a concern. 800H® is typically used at the lower end of this range, while 800HT® is employed at the upper end. Applications include structural members, furnace equipment, heat exchangers, petrochemical vessels and piping, and aerospace. CRA offers specialty alloy 800H/HT® seamless pipe & tube for use in multiple industries and applications, including:

  • Furnace Equipment
  • Aerospace
  • Petrochemical Vessels & Piping

Chemical Composition

UNS Designation N08800 N08810 N08811
Incoloy Alloys 800 800H 800HT
Nickel 30.0 - 35.0 30.0 - 35.0 30.0 - 35.0
Chromium 19.0 - 23.0 19.0 - 23.0 19.0 - 23.0
Iron 39.5 min. 39.5 min 39.5 min.
Carbon 0.10 max 0.05 - 0.10 0.06 - 0.10
Aluminum 0.15 - 0.60 0.15 - 0.60 0.25 - 0.60
Titanium 0.15 - 0.60 0.15 - 0.60 0.25 - 0.60

Aluminum +

Titanium

 0.30 - 1.20 0.30 - 1.20 0.85 - 1.20
ASTM Grain Size Not Specified 5 or Coarser 5 or Coaser



Alloy 800h / 800HT Nickel Alloy Plate Sheet Width 1000mm 1219mm 1500mm Nickel Alloy 0Alloy 800h / 800HT Nickel Alloy Plate Sheet Width 1000mm 1219mm 1500mm Nickel Alloy 1Alloy 800h / 800HT Nickel Alloy Plate Sheet Width 1000mm 1219mm 1500mm Nickel Alloy 2Alloy 800h / 800HT Nickel Alloy Plate Sheet Width 1000mm 1219mm 1500mm Nickel Alloy 3

  •
