SCH40S SCH80S SCH160S Hastelloy C276 Pipe Tube Seamless Pipe in 6m Length EN 2.4819
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Hastelloy C276 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Pipe | Grade | Hastelloy C276 |
|---|---|---|---|
| Diameter | DN10 - DN300 | Length | 6000mm Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Black, Bright |
| Highlight | Seamless Hastelloy C276 Pipe,SCH160S Hastelloy C276 Pipe,SCH80S Hastelloy C276 Pipe |
||
Product Description
SCH40S SCH80S SCH160S Hastelloy C276 Pipe Tube Seamless Pipe in 6m Length EN 2.4819
Alloy C276 Pipes Standard Quality Specification
| Specifications | ASTM B 622 ASME SB 622 / ASTM B 619 ASME SB 619 |
| Dimensions | ASME, ASTM, and API |
| Size | 15″NB upto 150″NB IN |
| Specialized in | Sizes in Large Diameter |
| Schedule | Schedule 5, 10, 40, STD, 80, 160 |
| Type | ERW / Seamless / Welded / LSAW Pipes / Fabricated |
| Form | Hydraulic, Round, Etc |
| Length | Double Random, Single Random, & Cut Length. |
| End | Beveled End, Plain End, Treaded |
Hastelloy C276 Pipe Specification
Alloy C276 Seamless Pipe
- Outside Diameter: 3-600mm
- Wall Thickness: 0.5-30mm
- Length: 0.5- 12 meter
WNR 2.4819 Welded Pipe
- Outside Diameter: 6-200mm
- Wall Thickness:0.35-6.00mm
- Length: 0.5- 12 meter
Nickel C276 Thick-Walled Pipe
- Outside Diameter: 10-600mm
- Wall Thickness:2.5 - 100mm
- Length: 0.5- 12 meter
- Trade name: Nicrofer® 5716, Nickelvac® HC276
International Specification
- ASTM B622 | ASME SB622
- UNS: N10276
- WNR: 2.4819
- Other: ASTM B619, ASTM B775, ASTM B516
About Hastelloy C276 Pipe
- Density:8.89 g/cm(3)
- Melting Point:1325–1370°C (2415–2500°F)
- Temprature Range: 1,323-1,371°C
- Brand: DELTA
Useful Information
- Finish: Annealing, Bright, Polished
- Method: Precision Rolled, Hot Formed, Cold Formed
- Testing: Chemical, Ultrasonic, Mechanical, PMI
- Manufacturing Process: Welded, ERW, Seamless
Nickel alloy c276 cold finished pipe welded pipe services
- Cut-to-length services
- Machining
- Welding
- Beveling
- Threading
WNR 2.4819 bright annealed pipe features
- Mechanical properties
- Heat treatment
- Corrosion resistance
- Elevated temperature resistance
- Workability
NW 0276 Cold Finished Seamless Pipe Marking
- Method of manufacturing (Seamless / Welded)
- Specification
- Material grade
- Nominal Size
- Heat number
- Manufacturer’s name or custom logo – on request
EN 2.4819 round pipe inspection checklist
- Mechanical test
- Destructive test
- Non destructive test
- Pmi test
- Nabl approved lab test
- Flaring Test
UNS N10276 Annealed Pipe Documentation Offered
- Copy of Invoice
- Country of Origin Certificate (Original)
- Bill of Lading.
- Manufacturer’s MTC certifying
Nickel C276 Annealed Pipe Equipment
- Sand-blasting machine
- Press machine
- Bending machine
- Electric bevelling machine
EN 2.4819 Pipe Welding Method
- FCAW, TIG
- Submerged arc welding
- SMAW
- GMAW including both MIG and MAG
Alloy C276 Seam Welded Pipe Physical Properties
- Hardness Range: 40 HRc
- Elongation: 40 %
- Electrical Resistivity :51 microhm-in.
Alloy C276 Seamless Pipe Properties
Offer Alloy C276 round pipe suitable for aggressive environments, refer hastelloy c276 chemical composition
| C | W | Mn | Fe | S | Si | Cr | Ni | Co | Mo | P | V | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | - | 3.000 | - | 4.000 | - | - | 14.500 | Bal | - | 15.000 | - | - |
| MAX | 0.010 | 4.500 | 1.000 | 7.000 | 0.030 | 0.080 | 16.500 | 2.500 | 17.000 | 0.040 | 0.035 |
| Yield Strength0.2% Proof(MPa) | Tensile strength(MPa) | Elongation (% in 50mm) | Hardness (HRB) | |
|---|---|---|---|---|
| MIN | 283 | 690 | 40.00 | - |
| MAX | - | - | - | 100 |
| Density | lb/in³ | 0.321 |
|---|---|---|
| g/cm³ | 8.89 | |
| Specific Heat | Btu/lb•°F | 0.102 |
| J/kg•°C | 427 | |
| Melting Range | °F | 2415-2500 |
| °C | 1325-1370 | |
| Thermal Conductivity | Btu•in/ft²•h•°F | 67.9 |
| W/m•°C | 427 | |
| Young's Modulus | 103 ksi | 29.8 |
| GPa | 205 | |
| Shear Modulus | 103 ksi | 11.4 |
| GPa | 79 | |
| Permeability | 200 oersted (15.9 kA/m) | 1.0002 |
| Poisson's Ratio | 0.307 |
-
Density lb/in³ 0.321 g/cm³ 8.89 Specific Heat Btu/lb•°F 0.102 J/kg•°C 427 Melting Range °F 2415-2500 °C 1325-1370 Thermal Conductivity Btu•in/ft²•h•°F 67.9 W/m•°C 427 Young's Modulus 103 ksi 29.8 GPa 205 Shear Modulus 103 ksi 11.4 GPa 79 Permeability 200 oersted (15.9 kA/m) 1.0002 Poisson's Ratio 0.307
