Hot Rolled Hastelloy C276 Round Bar / Nickel Alloy Rod Diameter 20 - 200mm for Chemical Area
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Hastelloy C276 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Bars | Grade | Hastelloy C276 |
|---|---|---|---|
| Diameter | 6 - 250mm | Length | 6000mm Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Black, Bright |
| Highlight | Hot Rolled nickel alloy rod,Hastelloy C276 nickel alloy rod,20mm nickel alloy rod |
||
Product Description
Hot Rolled Hastelloy C276 Round Bar / Nickel Alloy Rod Diameter 20 - 200mm for Chemical Area
| Form | Nickel Alloy Bars |
| Grade | Alloy C276 |
| Outer Diameter (mm) | 6mm-250mm or according to customer’s requirement |
| Length | 1meter, 3 meters and 6 meters or customer’s requirement |
| Standard | ASTM, ASME, EN, JIS, DIN, GB/T, etc |
| Process Method | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar & Rod |
| Surface Finish | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Other Grade |
Hastelloy : B2 B3 C22 C276 G30 X Incoloy: 800 800H 800HT 825 925 A286 330 Inconel: 600 601 617 625 718 725 X-750 Monel: 400 k-500 |
| Price Item | EXW FOB CFR CIF |
| Payment | 30% TT inadvance, 70% TT Balance against copy of B/L |
| Delivery Time | It depends on your bars order total quantity and stock of these mother origin materials. Usually from the start of the order to the completion of production is about 3-4 weeks |
| Quality Requirement | Mill test certificate will be offered with shipment, the third party inspection is available |
| Main Markets | Europe, North America, Middle East, Southeast Asia |
| Metal Test | High or low temperature impact test, metallographic analysis |
| Chemical Analysis | As nickel alloy C276 bars standard |
HASTELLOY C276 is a Nickel-chromium-molybdenum wrought alloy that is considered the most versatile corrosion resistant alloy available. This alloy is resistant to the formation of grain boundary precipitates in the weld heat-affected zone, thus making it suitable for most chemical process applications in an as welded condition. Alloy C-276 also has excellent resistance to pitting, stress-corrosion cracking and oxidizing atmospheres up to 1900°F. Alloy C-276 has exceptional resistance to a wide variety of chemical environments.
High Performance Alloys stocks and produces HASTELLOY C276 in this grade in the following forms: Bar, hex bar, square bar, wire spool, wire cuts, loose coil, sheet, plate, coil , tube, pipe, nipple, elbow, fitting, coupling, flange, fasteners, forging, disk, machined
Characteristics of Hastelloy C276 Round Bar
- HASTELLOY C276 is one of the few alloys resistant to wet chloride gas, hypochlorite and chlorine dioxide solutions.
- HASTELLOY C276 has exceptional resistance to strong solutions of oxidizing salts, such as ferric and cupric chlorides.
- HASTELLOY C276 is not prone to grain boundary precipitation in the as welded condition and therefore suitable for many chemical process applications
Applications of Hastelloy C276 Round Bar
- Digesters and bleach plants in the paper industry.
- Components exposed to sour gas.
- Equipment for flue-gas desulfurisation plants.
- Evaporators, heat exchangers, filters and mixers used in sulfuric acid environments.
- Sulfuric acid reactors.
- Organic chloride process equipment.
- Equipment for processes utilizing halide or acid catalysts.
Some typical applications of HASTELLOY C276 include equipment components in chemical and petrochemical organic chloride processes and processes utilizing halide or acid catalysts. Other industry applications are pulp and paper (digesters and bleach areas), scrubbers and ducting for flue gas desulfurization, pharmaceutical and food processing equipment.
HASTELLOY C-276 is a nickel-chromium-molybdenum alloy with universal corrosion resistance unmatched by any other alloy. It has outstanding resistance to a wide variety of chemical process environments including ferric and cupric chlorides, hot contaminated mineral acids, solvents, chlorine and chlorine contaminated (both organic and inorganic), dry chlorine, formic and acetic acids, acetic anhydride, sea water and brine solutions and hypochlorite and chlorine dioxide solutions. Alloy C276 also resists formation of grain boundary precipitates in the weld heat affected zone making it useful for most chemical processes in the as-welded condition. It has excellent resistance to pitting and stress corrosion cracking.
HASTELLOY C276 sheet 0.044" thick in the heat-treated condition at 2050°F, rapid quenched, has an average olsen cup depth of 0.48". Alloy C-276 can be successfully fabricated by many methods. The alloy tends to work harden but with the proper care, the alloy is readily hot and cold formed. Complete information on welding, machining and forming is available
Chemical Composition of Hastelloy C276
|
|
Ni |
Cr |
Mn |
Mo |
C |
Si |
Fe |
|---|---|---|---|---|---|---|---|
| Max % | Bal. | 16.5 | 1.0 | 17.0 | 0.010 | 0.08 | 7.0 |
| Min % | 14.5 | 15.0 | 4.0 |
Hastelloy C276 Products and Standard
| Form | Standard |
|
UNS |
UNS N10276 |
|---|---|
|
Bar |
ASTM B574 Din 17752 |
|
Wire |
|
|
Sheet |
ASTM B575 Din 17750 |
|
Plate |
ASTM B575 Din 17750 |
|
Fitting |
ASTM B366 |
|
Forging |
ASTM B564 |
|
Tube |
ASTM B619 ASTM B622 ASTM B626 Din 17751 |
|
Pipe |
ASTM B619 ASTM B622 ASTM B626 Din 17751 |
|
Weld Wire |
A5.14 ERNiCrMo-4 |
|
Weld Electrode |
A5.11 ENiCrMo-4 |
|
Din. |
2.4819 All Forms |
