Monel K-500 Plate Thickness 0.4 - 30.0mm UNS N05500 Nickel - Copper Alloy Plate
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Monel K500 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Sheet & Plate | Grade | Monel K500 |
|---|---|---|---|
| Thickness | 0.5 - 30.0mm | Standard Size | 1000*2000mm 1219*2438mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 NO.4 NO.8 |
| Highlight | N05500 Monel K-500 Plate,30.0mm Monel K-500 Plate |
||
Product Description
Monel K-500 Plate Thickness 0.4 - 30.0mm UNS N05500 Nickel - Copper Alloy Plate
|
Material
|
Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
|
|
Shape
|
Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet
|
|
Grade
|
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
|
|
Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc
|
|
|
Alloy : Alloy 20/28/31
|
|
|
Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g
|
|
|
Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C,
|
|
|
Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602,
|
|
|
Hastelloy C276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665
|
|
|
Haynes: Haynes 230/556/188
|
|
|
Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20
|
|
|
Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851,
|
|
|
Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 /
UNS N06600 / DIN W. Nr. 2.4816 |
|
|
Incoloy: Incoloy 800/800H/800HT/825/925/926;
|
|
|
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
|
|
|
Monel: Monel 400/K500/R405
|
|
|
Nitronic: Nitronic 40/50/60;
|
|
|
Nimonic: Nimonic 75/80A/90/A263 ;
|
|
|
Specification
|
Wire: 0.01-10mm
|
|
Strip: 0.05*5.0-5.0*250mm
|
|
|
Bar: φ4-50mm;Length 2000-5000mm
|
|
|
Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
|
|
|
Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
|
Monel K500 - UNS N05500 Nickel-Copper Alloy
| Grade | C | Mn | S | Si | Ni | Cu | Ti | Al | Fe |
| Monel K500 | 0.25 | 1.5 | 0.01 | 0.5 | 63.0 | 27-33 | 0.35-0.85 | 2.3-3.15 | 2.0 |
Monel K500 is a nickel-copper alloy with the same corrosion resistance and characteristics as the Monel 400. Due to added aluminum and titanium the nickel alloy Monel K-500® has a greater strength and hardness than the 400. In age-hardened condition, Monel K-500 also has greater tendency toward stress- corrosion cracking in some environments.
Nickel alloy Monel K500 in a variety of forms, including:
- Bar
- Wire
- Sheet
- Plate
- Forgings
- Pipe fittings
- Flanges
- Seamless & Welded pipe
- Seamless Tube & Welded tube
Nickel alloy Monel K500 has many different industrial applications, some of which include:
- Pump shafts and impellers
- Doctor blades and scrapers
- Oil-well drill collars and instruments
- Electronic components
- Springs
- Valve trim
