Inconel 625 / DIN 2.4856 Alloy Plate Hot Rolled 3.0 - 30.0mm Thickness 625 Alloy Plate
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | inconel 625 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Sheet & Plate | Grade | Inconel 625 |
|---|---|---|---|
| Thickness | 0.5 - 30.0mm | Standard Size | 1000*2000mm 1219*2438mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 NO.4 NO.8 |
| Highlight | Hot Rolled Inconel 625 Alloy Plate,30.0mm Inconel 625 Alloy Plate,3mm inconel 625 sheet |
||
Product Description
Inconel 625 / DIN 2.4856 Alloy Plate Hot Rolled 3.0 - 30.0mm Thickness 625 Alloy Plate
|
Material
|
Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
|
|
Shape
|
Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet
|
|
Grade
|
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
|
|
Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc
|
|
|
Alloy : Alloy 20/28/31
|
|
|
Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g
|
|
|
Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C,
|
|
|
Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602,
|
|
|
Hastelloy C276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665
|
|
|
Haynes: Haynes 230/556/188
|
|
|
Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20
|
|
|
Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851,
|
|
|
Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 /
UNS N06600 / DIN W. Nr. 2.4816 |
|
|
Incoloy: Incoloy 800/800H/800HT/825/925/926;
|
|
|
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
|
|
|
Monel: Monel 400/K500/R405
|
|
|
Nitronic: Nitronic 40/50/60;
|
|
|
Nimonic: Nimonic 75/80A/90/A263 ;
|
|
|
Specification
|
Wire: 0.01-10mm
|
|
Strip: 0.05*5.0-5.0*250mm
|
|
|
Bar: φ4-50mm;Length 2000-5000mm
|
|
|
Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
|
|
|
Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
|
Alloy 625 is perfectly suited to the most demanding applications, from sub-zero to extremely high-temperature environments. It achieves these levels of high strength as a result of the solid solution effects of molybdenum and niobium (also known as Colombium) from room temperatures up to 800°C. Alloy 625 is usually supplied in the hot worked and annealed condition.
Alloy 625 is particularly useful in situations where oxidation resistance and avoidance of pitting are required. In the annealed condition, this Inconel Alloy is fully austenitic and suitable for machining. It provides excellent corrosion resistance in a wide variety of severely corrosive environments due to its high alloy content. With nearly 60% nickel composition it is virtually immune from stress corrosion cracking.
Alloy 625 is non-magnetic and able to operate over a wide temperature range, from cryogenic temperatures up to 980degC. This supports applications in jet engines, heat exchangers, furnace hardware and chemical plant equipment.
Chemical Composition:
| Cr | Ni | Mo | Co | Nb (+Ta) | Ti | W | Cu | C | Mn | N | Si | P | S | Fe | Al | |
| Min | 20.00 | 58.00 | 8.00 | 3.15 | ||||||||||||
| Max | 23.00 | 10.00 | 1.00 | 4.15 | 0.40 | 0.10 | 0.50 | 0.50 | 0.015 | 0.015 | 5.00 | 0.40 |
Mechanical Properties:
| Bars up to and including 4” diameter or section | Bars above 4” diameter or section | |||
| 0.2% Proof Stress | 415 N/mm2 | 60ksi | 345 N/mm2 | 50ksi |
| Tensile Strength | 830 N/mm2 | 120ksi | 760 N/mm2 | 110ksi |
| Elongation, 5.65√S0 and 4D | 30% | 25% | ||
| Reduction of Area | 35% | 35% | ||
| Hardness (Brinell) | ||||
Key Features:
- Good strength/ductility properties from sub-zero temperatures to over 980°C
- Excellent corrosion and fatigue resistance in a wide variety of corrosive environments including seawater and industrial acids
- Non-magnetic and spark resistant
- Resistant to high temperature oxidation and carburisation
- Excellent resistance to stress corrosion cracking
Applications:
- Wellhead components
- Sheathing, Fasteners, Clamps
- Downhole equipment for corrosive/sour service
- Propellers and Shafts
- Propulsion Motors
- Fasteners
- Reactor core & control rod components
- Chemical process equipment
FAQ
Q: Are you trading company or manufacturer ?
A: We are a professional manufacturer with 20 years' experience and have took part in international trade for 10 years.
Q: How about your quality and how do you guarantee the quality?
A: All products we supply is primary as you need, Our company is certificated to ISO9001: 2008, and every product will be tested for 4-5 processes. We welcome customers or the third party inspection agencies to come to our factory for inspection.
Q: Do you provide samples ? Is it free or extra ?
A: Yes, we could offer the sample for free charge.
Q: How long is your delivery time?
A: For Stocks, we can send the goods to loading port within 7 days after receiving the deposit ;
For production period, it usually needs about 15 days ~30 days after receiving the deposit.
Q: What is your terms of payment ?
A: Usually 30% deposit by TT in advance and balance against copy pf BL or L/C at sight.
