EN 2.4856 / Alloy 625 Nickel Alloy Sheet 2B NO 4 HL BA Finishing 0.4 - 3.0mm Thickness Cold Rolled
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | inconel 625 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Sheet & Plate | Grade | Inconel 625 |
|---|---|---|---|
| Thickness | 0.5 - 30.0mm | Standard Size | 1000*2000mm 1219*2438mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 NO.4 NO.8 |
| Highlight | EN 2.4856 nickel alloy plate,3.0mm nickel alloy plate,2B NO 4 nickel alloy plate |
||
Product Description
EN 2.4856 / Alloy 625 Nickel Alloy Sheet 2B NO,4 HL BA Finishing 0.4 - 3.0mm Thickness Cold Rolled
|
Material
|
Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
|
|
Shape
|
Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet
|
|
Grade
|
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
|
|
Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc
|
|
|
Alloy : Alloy 20/28/31
|
|
|
Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g
|
|
|
Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C,
|
|
|
Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602,
|
|
|
Hastelloy C276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665
|
|
|
Haynes: Haynes 230/556/188
|
|
|
Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20
|
|
|
Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851,
|
|
|
Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 /
UNS N06600 / DIN W. Nr. 2.4816 |
|
|
Incoloy: Incoloy 800/800H/800HT/825/925/926;
|
|
|
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
|
|
|
Monel: Monel 400/K500/R405
|
|
|
Nitronic: Nitronic 40/50/60;
|
|
|
Nimonic: Nimonic 75/80A/90/A263 ;
|
|
|
Specification
|
Wire: 0.01-10mm
|
|
Strip: 0.05*5.0-5.0*250mm
|
|
|
Bar: φ4-50mm;Length 2000-5000mm
|
|
|
Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
|
|
|
Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
|
Inconel Alloy 625 is a widely used material in the aerospace, automotive, chemical, and processing industries due to its high strength, corrosion resistance, and high-temperature tolerance. Inconel Alloy 625 Sheets are particularly popular as they offer all the benefits of Inconel Alloy 625 in a versatile and easy-to-use form. This ultimate guide will explore everything you need to know about Inconel Alloy 625 Sheets, including their properties, uses, fabrication, and maintenance.
What is Inconel Alloy 625 Sheets?
Inconel Alloy 625 Sheets are specially designed stainless steel sheets that are composed primarily of nickel, chromium, and molybdenum. This unique combination of elements provides superior mechanical properties, excellent corrosion resistance even in highly corrosive environments, and incredible strength at high temperatures.
It is resistant to pitting and crevice corrosion and oxidation-resistant up to 2000°F (1093°C). Additionally, Inconel Alloy 625 Sheets have exceptional fatigue strength, which makes it ideal for structural components exposed to cyclic loadings, such as fasteners and springs.
Standard Size of our Inconel 625 Sheets in Stock
| 0.4*1219*2438mm | 0.5*1219*2438mm | 0.6*1219*2438mm | 0.8*1219*2438mm |
| 1.0*1219*2438mm | 1.2*1219*2438mm | 1.5*1219*2438mm | 2.0*1219*2438mm |
| 2.5*1219*2438mm | 3.0*1219*2438mm | 4.0*1500*6000mm | 5.0*1500*6000mm |
| 6.0*1500*6000mm | 8.0*1500*6000mm | 10.0*1500*6000mm | 12.0*1500*6000mm |
| 14.0*1500*6000mm | 16.0*1500*6000mm | 20.0*1500*6000mm | 30.0*1500*6000mm |
Properties of Inconel Alloy 625 Sheets
Inconel Alloy 625 Sheets are made of a nickel-based alloy that contains highly controlled amounts of iron, chromium, and molybdenum. These elements give Inconel Alloy 625 Sheets unique properties that suit various applications. Inconel Alloy 625 Sheets have high tensile strength, excellent resistance to corrosion, oxidation, and pitting, and outstanding thermal stability. They can withstand temperatures up to 980°C without degrading or changing their properties. Inconel Alloy 625 Sheets also exhibit good fatigue strength, making them suitable for high-stress applications.
Uses of Inconel Alloy 625 Sheets
Inconel Alloy 625 Sheets are used in various industries due to their excellent properties. They are commonly used in the aerospace industry for engine and exhaust components, in the chemical and processing industry for equipment exposed to corrosive environments, and in the automotive industry for exhaust systems. They are also used in the marine, oil and gas, and nuclear power industries due to their resistance to corrosion and high-temperature tolerance. Inconel Alloy 625 Sheets can also be used as welding wires and filler metals due to their low thermal expansion and good weldability.
Fabrication of Inconel Alloy 625 Sheets
Inconel Alloy 625 Sheets are fabricated using various techniques such as hot and cold rolling, forging, and stamping. They can also be welded using various welding techniques, such as gas tungsten arc welding (GTAW) and gas metal arc welding (GMAW). The choice of the fabrication technique depends on the specific application of the Inconel Alloy 625 Sheets. However, care must be taken during the fabrication process to avoid introducing defects that can affect the properties of the final product.
Maintenance of Inconel Alloy 625 Sheets
Inconel Alloy 625 Sheets are relatively easy to maintain due to their resistance to corrosion and high-temperature tolerance. Regular cleaning and inspection of the Inconel Alloy 625 Sheets are necessary to prevent minor defects from becoming major problems. In case of damage, repairs can be done using the same techniques used to fabricate the Inconel Alloy 625 Sheets. However, care must be taken to avoid introducing new defects in the process.
