EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | hastelloy c276 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Sheet & Plate | Grade | Hastelloy C276 |
|---|---|---|---|
| Thickness | 0.5 - 30.0mm | Standard Size | 1000*2000mm 1219*2438mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 NO.4 NO.8 |
| Highlight | N10276 nickel alloy plate,NO.1 nickel alloy plate,C276 nickel alloy plate |
||
Product Description
EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing
| Product Type | Hastelloy C276 ASTM B575 Sheet, Hastelloy C276 ASTM B575 Plate |
|---|---|
| Specification | ASTM B575 / ASME SB575 |
| Tolerances (width / thickness) |
|
| Dimensions |
|
| Thickness | 0.1 to 100 mm Thk |
| Width | 10-2500mm |
| Length | 2m, 2.44m, 3m, or as required |
| Finish | SATIN, 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), No.1 finish hot rolled, 1D, No.4, BA, 8K, hairline, brush, mirror etc. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard |
| variety of shapes | Coils, Foils, Plates, Sheet, Strip, Plain Sheet, Checker Plates, Rolling Sheet, Flats, Clad Plates, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), Rolling Plates, Flat Shim, soft annealed, descaled, tread Plates, sheared, annealed |
Hastelloy C276 Sheet is a high-quality, corrosion-resistant alloy made from nickel, molybdenum, and chromium. It has excellent resistance to hot oxidizing and reducing media, as well as to a wide range of other contaminants.
Hastelloy C276 Sheets is used in many industries, including the pulp and paper industry, oil and gas production, and chemical processing.
Equivalent Grades of Hastelloy C-276 Shim
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN | DIN | ISO | GOST | OR |
| Hastelloy C276 | 2.4819 | N10276 | NW 0276 | NiMo16Cr15W | 17750 | 6208 | ХН65МВУ | ЭП760 |
Chemical Composition of Hastelloy C276 Sheet
| C | Mn | Si | S |
Co |
Ni | Cr | Fe | Mo | P |
| 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
Mechanical Properties of B575 Hastelloy C276 Sheet
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
Hastelloy C276 Application
There are many sectors and industries consuming ASTM B575 Hastelloy C276 Sheet like:
| Organic chloride process equipment | Evaporators, heat exchangers, filters and mixers used in sulfuric acid environments |
| Equipment for flue-gas desulfurisation plants | Equipment for processes utilizing halide or acid catalysts |
| Digesters and bleach plants in the paper industry | Sulfuric acid reactors |
| Components exposed to sour gas | Military |
| Defence & Aerospace industries | Used for Oil and Gas |
