Hastelloy C276 UNS N10276 Nickel Alloy Plate Sheet Thickness 0.4 - 30.0mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | hastelloy c276 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Sheet & Plate | Grade | Hastelloy C276 |
|---|---|---|---|
| Thickness | 0.5 - 30.0mm | Standard Size | 1000*2000mm 1219*2438mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 NO.4 NO.8 |
| Highlight | N10276 hastelloy c276 plate,C276 nickel alloy plate,30.0mm hastelloy c276 plate |
||
Product Description
Hastelloy C276 UNS N10276 Nickel Alloy Plate Sheet Thickness 0.4 - 30.0mm
| Products Name | hastelloy C276 nickel alloy plate sheet |
| Thickness |
Cold rolled: 0.5 - 3.0mm Hot rolled 4.0 - 30.0mm |
| Standard Size | 1000*2000mm 1219*2438mm 1219*3048mm 1500*6000mm |
| Surface | 2B NO.1 |
| MOQ | 50 kgs |
| Service | Cutting, Surface Finishing |
| Packing | Waterproof paper and wooden pallets |
| Loading Port | Shanghai Port |
| Price term | FOB CFR CIF EXW |
| Payment term | 30% TT in advance , 70% TT balance against copy of B/L |
| Other Grade | Hastelloy C22 C4 X C276 |
| Monel 400 K500 | |
| Incoloy 800 800H 800HT 825 925 | |
| Inconel 600 601 625 716 718 | |
| Stainless Steel Grade | 201 202 301 304L 309S 310S 316L 316Ti 317L 321 347 409L 410 410S 420J1 420J2 430 431 436L 439 440A/B/C 441 443 444 2205 2507 904L 254SMO 253MA |
Hastelloy C276 ASTM Standard B575 Plate is a nickel-molybdenum-chromium superalloy with an enhancement of tungsten made to have superb deterioration resistance in a wide variety of extreme atmospheres. Although there are a number of variations of the nickel alloy, Hastelloy C276 Plate is without a doubt the most commonly used. Alloy C276 Plate shows superb deterioration resistance in a range of extreme settings and also media. Like lots of other nickel alloys, it is pliable, easily developed and also welded.
ASTM B575 UNS N10276 Hastelloy C276 Sheet is frequently utilized in several industries, consisting of petrochemical, chemical oil and gas, power generation, pharmaceutical, pulp and paper manufacturing and drainage treatment. Hastelloy C276 Coil has superior resistance to matching, tension deterioration breaking as well as oxidizing environments. ASME SB 575 UNS N10276 material likewise displays resistance to deterioration by salt water in crevice conditions, which can generate hostile attack in other commonly utilized materials. UNS N10276 Plate is usually remedy heat-treated at 2050 Degree F and fast quenched.
Hastelloy C276 Plate /Sheet Thickness
| Cold rolled Hastelloy C276 ASTM B575 thin Plates | 0.2-4mm |
| Hot rolled ASTM B575 C276 Alloy medium Plates | 4-20mm |
| Hot rolled ASTM B575 UNS N10276 thick Plates | 20-60mm |
| Hot rolled Alloy C276 extra thick Plates | 60-115mm |
2.4819 Alloy C 276 Plate equivalent
| Europe | America | Japan | Russia | Europe | Russia | |
|---|---|---|---|---|---|---|
| STANDARD |
WERKSTOFF NR. |
UNS | JIS | GOST | EN | OR |
| Alloy C276 | 2.4819 | N10276 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ЭП760 |
Hastelloy C276 ASTM B575 chemical composition
| Hastelloy C276 | Analysis |
|---|---|
| Ni | Bal |
| Mo | 15 – 17 |
| Cr | 14.5 – 16.5 |
| Fe | 4 – 7 |
| W | 3 – 4.5 |
| Co | 2.5 max |
| Mn | 1.0 max |
| C | 0.01 max |
| v | 0.35 max |
| P | 0.04 max |
| S | 0.03 max |
| Si | 0.08 max |
UNS N10276 Plates mechanical properties
| Density | 8.89 g/cm3 |
| Melting Range | 1370 °C (2500 °F) |
| Tensile Strength | Psi – 1,15,000 MPa – 790 |
| Yield Strength (0.2%Offset) | Psi – 52,000 MPa – 355 |
| Elongation | 40 % |
