EN 1.4571 Alloy Seamless Stainless Steel Pipe Tube SCH40S SCH80S AISI316Ti Stainless Steel
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 316Ti / UNS S31635 / EN 1.4571 |
| Minimum Order Quantity | 500 kgs |
| Price | 4650-5760 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Pipe | Grade | 316Ti / UNS S31635 / EN 1.4571 |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN500 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Industrial | Packing | Wooden Box Or PP Bag |
| Highlight | SCH40S Stainless Steel Pipe,AISI316Ti Stainless Steel Pipe,EN 1.4571 Stainless Steel Pipe |
||
Product Description
EN 1.4571 Alloy Seamless Stainless Steel Pipe Tube SCH40S SCH80S AISI316Ti Stainless Steel
| Name | stainless steel pipe |
| Standard | ASTM, GB, JIS, DIN, EN, AISI |
| Material Grade | TP304 TP304L TP316 TP316L TP316Ti TP347 TP347H TP321 TP321H TP310 TP310S |
| TP410 TP410S TP403 | |
| S31803/S32205 S32750 S32760 | |
| Outer Diameter | Seamless Pipe: 4mm-812.80mm |
| Welded Pipe: single slit(Φ8mm-Φ630mm); girth(Φ630mm-Φ3000mm), | |
| Thickness | Seamless Pipe: 0.5mm - 60mm |
| Welded Pipe: single slit(0.5mm-25mm);girth(3mm-45mm) | |
| Length | 5.8-6.1 m or as customers' request |
| Tolerance | Acording to the Standard. |
| Surface | 180G, 320G, 400G Satin / Hairline |
| 400G, 500G, 600G or 800G Mirror finish | |
| Test | UT, ET, HT, RT,ect, and others according to the standard,or as the requests of the customers |
| Certificate | ISO9001-2008,ASME, PED |
| Delivery Time | 7-30 Days, Depends on quantity |
316Ti stainless steel contains a small amount of titanium element based on 316 Austenitic stainless steel, titanium content is typically around 0.5%, and adding the titanium can stabilize the structure of the 316 at temperatures over 800°C. it prevents carbide precipitation at the grain boundaries and protects the metal from corrosion. The main advantage of 316Ti is that it can be held at higher temperatures for a longer period without sensitization (precipitation) occurring.
316Ti stainless steel is a derivate of 316 stainless steel and retains physical and mechanical properties similar to standard grades of 316.
| We can also cut, thread, and groove Stainless Steel 316Ti Tubes to meet your specifications |
SA312 TP316TI Tubing Tolerances
The Stainless Steel 316Ti tubes outer diameter (OD) are according to ASTM A269/A213. Stainless Steel 316Ti Tubing Tolerance specifications are as per below:
| Stainless Steel 316Ti Tube OD | Stainless Steel 316Ti Tube Tolerance |
|---|---|
| 4mm to 35mm | +/- 0.08mm |
| 35mm to 38mm | +/- 0.15mm |
| 38mm to 60mm | +/- 0.20mm |
| 60mm and above | +/- 0.25mm |
AISI 316ti Tube Properties
316Ti Stainless Steel mechanical properties & chemical composition
316TI Stainless Steel Tube Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 316TI | min. | – | – | – | – | – | 16.0 | 2.0-3.0 | 10.0 | – |
| max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 18.0 | 14.0 | 0.1 | ||
Stainless Steel 316TI Tubes Mechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 316TI | 515 | 205 | 35 | 75 | 205 |
Stainless Steel 316TI Tube Physical Properties
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
|---|---|---|---|---|---|---|---|---|---|
| 0-1000C | 0-3150C | 0-5380C | at 1000C | at 5000C | |||||
| 316TI | 8000 | 193 | 15.9 | 16.2 | 17.0 | 14.2 | 18.7 | 500 | 740 |
1.4571 Stainless Steel Equivalent
Equivalent Grades for 316TI Stainless Steel Pipes & Tubes
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 316TI | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
| Types | Out diameter | Sizes | Length |
|---|---|---|---|
| NB Sizes (in stock) | .0035” ~ 8” | 1/8", 1/4", 3/8", 1/2", 5/8", 3/4", 1", 1.25", 1.5", 2", 2.5", 3", 4", 5", 6" | Cut to length |
| Stainless Steel 316Ti Seamless Tube (Custom Sizes) | 6.35 mm OD To 101.6 mm OD | As per requirement | Cut to length |
| Stainless Steel 316Ti Welded Tube (ERW Tube) (in Stock + Custom Sizes) | 6.35 mm OD To 152 mm OD | As per requirement | Cut to length |
