W. Nr. 2.4819 / Alloy C276 Nickel Base Alloy Seamless Pipe Tube with EN 10204-3.1 Certificate
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Hastelloy C276 / UNS N10276 / 2.4819 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Bars | Grade | Hastelloy C276 |
|---|---|---|---|
| Diameter | DN6-DN400 | Length | 6000mm Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Black, Bright |
| Highlight | W. Nr. 2.4819 Seamless Pipe Tube,EN 10204-3.1 Certificate Seamless Pipe Tube,C276 Nickel Base Alloy Seamless Pipe |
||
Product Description
W. Nr. 2.4819 / Alloy C276 Nickel Base Alloy Seamless Pipe Tube with EN 10204-3.1 Certificate
Specification List of Alloy C276 Seamless Tube
| Specifications | ASTM B 622 ASME SB 622 / ASTM B 619 ASME SB 619 |
|---|---|
| Dimensions | ASTM, ASME and API |
| Size | 15″NB TO 150″NB IN |
| Specialized in | Large Diameter Size |
| Schedule | SCH5, SCH10, SCH40, STD, SCH80, SCH160 |
| Type | Seamless / ERW / Welded / Fabricated |
| Form | Round, Hydraulic Etc |
| Length | Single Random, Double Random & Cut Length. |
| End | Plain End, Beveled End, Treaded |
Alloy C276 nickel pipe is made from a nickel-molybdenum-chromium alloy with addition of tungsten having excellent corrosion resistance in a wide range of severe environments. The high molybdenum content makes this alloy especially resistant to pitting and crevice corrosion. The low carbon content minimizes carbide precipitation during welding to maintain corrosion resistance in as-welded structures.
C276 Hastelloy Alloy Pipes Chemical Composition
| Hastelloy C276 | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr |
| Balance | 0.01 max | 15 – 17 | 1.0 max | 0.08 max | 4 – 7 | 0.04 max | 0.03 max | 2.5 max | 14.5 – 16.5 |
Hastelloy Alloy C276 Pipe Mechanical Properties
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | Psi – 1,15,000 , MPa – 790 | 40 % |
Equivalent Grades for C276 Hastelloy Pipe
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | OR | GOST |
| Hastelloy C276 | N10276 | 2.4819 | – | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
Applications of EN 2.4819 / Alloy C276 Pipe
Some typical applications include equipment components in chemical and petrochemical organic chloride processes and processes utilizing halide or acid catalysts. Other industry applications are pulp and paper (digesters and bleach areas), scrubbers and ducting for flue gas desulfurization, pharmaceutical, and food processing equipment.
Alloy C-276 sheet 0.044" thick in the heat-treated condition at 2050 °F, rapid quenched, has an average olsen cup depth of 0.48". C-276 can be successfully fabricated by many methods. The alloy tends to work harden but with the proper care, the alloy is readily hot and cold formed.
- Digesters and bleach plants in the paper industry.
- Components exposed to sour gas.
- Equipment for flue-gas desulphurisation plants.
- Evaporators, heat exchangers, filters and mixers used in sulphuric acid environments.
- Sulphuric acid reactors.
- Organic chloride process equipment.
- Equipment for processes utilising halide or acid catalysts.
Our Products Grade We Can Supply
| Inconel |
Inconel 722, Inconel 725, Inconel X-750, Inconel 625, Inconel 686, Inconel 690, Inconel 702, Inconel 706, Inconel 713C, Inconel 600, Inconel 601, Inconel 602CA, Inconel 617, Inconel 718.
|
| Incoloy | Incoloy 945, Incoloy A-286, Incoloy 901, Incoloy 903, Incoloy 907, Incoloy 909, Incoloy 925, Incoloy 926, Incoloy 330, Incoloy 800, Incoloy 800H, Incoloy 800HT, Incoloy 801, Incoloy 840, Incoloy 20, Incoloy 205, Incoloy 208 |
| Hastelloy | Hastelloy C 276, Hastelloy G, Hastelloy W, Hastelloy X, Hastelloy G-30, Hastelloy G-35, Hastelloy G3, Hastelloy N, Hastelloy S, B-2, Hastelloy B-3, Hastelloy C2000, Hastelloy C22 |
| Haynes | Haynes 75, Haynes 244, Haynes 25, Haynes 263, Haynes 282, Haynes 556, Haynes 188, Haynes 230, Haynes 233, Haynes 242 |
| Monel | Monel 400, Monel K-500, Monel R405, Monel 401, Monel 404, Monel 405. |
| Nimonic | Nimonic 91, Nimonic C263, Nimonic PE11, Nimonic PE16, Nimonic PK33, Nimonic 80A, Nimonic 96, Nimonic 90, Nimonic 901, Nimonic 105, Nimonic 115 |
| Other Nickel | Waspaloy, Multimet N155, Mumetal 80, Rene 41, Kovar, Maraging 250, Maraging 300, Maraging 350, MP159, MP35N, Alloy 46, Alloy 48, Alloy 52, Alloy 42, Alloy 45, Cobalt alloy 6b, Custom 455, Invar 36, Invar 42, Nickel 200, Nickel 201 |
