Alloy 416 Stainless Steel Round Bar / SS416 Stainless Steel Rod Hot Rolled SS Bars
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 321 309S 310S 2205 17-4PH 2507 410 416 420 430 431 440.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 1100 - 1500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Angle Bar / Channel Bar | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 321 309S 310S 2205 17-4PH 2507 410 420 430 431 440.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | Custom As Request |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | Hot Rolled Steel Round Bar,Hot Rolled Stainless Steel Round Bar,SS Steel Round Bar |
||
Product Description
Alloy 416 Stainless Steel Round Bar / SS416 Stainless Steel Rod Hot Rolled SS Bars
| Product Name | ASTM A276 202/304/316/316L Stainless steel rod stainless steel round bar |
| Standard | ASTM A276/A582/A167/A176/A666/A240/A887/A269/A312/A511/A554/A249/A580/A581/A313 |
| 200 Series:201/202/204Cu 300 Series:301/302/303/304/304L/309/309S/310/310S/316/316L/316Ti/317L/321/347 400 Series: 410/416/420/430/430F/430FR/440C/444/446 600 Series: 630/17-5PH,631/17-7PH 900 Series:904L Duplex:S32205/2205,S32750/2507,F55 Others:XM-19,XM-25,AL-6XN |
|
| Finish | Black/Bright/Polished/Satin |
| Shape | Round/Square/Rectangular or Customized |
| Quality Control | Mill Test Certification is supplied with shipment,Third Party Inspection is acceptable. |
| MOQ | 100KG |
| Delivery Time | 5-10 days after the deposit received. |
| Package | Standard Seaway Packing,Wooden case can be also provided. |
| Payment Item | 30% TT deposit+70% TT balance before delivery. |
GENERAL PROPERTIES
Alloy 416 is a martensitic, free-machining, chromium steel alloy that is generally considered to be the first free-machining stainless steel. It has the highest machinability of any stainless steel at about 85% of that of a free-machining carbon steel. Martensitic stainless steels were designed to be hardenable by heat treatment and also corrosion resistant. Although Alloy 416 and other martensitic stainless steels are not as resistant as austenitic or ferritic stainless, it still demonstrates good corrosion and oxidation resistance plus high strength in the hardened and tempered condition. Alloy 416HT is easily machined, is always magnetic, and has low frictional properties that reduce galling and seizing.
Specifications: UNS S41600
Application of 416 Stainless Steel
Alloy 416 is generally used for parts that are extensively machined and require the corrosion resistance of a 13% chromium stainless steel. Applications that generally use Alloy 416 include:
- Electrical motors
- Nuts and bolts
- Pumps
- Valves
- Automatic screw machine parts
- Washing machine components
- Studs
- Gears
Chemical Properties:
| C | Mn | Si | P | S | Cr | |
|---|---|---|---|---|---|---|
| 416 | 0.15 max |
1.25 max |
1.00 max |
0.06 max |
0.15 max |
min: 12.0 max: 14.0 |
Mechanical Properties:
| Tempering Temperature (°C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) |
Elongation (% in 50mm) |
Hardness Brinell (HB) |
Impact Charpy V (J) |
|---|---|---|---|---|---|
| Annealed * | 517 | 276 | 30 | 262 | – |
| Condition T ** | 758 | 586 | 18 | 248-302 | – |
| 204 | 1340 | 1050 | 11 | 388 | 20 |
| 316 | 1350 | 1060 | 12 | 388 | 22 |
| 427 | 1405 | 1110 | 11 | 401 | # |
| 538 | 1000 | 795 | 13 | 321 | # |
| 593 | 840 | 705 | 19 | 248 | 27 |
| 650 | 750 | 575 | 20 | 223 | 38 |
