EN 2.4660 / 347 / 347H Stainless Steel Seamless Pipe OD10 - 600mm SS Pipe Tube with EN 10204-3.1 Certificate
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 347 / 347H / 2.4660 |
| Minimum Order Quantity | 500 kgs |
| Price | 4650-5760 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Pipe | Grade | 347 / 347H / 2.4660 |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Industrial | Packing | Wooden Box Or PP Bag |
| Highlight | OD10 600mm Stainless Steel Pipe,OD10 600mm Stainless Steel Seamless Pipe,347H Stainless Steel Pipe |
||
Product Description
EN 2.4660 / 347 / 347H Stainless Steel Seamless Pipe OD10 - 600mm SS Pipe Tube with EN 10204-3.1 Certificate
|
Standard
|
GB/T14975, GB/T14976, GB13296-91, GB9948 ,ASTM A312, ASTM A213,ASTM A269, ASTM A511,JIS349,DIN17456, ASTM A789, ASTM A790, DIN17456,DIN17458, EN10216-5, JIS3459,GOST 9941-81
|
|
Material Grade
|
304, 304L, 316, 316L, 321, 321H, 310S, 347H,309.317.0cr18N9, 0Cr25Ni20 00Cr19Ni10,08X18H10T,S31803,S31500,S32750
|
|
Outer Diameter
|
6mm to 710mm
|
|
Thickness
|
0.9mm - 40mm
|
|
Size
|
OD (6-710) x (0.9-40) x MAX 13000mm
|
|
Tolerance
|
under the ASTM A312 A269 A213 standard
under the ASTM A312 A269 A213 standard
under the ASTM A312 A269 A213 standard
|
|
Surface
|
POLISH 180 GRIT, 240GRIT, 320GRIT.
|
|
Customized
|
Other Specifications According To Customers' Requirements
|
|
Delivery time
|
up to the order quantity
|
|
Packing
|
Bundled with knitted plastic bag, wooden cases or according to customers' request.
|
|
Application
|
Fluid and gas transport,decoration, construction,medical equipment, aviation,boiler heat-exchanger and other fields
|
Alloy 347 is a stabilized, austenitic, chromium steel containing columbium which allows for the elimination of carbide precipitation, and, consequently, intergranualr corrosion. Alloy 347 is stabilized by the additions of chromium and tantalum and offers higher creep and stress rupture properties than alloy 304 and 304L which may also be used for exposures where sensitization and intergranualr corrosion are of concern. The addition of columbium also allows Alloy 347 to have excellent corrosion resistance, even superior to that of alloy 321. 347H is the higher carbon composition form of Alloy 347 and demonstrates improved high temperature and creep properties.
Stainless Steel Pipe Standard and Grade Specification
| Trade Name |
Grade
|
UNS #
|
Stainless Steel Seamless Pipe
|
|
| 304 |
TP304
|
S30400
|
A312 / SA312
|
A376 / SA376
|
| 304L |
TP304L
|
S30403
|
A312 / SA312
|
----
|
| 304H |
TP304H
|
S30409
|
A312 / SA312
|
A376 / SA376
|
|
|
|
|
|
|
| 316 |
TP316
|
S31600
|
A312 / SA312
|
A376 / SA376
|
| 316L |
TP316L
|
S31603
|
A312 / SA312
|
----
|
| 316H |
TP316H
|
S31609
|
A312 / SA312
|
A376 / SA376
|
|
|
|
|
|
|
| 321 |
T321
|
S32100
|
A312 / SA312
|
A376 / SA376
|
| 321H |
TP321H
|
S32109
|
A312 / SA312
|
A376 / SA376
|
|
|
|
|
|
|
| 347 |
TP347
|
S34700
|
A312 / SA312
|
A376 / SA376
|
| 347H |
TP347H
|
S34709
|
A312 / SA312
|
A376 / SA376
|
|
|
|
|
|
|
| 317L |
TP317L
|
S31703
|
A312 / SA312
|
----
|
Application of AISI347H / 2.4660 Stainless Steel Pipe
Alloy 347 is frequently used for the fabrication of equipment, which must be placed in service under severe corrosive conditions, and is also common to the petroleum refining industries. Applications that consistently used Alloy 347 include:
- High temperature chemical processes
- Heat exchanger tubes
- High temperature steam service
- High pressure steam pipes
- Radiant superheaters
- Boiler tubes
- Heavy duty exhaust systems
- General refinery piping
FAQ
1.Are You Manufacture or Trade Company?
We are manufacture,we have 12 years experience for supply Metal material and products in domestic.
2.Can you supply what is the service?
We can supply the kinds of metal materials and products,and we also can supply other process services.
3.Can you supply the free sample?
We can supply the free sample,but the sample express freight should be by you.
4.What about your the fast lead time if we place order?
It is normal 7-10 days after receive your deposit.
5.Which payment terms can you accept?
We can accept the TT,Western Union now or Negotiation.
