EN 1.7225 Alloy Steel Plate 42CrMo4 Alloy Steel Chemical Composition and Mechanical Data

EN 1.7225 Alloy Steel Plate 42CrMo4 Alloy Steel Chemical Composition and Mechanical Data

Products Specification of  Steel Plate

Regular Thickness of our aisi4140 Steel Plate in stock

Note: Standard size of our plate: 1500*6000mm  2000*8000mm 2200*12000mm .

Our Service for our AISI4140 Allot Steel Plate

• Cutting

We have several cutting machine for customer cutting request. Our cutting thickness from 4mm to 150mm. Cutting tolerance within ±5mm, Cutting width range within 2500mm, cutting length within 10 meters.

Our cutting method is plasma cutting. The cutting edge is very smooth without burr.  We can cutting our plate into any shape as clients request. If you have request on cutting plate. Please free contact with me and send me your drawning of the cutting items.

1.7225 Material, 42CrMo4 Chemical Composition

The following table shows 42CrMo4 material chemical composition.

42CrMo4 (1.7225) Material Mechanical Properties

42CrMo4 steel properties at room temperature in the quenched and tempered condition.

• Yield strength: ≥900 N/mm2 (d≤16mm, t≤8mm)
  • ≥750 N/mm2 (16 < d ≤ 40mm, 8 < t ≤ 20mm)
  • ≥900 N/mm2 (40 < d ≤ 100mm, 20 < t ≤ 60mm)
  • ≥900 N/mm2 (100 < d ≤ 160mm, 60 < t ≤ 100mm)
  • ≥900 N/mm2 (160 < d ≤ 250mm, 100 < t ≤ 160mm)
• Tensile strength: 1100-1300 N/mm2 (d≤16mm, t≤8mm)
  • 1000-1200 N/mm2 (16 < d ≤ 40mm, 8 < t ≤ 20mm)
  • 900-1100 N/mm2 (40 < d ≤ 100mm, 20 < t ≤ 60mm)
  • 850-950 N/mm2 (100 < d ≤ 160mm, 60 < t ≤ 100mm)
  • 750-900 N/mm2 (160 < d ≤ 250mm, 100 < t ≤ 160mm)
• Elongation: ≥ 10% (d≤16mm, t≤8mm)
  • ≥11% (16 < d ≤ 40mm, 8 < t ≤ 20mm)
  • ≥12% (40 < d ≤ 100mm, 20 < t ≤ 60mm)
  • ≥13% (100 < d ≤ 160mm, 60 < t ≤ 100mm)
  • ≥14% (160 < d ≤ 250mm, 100 < t ≤ 160mm)
• Impact strength of longitudinal Charpy-V-notch test: ≥35J (16 < d ≤ 250mm, 8 < t ≤ 160mm)
• 42CrMo4+QT hardness in HRC: ≥53 (after flame or induction hardening)
• 42CrMo4 hardness in HBW: ≤255 (treated to improve shearability); ≤241 (soft annealed)
