631 Bright Annealed Stainless Steel Sheets AISI630 17-7PH Stainless Steel 2B BA Surface
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 631 |
| Minimum Order Quantity | 500 kgs |
| Price | 3300 - 3480 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 631 |
|---|---|---|---|
| Standard | ASTM EN JIS GB | Size | 1219*2438mm |
| Thickness | 0.5 - 3.0mm | Type | Cold Rolled |
| Service | Cutting, Surface Treatment | Application | Auto Exhaust Pipe |
| Packing | Wooden Pallets | ||
| Highlight | Bright Annealed Stainless Steel Sheet,631 Stainless Steel Sheet,AISI630 Stainless Steel Sheet |
||
Product Description
631 Bright Annealed Stainless Steel Sheets AISI630 17-7PH Stainless Steel 2B BA Surface
Products Specification
|
Product Name
|
631 Stainless Steel Sheets
|
|
Material Type
|
Ferrite stainless steel, magnetic; Austenitic stainless steel, Non-magnetic.
|
|
Grade
|
300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347
|
|
200series:201,202,202cu,204
|
|
|
400series:409,409L,410,420,430,431,439,440,441,444
|
|
|
Others:2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc
|
|
|
Duplex stainless steel:S22053,S25073,S22253,S31803,S32205,S32304
|
|
|
Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo
|
|
|
Technology
|
Cold Rolled /Hot Rolled
|
|
Length
|
2000/2438/2500/3000/3048 mm
|
|
Width
|
1000/1219/1250/1500 mm
|
|
Thickness
|
0.4-3mm(cold Rolled), 3-200mm(hot Rolled)
|
|
|
BA, 2B, NO.1,2D, 4K, 6K, 8K, NO.4, HL, SB, Embossed,perforated etc.
|
|
Leveling: improve flatness, esp. for items with high flatness request.
|
|
|
Skin-Pass: improve flatness, higher brightness
|
|
|
Other Choices
|
Cutting:Laser cutting, help the customer to cut the required size
|
|
Protection
|
1. Inter paper available
|
|
2. PVC protecting film available
|
|
|
Price Item
|
FOB,CIF,DDU,FCA,EXW ,.etc
|
|
Quality Assurance
|
1.Provide MTC (Mill Test).
2.Accept the inspection by the third party agent
|
Stainless Grade 17-7 PH ® is a precipitation hardening stainless steel that provides high strength and hardness, excellent fatigue properties, good corrosion resistance, good formability, and minimum distortion upon heat treatment. The alloy provides valuable property combinations particularly well suited for aerospace applications. This special alloy also provides benefits for other applications requiring high strength and good corrosion resistance, as well as excellent properties for flat springs at temperatures up to 600°F (316°C).
631 / 17-7PH Stainless Steel Sheets in Stock
| 631 / 17-7PH Stainless Steel Sheets Thickness | |||||||
| 0.3mm | 0.4mm | 0.5mm | 0.6mm | 0.8mm | 1.0mm | 1.2mm | 1.5mm |
| 2.0mm | 2.5mm | 3.0mm | 4.0mm | 5.0mm | 6.0mm | 8.0mm | 10.0mm |
| 12.0mm | 14.0mm | 16.0mm | 20.0mm | 22.0mm | 25.0mm | 28.0mm | 30.0mm |
Chemical Properties of 631 Stainless Steel Sheets
| TYPE | Cr | Ni | Al | C | Mn | P | S | Si |
|---|---|---|---|---|---|---|---|---|
| 17-7 | min: 16.0 max: 18.0 |
min: 6.75 max: 7.75 |
min: 0.75 max: 1.50 |
0.09 max |
1.00 max |
0.05 max |
0.03 max |
1.00 max |
Mechanical Properties of 17-7PH Stainless Steel
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
|---|---|---|---|---|
| 17-7 | 130 | 40 | 35 | B85 |
Packing Detail Informations
631 Stainless Steel Uses
The 631 stainless steel is widely used in various applications such as aerospace, automotive, chemical processing, and medical devices. It finds applications in producing springs, washers, fasteners, valves, and aircraft fittings. Due to its biocompatibility, the alloy is also used in making surgical instruments and orthopaedic implants.
FAQ
1. How can I get a quotation from you ?
You can leave us message, and we will reply every message in time. Or we may talk on line by Trademanager.
And you can also find our contact information on contact page.
2.Can I get samples before order ?
Yes, of course. Usually our samples are free. we can produce by your samples or technical drawings. We can build the molds and fixtures.
3. what is your delivery time ?
The time of delivery is usually around 1 month(1*40FT as usual).
We can send out in 2 days, if it has stock.
4.What is your payment terms?
Our usual payment term is 30% deposite, and rest against B/L. L/C is also acceptatble.EXW,FOB,CFR,CIF,DDU.
