EN 10204-3.1 Certificated AISI416 Stainless Steel Sheets High Hardness 0.4 - 3.0mm Cold Rolled SS Plate
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 409L 410S 416 420 430 436L 439 441 443 444 |
| Minimum Order Quantity | 500 kgs |
| Price | 1320 - 1500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | 409L 410S 416 420 430 436L 439 441 443 444 |
|---|---|---|---|
| Standard | ASTM EN JIS GB | Size | 1219*2438mm |
| Thickness | 0.4 - 12.0mm | Type | Cold Rolled Hot Rolled |
| Service | Cutting, Surface Treatment | Application | Auto Exhaust Pipe |
| Packing | Wooden Pallets | ||
| Highlight | AISI cold rolled stainless steel sheet,0.4mm cold rolled stainless steel sheet,High Hardness Stainless Steel Sheets |
||
Product Description
EN 10204-3.1 Certificated AISI416 Stainless Steel Sheets High Hardness 0.4 - 3.0mm Cold Rolled SS Plate
Products Specification
| Products Name | 400 Series Stainless Steel Sheet |
| Standard | ASTM EN JIS GB BIS |
| Thickness |
0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm |
| Surface | 2B 2D NO.1 or process other surface as request |
| Standard Size | 1219*2438mm 1000*2000mm |
| Service | Slit Cutting, bending , surface treatment |
| Other Grade | 200 Series: 201 202 |
| 300 Series: 301 304 304L 309S 310S 316L 316Ti 317l 321 329 347 | |
| 400 Series: 409L 410S 416 420 431 436L 439 441 443 444 446 | |
| Special Grade: 254SMO 904L 2205 2507 253MA Nickel Alloy | |
| MOQ | 500 kgs |
| Packing | Wooden Pallets and waterproof paper |
Size Range of our 416 Stainless Steel Sheet & Plate
| Type | Thickness | Standard Size | Service |
| 416 Stainless Steel Sheets | 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm | 1000*2000mm 1219*2438mm | Cutting, surface finishing |
| 416 Stainless Steel Plates | 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm or other thickness as request | 1500*6000mm | Cutting, surface finishing |
416 Stainless Steel Composition
416 stainless steel is an interesting material due to its chemical composition. It contains a higher amount of chromium than Inconel sheet, giving it improved corrosion resistance and strength. This steel also contains sulfur, increasing machinability and reducing cost. The added nickel found in 416 stainless steel decreases works hardening which allows the material to be more stable during welding processes. Overall, 416 stainless steel is a versatile and popular material that can be used in many applications due to its unique chemical composition.
| Grade | C | Mn | Si | P | S | Cr | Mo | |
| 416 |
0.15 |
1.25 |
1.00 |
0.06 |
0.15 |
12.0-14.0 |
0.60 |
|
416 Stainless Steel Mechanical Properties
UNS S41600 is an excellent choice for applications where optimal corrosion and oxidation resistance are desired. This heat-treatable alloy exhibits exceptional mechanical properties such as high tensile strength and impact resistance. Its low carbon content ensures it will remain tough even under high temperatures, while its chromium content helps it to resist rust and oxidation. Furthermore, it has higher machinability compared to other stainless steel alloys, making it easier to work with. In summary, 416 stainless steel has many desirable characteristics that make it an ideal choice for Inconel sheet applications.
| Tempering Temperature (°C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) |
Elongation (% in 50mm) |
Hardness Brinell (HB) |
Impact Charpy V (J) |
| Annealed * | 517 | 275 | 30 | 262 | – |
| Condition T ** | 758 | 586 | 18 | 248-302 | – |
| 204 | 1340 | 1050 | 11 | 388 | 20 |
| 316 | 1350 | 1060 | 12 | 388 | 22 |
| 427 | 1405 | 1110 | 11 | 401 | # |
| 538 | 1000 | 795 | 13 | 321 | # |
| 593 | 840 | 705 | 19 | 248 | 27 |
| 650 | 796 | 670 | 17.5 | 253 | 38 |
416 Stainless Steel Properties
416 SS is part of the 400 series, which contains 11-14% chromium and a small amount (1%) of sulfur or selenium. Chromium adds hardness to the metal, while sulfur improves machinability. This combination results in a metal with good corrosion resistance and welding characteristics.
- 416 stainless steel is martensitic stainless steel with 12-13% chromium.
- It has good machinability but poor weldability due to the high sulfur content.
- It is magnetic in all conditions.
- It is heat treatable and can be hardened by tempering or annealing.
- It has excellent corrosion resistance and is often used in marine applications.
416 Stainless Steel Equivalent
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 416 | S41600 | 416S21 | 56AM | 1.4005 | X12CrS13 | 2380 | SUS 416 |
416 Stainless Steel Uses
Because of its strength and wear resistance, 416 steel Material is used in many industries, such as automotive manufacturing, construction, mining equipment manufacturing, aerospace parts manufacturing, medical device manufacturing, food processing equipment manufacturing, and machine shops. In addition to being used for fabricated parts like blades or screws, this metal is also commonly used for fasteners like nuts and bolts or rivets due to its superior strength. It can also be found in hand tools like wrenches or hammers because its power allows them to withstand heavy use without breaking down over time.
