EN 10204-3.1 Certificated S350GD+Z275 Hot Dipped Galvanized Steel Coil & Sheets
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL WISCO |
| Certification | ISO |
| Model Number | S350GD+Z275 |
| Minimum Order Quantity | 2 Ton |
| Price | 620-860 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Galvanized Steel Coil | Thickness | 0.3 - 3.0mm |
|---|---|---|---|
| Width | 1000mm 1250mm 1500mm Or As Request | Surface | Regular Spangle, Zero Spangle |
| Zinc Coating | Z40 - Z275 | Brand | BAOSTEEL ANSTEEL |
| Service | Cutting | Coil ID | 508mm |
| Highlight | Zinc Steel Coils,Steel Coil Galvanized,Hot Dipped Steel Coil |
||
Product Description
EN 10204-3.1 Certificated S350GD+Z275 Hot Dipped Galvanized Steel Coil & Sheets
Specification of our galvanized steel coil
|
Product Name
|
S350GD+Z275 Galvanized steel coil
|
|
Width
|
1000mm 1250mm 1500 or other width according to customer's requirement
|
|
Thickness
|
0.3 - 3.0mm
|
| Zinc Coating | Z40 Z60 Z80 Z100 Z120 Z150 Z180 Z275 |
|
Standard Size
|
1000*2000mm 1250*2500mm 1500*3000mm
|
|
Surface Structure
|
Normal spangle coating(NS),minimized spangle coating(MS),spangle-free(FS)
|
|
Standard
|
ASTM JIS EN GB
|
|
Type of Coating
|
Hot Dipped Galvanized Steel
|
|
Service
|
Slit Cutting any size as request
|
|
Packing
|
packing on wooden frame
|
About S350GD+Z Galvanized Steel
S350gd is a grade in the European standard “EN 10346-2009 Continuous Hot-Dip Galvanized Steel Sheet Products”, which is a galvanized steel sheet. S350G is structural steel requiring tensile strength greater than 350MPa, D means galvanized sheet, so s350gd is structural galvanized sheet with yield strength greater than 350MPa
The S350G is available in the following hot dip coatings: S350GD+Z (galvanized), S350GD+ZF (galvanized-iron), S350GD+ZA (galvanized-aluminum), S350GD+AZ (aluminum-zinc), S350GD+AS (galvanized-iron) aluminum silicon).
Features of S350GD+Z Galvanized Steel
S350GD galvanized sheet (coil) has the characteristics of strong coating adhesion, strong erosion resistance, precise control of galvanized layer thickness, high dimensional accuracy, flat profile, good mechanical properties, processing performance and welding performance. They can be used to manufacture interior and exterior panels, structural parts and reinforcements for automobiles.
Percent chemical composition of steel S350GD: EN 10346-2009
| C | Si | Mn | P | S |
| max 0.2 | max 0.6 | max 1.7 | max 0.1 | max 0.045 |
Mechanical properties of steel S350GD (1.0529)
| Rm - Tensile strength (MPa) | 420 |
| Rp0.2 0.2% proof strength (MPa) | 350 |
| A - Min. elongation Lo = 80 mm (%) | 16 |
Equivalent grade for steel S350GD (1.0529)
| EU | European old |
| EN | EN |
| S350GD | FeE350G |
S350GD Z275
S350GD Galvanized Steel Coil with Zinc Weight Z275
Application industry
Prefabricated steel buildings, industrial and commercial roofing and cladding, agricultural buildings, building accessories, light steel frames, building pipes
FAQ
Q: Are you trading company or manufacturer ?
A: We are professional manufacturer for many years. we can provide a wide range of steel products.
Q: Will you delivery the goods on time?
A: Yes,we promise to provide best quality products and delivery on time .Honesty is our company's tenet.
Q: Do you provide samples ? is it free or extra ?
A: The sample could can provide for customer with free,but the courier freight will be covered by customer account.
Q: Do you accept the third party inspection?
A: Yes absolutely we accept.
Q: How could you guarantee your products?
A: Each piece of products is manufactured by certified workshops, inspected by Jinbaifeng piece by piece according to
national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
Q: How can I get your quotation as soon as possible?
A: The email and fax will be checked within 24 hours,meanwhile,the Skype,Wechat and WhatsApp
will be online in 24 hours.Please send us your requirement , we will work out a best price soon.
Q: Will you delivery the goods on time?
A: Yes,we promise to provide best quality products and delivery on time .Honesty is our company's tenet.
Q: Do you provide samples ? is it free or extra ?
A: The sample could can provide for customer with free,but the courier freight will be covered by customer account.
Q: Do you accept the third party inspection?
A: Yes absolutely we accept.
Q: How could you guarantee your products?
A: Each piece of products is manufactured by certified workshops, inspected by Jinbaifeng piece by piece according to
national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
Q: How can I get your quotation as soon as possible?
A: The email and fax will be checked within 24 hours,meanwhile,the Skype,Wechat and WhatsApp
will be online in 24 hours.Please send us your requirement , we will work out a best price soon.
