S350GD+Z275 Galvanized Steel Coil Thickness 0.6 - 3.0mm With Regular Spangle
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL WISCO |
| Certification | ISO |
| Model Number | S350GD+Z275 |
| Minimum Order Quantity | 2 Ton |
| Price | 600-860 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Galvanized Steel Coil | Thickness | 0.3 - 3.0mm |
|---|---|---|---|
| Width | 1000mm 1250mm 1500mm Or As Request | Surface | Regular Spangle, Zero Spangle |
| Zinc Coating | Z40 - Z275 | Brand | BAOSTEEL ANSTEEL |
| Service | Cutting | Coil ID | 508mm |
| Highlight | Zinc Steel Coils,Steel Coil Galvanized,Hot Dipped Steel Coil |
||
Product Description
S350GD+Z275 Galvanized Steel Coil Thickness 0.6 - 3.0mm With Regular Spangle
Specification of our galvanized steel coil
|
Product Name
|
S350GD+Z275 Galvanized steel coil
|
|
Width
|
1000mm 1250mm 1500 or other width according to customer's requirement
|
|
Thickness
|
0.3 - 3.0mm
|
| Zinc Coating | Z40 Z60 Z80 Z100 Z120 Z150 Z180 Z275 |
|
Standard Size
|
1000*2000mm 1250*2500mm 1500*3000mm
|
|
Surface Structure
|
Normal spangle coating(NS),minimized spangle coating(MS),spangle-free(FS)
|
|
Standard
|
ASTM JIS EN GB
|
|
Type of Coating
|
Hot Dipped Galvanized Steel
|
|
Service
|
Slit Cutting any size as request
|
|
Packing
|
packing on wooden frame
|
S350GD is a code used to identify hot-dip galvanized steel products that adhere to the EN 10346-2009 European standard. The “S” in the code refers to structural steel, while “350” indicates that the steel’s yield strength is at least 350 MPa. At Wanzhi Steel, we offer an extensive range of continuously hot-dip galvanized steel products, with the highest strength reaching 550MPa. Our range includes S250GD, S320GD, S450GD, S550GD, and more. The sizes range from 0.2 mm-3 mm*600 mm-1500 mm, with zinc coating of 60-275 g/㎡.
Our products are known for their high strength, strong corrosion resistance, and smooth surface finish. They are widely used in various applications such as building materials or structural parts, including roofing, wall panels, ventilation pipes, interior decoration, fencing, steel frames, and more. If you are interested in learning more about our hot-dip galvanized steel products, please feel free to contact us.
What Is S350GD?
S350GD is a code of hot dip galvanized steel, which is a type of structural steel that has a minimum yield strength of 350 MPa. It is often followed by “+Z” or “+AZ” and number, which indicates the thickness of the zinc or aluzinc coating. For instance, S350GD+Z275 refers to galvanized steel that has been coated with a zinc layer weighing 275 g/㎡, while S350GD+AZ150 refers to galvalume steel coated with an aluminum-zinc alloy weighing 1.5 ounces per square foot.
Chemical Composition of Steel S350GD
| C | Si | Mn | P | S |
| ≤0.2% | ≤0.6% | ≤1.7% | ≤0.1% | ≤0.045% |
Mechanical Properties of S350GD+Z275
| Item | S350GD |
| Rm – Tensile Strength | 400 MPa |
| Rp0.2 – 0.2% Yield Strength | 350 MPa |
| A – Min. elongation Lo = 80 mm | 16% |
Below is mechanical properties of S280GD for your reference.
| Item | S350GD |
| Rm – Tensile Strength | 360 MPa |
| Rp0.2 – 0.2% Yield Strength | 280 MPa |
| A – Min. elongation Lo = 80 mm | 18% |
Equivalent Grades
| Europe | USA | Japan | Australia | China |
| EN | ASTM | JIS | AS | GB |
| S350GD | SS Grade 340 | SGC440 | G350 | S350GD |
Difference Between SGCC, SGHC, S350GD, and DX51D
Let’s learn the meaning of the codes first.
SGCC (JIS G3302): S- Steel; G- Galvanized; C- Cold rolled steel; C- for common uses; which is equivalent to DX51D+Z.
SGHC: S- Steel; G- Galvanized; H- Hot rolled steel; C- for common uses;
S350GD: S- Structural steel; 350- yield strength should be at least 350MPa; GD- Galvanized;
DX51D: D- low carbon steel; X – the rolling state of the substrate is not specified; 51 – steel grade for common uses; D- Galvanized.
