Precision Stainless Steel Pipe Grade 316L SS Pipe ASTM A270 A789 Bright Surface
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 316L |
| Minimum Order Quantity | 500 kgs |
| Price | 7100-8200USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Pipe | Grade | Stainless Steel 316L |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Heat Exchanger | Packing | Wooden Box Or PP Bag |
| Highlight | ASTM Stainless Steel Pipe,ASTM Stainless Steel Tube,Stainless Steel Round Pipe |
||
Product Description
Precision Stainless Steel Pipe Grade 316L SS Pipe ASTM A270 A789 Bright Surface
| Products Name | 316L Stainless Steel Pipe |
| Pipe Type | Seamless Pipe . Welded Pipe |
| Surface | Pickling , polishing |
| Out Diameter | 6 - 508mm |
| Wall Thickness | 1.0 - 50.0mm |
| Length | 6m or cutting any length as request |
| Standard | ASTM / GB / EN / DIN / JIS / BS / BIS |
| Mainly Grade | 304 304L 304H 309S 310S 316L 316Ti 317L 321 347 2205 2507 904L 254SMO 800/800H Alloy20 ,Hastelloy Alloy, Monel Alloy,Inconel Alloy |
| Service | Cutting, Polishing, Hairline Finishing |
| MOQ | 200 Kgs |
| Packing | standard packing for export |
| Application | Industrial , food , medical, househould |
Precision stainless steel tubing is hard drawn ,straightened tubing, having highly polished or bright annealed surface. A pickled surface can be delivered on request. Surface roughness ≤ 0.4 μm on both the outside and inside surfaces is guaranteed.
Because its excellent mechanical properties of good corrosion resistance, more prominent cold deformation capacity and non-magnetic, precision stainless steel tubing is widely used in automobile manufacturing, medical industrial, aerospace, food and beverage industrial such as tailpipe,needle tubing and so on.
We offer wide range of precision welded, welded-and-drawn and seamless stainless steel tube and pipe to meet your unique needs: Large diameter stainless steel tube, small diameter stainless steel tube, thin wall stainless steel tube, bright annealed stainless steel tube for precision purpose.
Standards:
- AISI 304/AISI 316
- ASTM A269, Seamless and Welded Austenitic Stainless Steel Tubing for General Service.
- ASTM A270, Seamless and Welded Austenitic and Ferritic/Austenitic Stainless Steel Sanitary Tubing
- JIS 3447, Stainless Steel Sanitary Pipes
- Available grades: 304, 304L, 316, 316L,Duplex S31803
Standard comparation:
| Standards | JIS G3447 | ASTM A270 |
designation of grades | SUS 304TBS | TP304 |
| SUS 304LTBS | TP304L | |
| SUS 316TBS | TP316 | |
| SUS 316LTBS | TP316L |
Welded and seamless Precision tube size:
- O.D: 0.25mm-45mm
- W.T: 0.1-1.5mm
- Length: 6m or made to order
Tolerance:
D1 ±1.5%. min±0.75 mm for common application
D2 ±1.0%. min±0.50 mm for Decorative purpose purpose
D3 ±0.75%. min±0.30 mm for Decorative/industrial purpose
D4 ±0.50%. min±0.10 mm for precision tube/industrial purpose
Our Stainless Steel Precision Pipe Grade:
TP304LTP316L321 3105 904L317L,N02200 N02201N04400N06600N06601N06625 N08800NO8810NO8811
N08825 N08020N8028892678,N06022(C22)N10276(C-276)N10665(B-2)N10675(B-3)C2000C4N06030(G-30)N06035(G-35),GH3030 GH3039 GH3044,S31803 S32205 S31500 S31200 S31260 S32001 S32304 S32750 S32707,S30815253MAS31254254SM0 00Cr14Ni14Si4,S38815 304LN 316Ti,347HFG TP310HCbN316,316LMoD S310501.4466 00Cr25Ni22Mo2(2522),25072205C2761.4435TP317L
