AR500 Wear Plate - Abrasion Resistant Steel Plate Q+T Treatment
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL BENSTEEL HBIS XINGCHENG |
| Certification | ISO |
| Model Number | AR400 AR500 AR600 |
| Minimum Order Quantity | 1000 kgs |
| Price | 870 - 962USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Wear Resistant Steel Plate | Thickness | 10.0 - 40.0mm |
|---|---|---|---|
| Width | 1000-2200mm | Length | 2000-12000mm |
| Standard | ASTM EN GB | Other Grade | AR400 / AR450 / AR500 / AR600 |
| Brand | BAOSTEEL XINYU XINGCHENG HBIS | Service | Cutting |
| Highlight | abrasion resistant steel plate,wear resistant steel plate,wear resistant plate |
||
Product Description
AR500 Wear Plate - Abrasion Resistant Steel Plate Q+T Treatment
Products Specification of Wear Resistant Steel Plate
| Products Name | Abrasion Resistant Steel Plate |
| Thickness | 4.0 - 40.0mm |
| Width | 100 - 2200mm custom cutting any size as request |
| Length | 6m 8m 10m 11.5m 12m or cutting any length as request |
| Standard | ASTM JIS GB EN |
| MOQ | 500 Kgs |
| Deliver time | 7 - 14 days |
| Loading Port | Shanghai Port |
| Packing | wooden pallets |
| Other Grade | AR400 / AR450 / AR500 / AR600 NM400 NM450 NM500 NM600 |
| Service | Cutting, Heat treatment |
Description
A high carbon quenched – quenched and tempered steel with good weldability.
A key feature is the high strength and toughness with a guaranteed hardness - Brinell level.
This material has good formability.
This grade of steel plate has a nominal hardness of 500 HBW.
Chemical Composition of AR500
| Ni | Cr | Mo | Si | Mn | Cu | C | S | P | CEV* | |
|---|---|---|---|---|---|---|---|---|---|---|
| Min | ||||||||||
| Max | 1.5 | 0.8 | 1.7 | 0.23 | 0.015 | 0.025 | 0.45 |
(*differs with section thickness and grade variation)
ADVANTAGES OF ABRASION RESISTANT STEEL PLATES
One of the main advantages of abrasion-resistant steel plates is their ability to withstand wear and tear. That means they can last longer than regular steel plates, thus reducing the need for frequent replacements. Moreover, abrasion-resistant steel plates are also more corrosion-resistant, making them ideal for harsh environments.
Another advantage of abrasion-resistant steel plates is their cost-effectiveness. While the initial cost of the plates may be higher than regular steel plates, their long life span and durability make them a more cost-effective choice in the long run.
Typical Applications
- Yellow goods
- Mining
- Agriculture
- General engineering
- Mechanical handling
- Structural applications
Why Choose Us :
- You can get the perfect material according to your requirement at the least possible price.
- We also offer Reworks, FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.
- The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement.(Reports will show on requirement)
- e guarantee to give a response within 24hours(usually in the same hour)
- You can get stock alternatives, mill deliveries with minimizing manufacturing time.
- We are fully dedicated to our customers. If it will not possible to meet your requirements after examining all options, we will not mislead you by making false promises which will create good customer relations
