GB/T 24186 Standard NM500 Wear Resistant Steel Plate HB500 Harded Steel Plate
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL BENSTEEL HBIS XINGCHENG |
| Certification | ISO |
| Model Number | AR500 /NM500 / Hardox500 |
| Minimum Order Quantity | 1000 kgs |
| Price | 800 - 942USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Wear Resistant Steel Plate | Thickness | 4.0 - 40.0mm |
|---|---|---|---|
| Width | 1000-2200mm | Length | 2000-12000mm |
| Standard | ASTM EN GB | Other Grade | AR400 / AR450 / AR500 / AR600 |
| Brand | BAOSTEEL XINYU XINGCHENG HBIS | Service | Cutting |
| Highlight | abrasion resistant steel plate,wear resistant steel plate,wear resistant plate |
||
Product Description
GB/T 24186 Standard NM500 Wear Resistant Steel Plate HB500 Harded Steel Plate
Products Specification of Wear Resistant Steel Plate
| Products Name | Abrasion Resistant Steel Plate |
| Thickness | 4.0 - 40.0mm |
| Width | 100 - 2200mm custom cutting any size as request |
| Length | 6m 8m 10m 11.5m 12m or cutting any length as request |
| Standard | ASTM JIS GB EN |
| MOQ | 500 Kgs |
| Deliver time | 7 - 14 days |
| Loading Port | Shanghai Port |
| Packing | wooden pallets |
| Other Grade | AR400 / AR450 / AR500 / AR600 NM400 NM450 NM500 NM600 |
| Service | Cutting, Heat treatment |
NM500 Wear Resistant Steel Plate
Application
Wear resistant (abrasion resistant) steel plate is strong steel materials for wear resistant, widely used in the bad working conditions, demanded of high strength, high-wear-resisting performance in engineeing, mining, construction, agriculture, port and metallurgical machinery products. Therefore, solving wear and prolong the used life of mechanical equipment and components becomes the first consideration in the desiging, manufacturing and using. Loading machines, dredgers, skip cars, conveying plants, dump trucks, cutting edges, knives, breakers, crushers, sieves, feeders, measuring pockets, journals, buckets, gears, sprockets, loaders industrial trucks, lorries, bulldozers, excavators, slurry pipe systems, screw conveyors, presses, etc.
Quality Standard
DIN EN ISO 6506 EN ISO6892 EN 10045
Chemical Composition(%)
| Steel Grade | C | Si | Mn | P | S | Cr | Ni | Mo | B |
| NM360 | 0.17 max | 0.50 max | 1.50 max | 0.025 max | 0.015 max | 0.70 max | 0.50 max | 0.40 max | 0.005 max |
| NM400 | 0.24 max | 0.50 max | 1.60 max | 0.025 max | 0.015 max | 0.40-0.80 | 0.20-0.50 | 0.20-0.50 | 0.005 max |
| NM450 | 0.26 max | 0.70 max | 1.60 max | 0.025 max | 0.015 max | 1.50 max | 1.00 max | 0.50 max | 0.004 max |
| NM500 | 0.38 max | 0.70 max | 1.70 max | 0.020 max | 0.010 max | 1.20 max | 1.00 max | 0.65 max | 0.005-0.006 |
Delivery condition
Q+T(Quenched and Tempered)
Mechanical Properties
| Steel Grade | Y.S (MPa) | T.S (MPa) | Elongation A5(%) | Impact Test | Hardness | |
| min | min | min | (°C) | AKV J(min) | HBW | |
| NM360 | 800 | 1000 | 10 | -20 | 30 | 320-400 |
| NM400 | 1000 | 1250 | 10 | -20 | 30 | 360-440 |
| NM450 | 1250 | 1500 | 10 | -20 | 30 | 410-490 |
| NM500 | 1300 | 1700 | 10 | -20 | 30 | 450-540 |
Capacity: 3,000 ton per month.
How to use NM500 STEEL PLATE?
It is used for excavator, loader, bulldozer bucket board, blade plate, side blade plate, blade and crusher liner, and so on. NM500 Steel Plates, NM500 Wear/ Abrasion Resistant Steel Plate Manufacturer in China, NM500 Abrasion Resistant Steel Plate, High Strength Wear Resistant Alloy Steel Plate NM500 Stockist, NM500 Plates Manufacturer. Wear Resistant Steel Plate NM500, NM500 Steel Plate in Shanghai, Grade NM500 Plates, T107 ASTM Steel Plate, NM500 Hot Rolled Structural Steel Plate, NM500 Plates Manufacturer, NM500 Steel Plate, JIS G4051 GB711 YB Steel Plates Stockists, NM500 Structural High Tensile Steel Plates, NM500 Hard Wear Resistant Steel Plates Exporters. NM500 Wear-resistant steel plate, NM500, is an abrasion resistant plate with a hardness of 500 HBW, supposed for purposes where calls for are imposed on abrasion resistance together with excellent cold bending properties.
