High Hardness AR450 Abrasion Resistant Steel Plate Hardox 450 / AR450F Steel Plate
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL BENSTEEL HBIS XINGCHENG |
| Certification | ISO |
| Model Number | AR450 |
| Minimum Order Quantity | 500 kgs |
| Price | 816 - 948 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Wear Resistant Steel Plate | Thickness | 4.0 - 40.0mm |
|---|---|---|---|
| Width | 1000-2200mm | Length | 2000-12000mm |
| Standard | ASTM EN GB | Other Grade | AR400 / AR450 / AR500 / AR600 |
| Brand | BAOSTEEL XINYU XINGCHENG HBIS | Service | Cutting |
| Highlight | abrasion resistant steel plate,wear resistant steel plate,wear resistant plate |
||
Product Description
High Hardness AR450 Abrasion Resistant Steel Plate Hardox 450 / AR450F Steel Plate
Products Specification of Wear Resistant Steel Plate
| Products Name | Abrasion Resistant AR450 Steel Plate |
| Thickness | 4.0 - 40.0mm |
| Width | 100 - 2200mm custom cutting any size as request |
| Length | 6m 8m 10m 11.5m 12m or cutting any length as request |
| Standard | ASTM JIS GB EN |
| MOQ | 500 Kgs |
| Deliver time | 7 - 14 days |
| Loading Port | Shanghai Port |
| Packing | wooden pallets |
| Other Grade | AR400 / AR450 / AR500 / AR600 NM400 NM450 NM500 NM600 |
| Service | Cutting, Heat treatment |
AR450 Wear Plate
Wear plates are usually resistant to wear and abrasion that might occur over a period of time due to various factors. They are categorized into various grades. AR450 Wear Plate is one such grade that reduces the industrial wear in applications that may be caused due to rubbing, scraping, or erosion. The reduction of wear by AR450 Steel Plate leads to an increase in production time and reduction in downtime and maintenance cost. Ar450 Material consists of carbon and boron this unique composition provides it more surface hardness thereby maintaining good ductility, impact resistance, and formability. It has a high tensile and yield strength with a Brinell Hardness that is greater than 400 grade.
AR450 Wear Plate showcases minimal resistance to corrosion and excellent bending. However, machining or grinding of these plates is not recommended. Though the Ar450 Steel Price depends upon the thickness of the plate. When compared to the 400 grade the AR450 plate price is said to be exorbitant. One of the worlds leading abrasion resistant steel is the Hardox® 450 Plate. It is hard till the core. It wears slowly even under heavy mechanical load. It also provides higher resistance against chipping. They are widely used in grapples, garbage trucks, liner plates, prismatic knives, granulator knives, sieves, and hammer mills. Moreover, these ABREX 450 Steel Plates are also used in containers and conveyor belts.
Ar450 Steel Plate Equivalent can be used for the fragmentation of waste, rubber, cables, tires, and plastic. Shredders made using these plates offer higher resistance against cracking and cleavage. 450HB Steel Plates are passed through various tests to confirm the properties that it has inherited. Rockstar 450 Plate has good formability with the minimum effect of the hardness of the product. They are used in the mining and construction market. They also have a good surface finish. Xar 450 Steel on the other hand have good processability and can be cut as per the specific requirement of the customer. The molten steel is deoxidized before the production of these plates.
AR450 Wear Resistant Steel Plate Availability
Typical plate widths are 2 m and 3 m but we also have a number of narrower plates and also at the 2.5 m level. Plate lengths are typically at 12 m for the thinner plates and this shortens as plate thickness increases. There is a wide range of plate sizes and choices allowing us to fulfill most RFQ directly from stock.
Typical CEV Values At 25 Mm Are 0.46 Rising To 0.64 At 120 Mm
[CEV = C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15]
AR450 Steel Plates Stockist, Check specification & Thickness of ABREX 450 Steel Plate
For 20 Mm Thick AR450 Abrasion Resistant Plate Typical Values Are:
- Tensile strength – 1200 MPa (175 ksi)
- Yield point – 800 MPa (116 ksi)
- Elongation – 12 % (lo = 5.65√So)
Chemical Properties Of AR450 Wear Resistant Steel Plates
| Plate | C | Si | Mn | P | S | Cr | Ni | Mo | B | CEV | CET |
| thickness mm | max % | max % | max % | max % | max % | max % | max % | max % | max % | typv | typv |
| 3-(8) | 0.19 | 0.7 | 1.6 | 0.025 | 0.01 | 0.25 | 0.25 | 0.25 | 0.004 | 0.41 | 0.30 |
| 8-20 | 0.21 | 0.7 | 1.6 | 0.025 | 0.01 | 0.50 | 0.25 | 0.25 | 0.004 | 0.47 | 0.34 |
| (20)-40 | 0.23 | 0.7 | 1.6 | 0.025 | 0.01 | 1.00 | 0.25 | 0.25 | 0.004 | 0.57 | 0.37 |
| (40)-50 | 0.23 | 0.7 | 1.6 | 0.025 | 0.01 | 1.40 | 0.25 | 0.60 | 0.004 | 0.59 | 0.36 |
| (50)-80 | 0.26 | 0.7 | 1.6 | 0.025 | 0.01 | 1.40 | 1.00 | 0.60 | 0.004 | 0.72 | 0.41 |
Mechanical Properties Of AR450 Wear Resistant Steel Plates
| Grade | Mechanical Property | Charpy V Impact Test | |||
| 450HB | Yield | Tensile | Elongation | Degree | longitudinal |
| Min Mpa | Mpa | Min % | -40 | J | |
| 1200 | 1400 | 10 | 40 | ||
