Wear Resistant AR400 / NM400 / Hardox 400 Steel Plate Thickness 4.0 - 40.0mm
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL BENSTEEL HBIS XINGCHENG |
| Certification | ISO |
| Model Number | AR400 / Hardox 400 / NM400 |
| Minimum Order Quantity | 500 kgs |
| Price | 800 - 950 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Wear Resistant Steel Plate | Thickness | 4.0 - 40.0mm |
|---|---|---|---|
| Width | 1000-2200mm | Length | 2000-12000mm |
| Standard | ASTM EN GB | Other Grade | AR400 / AR450 / AR500 / AR600 |
| Brand | BAOSTEEL XINYU XINGCHENG HBIS | Service | Cutting |
| Highlight | abrasion resistant steel plate,wear resistant steel plate,wear resistant plate |
||
Product Description
Wear Resistant AR400 / NM400 / Hardox 400 Steel Plate Thickness 4.0 - 40.0mm
Products Specification of Wear Resistant Steel Plate
| Products Name | AR400 / NM400 Steel Plate |
| Thickness | 4.0 - 40.0mm |
| Width | 100 - 2200mm custom cutting any size as request |
| Length | 6m 8m 10m 11.5m 12m or cutting any length as request |
| Standard | ASTM JIS GB EN |
| MOQ | 500 Kgs |
| Deliver time | 7 - 14 days |
| Loading Port | Shanghai Port |
| Packing | wooden pallets |
| Other Grade | AR400 / AR450 / AR500 / AR600 NM400 NM450 NM500 NM600 |
| Service | Cutting, Heat treatment |
What is AR400 Steel?
AR400 is specifically designed for abrasion and wear-resistant applications. AR400 has a typical hardness range of 360-444 BHN, which is slightly lower than AR450. As with other abrasion-resistant steels, it does not have defined chemistry, but rather, the grade is determined based on hardness.
AR400 Steel Plate Sizes
- .125"-.315 offered in 48"-65" wide cut to your requested length
- .375”-2.00” offered in standard sizes (96" X 240"/288”)
Properties of AR400 Steel Plate
In addition to its general characteristics of being formable, while maintaining good abrasion resistance, AR400 steel also has the following mechanical properties:
- Machining = Fair
- Bending = Good
- Corrosion Resistance = Good
- Welding = Excellent
- Wear Resistance = Great
- Excellent resistance to both impact and sliding abrasion at a moderate cost.
- Recommended for: liners for mining and material handling equipment like dump trucks, material transfer chutes, storage bins, buckets, and hopper
Benefits of AR400 Steel Plate
When zeroing in on what abrasion resistant steel is best for your applications, it’s important to note that each grade reacts differently to many fabricating processes. AR400 steel plate is excellent for applications in which abrasion resistance is required, but formability and weldability are a must. Because of these properties, it can be used for a variety of different applications. It is particularly good in applications where there may be impact or sliding abrasion.
Industries and Applications
Because of its unique properties, AR400 has applications in a variety of different industries and for all types of general uses. It is often used in:
- Mining
- Material Handling Equipment
- Dump Truck Liners
- Material Transfer Chute Liners
- Storage Bin Liners
- Bucket Liners
- Hoppers
- Aggregate
A QUENCHED & TEMPERED PRODUCT FOR APPLICATIONS REQUIRING ABRASION RESISTANCE, FORMABILITY AND WELDABILITY
| Weldability | Carbon equivalent of 0.79 Max - 0.72 Typical | ||
| Mechanical Properties (ASTM A370) | Hardness | 363-400 BH | (ASTM E10) |
| Yield Strength (Typical) | 172 Ksi | 1187 MPa | |
| Tensile Strength (Typical) | 191 Ksi | 1318 MPa | |
| Elongation 2" (Typical) | 10% (in 2") | 10% (in 50mm) | |
| Charpy V-Notch Impact (ASTM A673, A370) Bend Test |
Standard size, 17 foot pounds (23 joules) @ - 40deg C/F test temp, transverse direction hardness 363BHN. | ||
| 4T (up to .50inches - 12.5mm | |||
| Flatness | Standards are 50% of that specified in ASTM A-6. Special tolerances are available. | ||
| Thickness | The standards are 50% of that specified in ASTM A-6. Special tolerances are available. | ||
