AISI439 Stainless Steel Sheet Cold Rolled 2D Surface 0.5 - 3.0mm for Exhaust Pipe
| Place of Origin | China |
|---|---|
| Brand Name | TISCO |
| Certification | ISO |
| Model Number | 439 |
| Minimum Order Quantity | 500 kgs |
| Price | 1400-1600USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet | Grade | Stainless Steel 439 |
|---|---|---|---|
| Standard | ASTM EN JIS GB | Size | 1219*2438mm |
| Thickness | 0.5 - 3.0mm | Type | Cold Rolled |
| Service | Cutting, Surface Treatment | Application | Auto Exhaust Pipe |
| Packing | Wooden Pallets | ||
| Highlight | cold rolled stainless steel sheet,stainless steel cold rolled sheet,cold rolled steel sheet |
||
Product Description
AISI439 Stainless Steel Sheet Cold Rolled 2D Surface 0.5 - 3.0mm for Exhaust Pipe
Products Specification
| Products Name | 439 Stainless Steel Sheet |
| Standard | ASTM EN JIS GB BIS |
| Thickness | 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm |
| Surface | 2B 2D or process other surface as request |
| Standard Size | 1219*2438mm 1000*2000mm |
| Service | Slit Cutting, bending , surface treatment |
| Other Grade | 200 Series: 201 202 |
| 300 Series: 301 304 304L 309S 310S 316L 316Ti 317l 321 329 347 | |
| 400 Series: 409L 410S 416 420 431 436L 439 441 443 444 446 | |
| Special Grade: 254SMO 904L 2205 2507 253MA Nickel Alloy | |
| MOQ | 500 kgs |
| Packing | Wooden Pallets and waterproof paper |
GENERAL INFO ABOUT 439
439 stainless steel sheet is a ferritic stainless steel that is titanium stabilized. It shows excellent resistance in fresh water and boiling acids. It is a common choice for automotive exhaust systems, heat exchangers, kitchen equipment, and architectural structures.
Advantages/Disadvantages of 439 Stainless Steel
This stainless steel grade provides excellent protection against fresh water and boiling acids at relatively high temperatures. It can resist both oxidizing environments and stress corrosion cracking. Its titanium stabilizer leads to improved welding capability and it can be work hardened to increase tensile strength. One of the disadvantages of this stainless steel grade is that it is not heat treatable.
PRODUCT FORMS:
Sheet, Strip
SPECIFICATIONS:
ASTM A240
TYPICAL APPLICATIONS:
Type 439 Stainless Steel is attractive for numerous automotive exhaust applications. Typical uses include tubular manifolds and other exhaust system components where temperatures may exceed the oxidation limit of Type 409, or where wet corrosion resistance, particularly to chlorides, is needed.
CHEMICAL COMPOSITION:
| Element | Type 439 |
|---|---|
| Carbon | 0.030 max. |
| Manganese | 1.00 max. |
| Sulfur | 0.030 max. |
| Phosphorus | 0.040 max. |
| Silicon | 1.00 max. |
| Chromium | 17.0 – 19.0 |
| Nickel | 0.50 max. |
| Nitrogen | 0.030 max. |
| Aluminum | 0.15 max. |
| Titanium | [0.20+4x(C+N)] min. – 0.75 max. |
MECHANICAL PROPERTIES:
| Type | Yield Strength 0.2% offset (KSI) | Tensile Strength (KSI) | % Elongation (2″ Gauge length) |
|---|---|---|---|
| 439 Ann | 30 min. | 60 min. | 22 min. |
PHYSICAL PROPERTIES:
| Density (lb./ in^2) @ RT | 0.278 | |
|---|---|---|
| Modulus of Elasticity in Tension (psi x 10^6) | 29.0 | |
| Specific Heat (BTU/o F/lb.) | 32 to 212 oF | 0.11 |
| Thermal Conductivity (BTU/hr/ft^2/ft) | 212oF | 168.0 |
| Mean Coefficient of Thermal Expansion (in. x 10^-6 per o F) | 32 to 212oF | 5.6 |
| 32 to 932oF | 6.4 | |
| 32 to 1,472oF | 6.9 | |
| Electrical Resistivity (micro ohms – cm) | at 70oF | 63 |
| Oxidation Resistance – Continuous Service(oF) | 1700 |
