ASTM SA790 Duplex 32750 (2507) Stainless Steel Seamless Pipe / Welded Pipe
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | S32750 |
| Minimum Order Quantity | 500 kgs |
| Price | 7000-8000USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Pipe | Grade | Stainless Steel 2507 |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Heat Exchanger | Packing | Wooden Box Or PP Bag |
| Highlight | ASTM Stainless Steel Pipe,ASTM Stainless Steel Tube,Stainless Steel Round Pipe |
||
Product Description
ASTM SA790 Duplex 32750 (2507) Stainless Steel Seamless Pipe / Welded Pipe
| Products Name | S32750 / 2507 Stainless Steel Pipe |
| Pipe Type | Seamless Pipe . Welded Pipe |
| Surface | Pickling , polishing |
| Out Diameter | 6 - 508mm |
| Wall Thickness | 1.0 - 50.0mm |
| Length | 6m or cutting any length as request |
| Standard | ASTM / GB / EN / DIN / JIS / BS / BIS |
| Mainly Grade | 304 304L 304H 309S 310S 316L 316Ti 317L 321 347 2205 2507 904L 254SMO 800/800H Alloy20 ,Hastelloy Alloy, Monel Alloy,Inconel Alloy |
| Service | Cutting, Polishing, Hairline Finishing |
| MOQ | 200 Kgs |
| Packing | standard packing for export |
| Application | Industrial , food , medical, househould |
Alloy 2507, is referred to as a super duplex stainless steel alloy for several reasons. First, the chemistry of the ASTM A790 UNS S32750 Seamless Pipe is designed to withstand highly corrosive environments, in particular those environments which are susceptible to getting decayed by either pitting or by crevice corrosion. Second, due to its mixed microstructure phase, the A790 uns s32750 seamless pipe has properties reminiscent of both austenitic as well as ferritic classes of stainless steel, making this variety a much stronger and better class of steels.
More Detail Specification of SA790 S32750 Seamless / Welded Pipe
| Specification | ASTM A790 and ASME SA790 |
|---|---|
| Standard | ASTM, AISI, EN, GB, DIN, JIS, ASME |
| Outer Diameter | 6.00MM Outer Diameter upto 250MM Outer Diameter, Sizes upto 12Inch NB |
| ASTM A790 S32750 Welded Pipe size | 5.0 MM To 1219.2 MM |
| ASME SA790 UNS S32750 EFW Pipe size | 5.0 To 1219.2 MM |
| Thickness | 0.3 To 50 MM |
| SA790 S32750 Seamless Pipe Sizes | 3.35MM Outer Diameter - 101. MM Outer Diameter, 15NB to 150NB Inch |
| ASTM A790 UNS S32750 Welded Pipe Sizes | 6.35MM Outer Diameter To 152MM Outer Diameter Pipe |
| Swg and Bwg | 10, 12, 14, 16, 18, 20 Swg. |
| ASTM A790 S32750 Pipe wall thickness | 0.020" –0.220 Inch (special wall thicknesses available) |
| ASTM A790 UNS S32750 Pipe Schedule | 5, 10, 40, 80, 80S, 160, XXS, XS |
| Finish | NO.1, Polished, 2B, Annealed and Pickled, Bright and Annealed, MF, NO.4, BA, HL, 8K, Mirror finish etc |
| Form | U Shape, Round, Square, Hollow, Hydraulic, Coiled, Straight Pipes, Rectangular, Pan Cake Coils etc. |
| Length | Double Random, Single Random, Standard and Cut length |
| End | Plain End, Beveled End, Treaded Pipe |
| Type | Seamless, ERW, EFW, Welded, Fabricated, CDW, DOM and CEW Pipe |
| Marking | All A790 UNS S32750 Pipes are marked as follows: Supplier and Manufacturer’s Name, Grade, Standard, OD, Thickness, Length, Heat No and Supplier / Manufacturer’s Name |
| Supplier provide Value Added Service | Draw and Expansion as per required Size and Length, Polish are Electro and Commercial or Annealed and Pickled Bending, Machining Etc. |
SA 790 UNS S32750 Round Pipe Chemical Compostion
| C | N | P | Si | Mn | Mo | Ni | Cr | S | Other |
| 0.030 | 0.24/0.32 | 0.035 | 0.80 | 1.20 | 3.0/5.0 | 6.00/8.00 | 24.0/26.0 | 0.020 | Cu:0.50 |
ASME SA 790 UNS S32750 Pipe Mechanical properties
| Density | Melting point | Yield strength | Tensile trength | Elongation |
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi - 80000 , MPa - 550 | Psi - 116000 , MPa - 800 | 15 % |
SA790 S32750 welded Pipe Application
- Off-Shore Oil Drilling Companies
- Power Generation
- Structural and mechanical components
- Petrochemicals
- Gas Processing
- Condensers
- Sea Water Equipment
- Heat exchangers
- Pharmaceutical Equipment
- Chemical Equipment
- Cooling pipes
