EN 2.4660 Alloy 20 Seamless Nickel Alloy Pipe Tube DN8 - DN400 With EN 10204-3.1 Certificate
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Alloy 20 (UNS N08020) 2.4660 |
| Minimum Order Quantity | 500 kgs |
| Price | 4400-5600 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | N08020 Stainless Steel Pipe | Grade | Alloy 20 (UNS N08020) 2.4660 |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Heat Exchanger | Packing | Wooden Box Or PP Bag |
| Highlight | Stainless Steel Round Tubing,Ss Round Tube,Ss Round Pipe |
||
Product Description
EN 2.4660 Alloy 20 Seamless Nickel Alloy Pipe Tube DN8 - DN400 With EN 10204-3.1 Certificate
| Products Name | Alloy 20 Stainless Steel Pipe |
| Pipe Type | Seamless Pipe . Welded Pipe |
| Surface | Pickling , polishing |
| Out Diameter | 6 - 508mm |
| Wall Thickness | 1.0 - 50.0mm |
| Length | 6m or cutting any length as request |
| Standard | ASTM / GB / EN / DIN / JIS / BS / BIS |
| Mainly Grade | 304 304L 304H 309S 310S 316L 316Ti 317L 321 347 2205 2507 904L 254SMO 800/800H Alloy20 ,Hastelloy Alloy, Monel Alloy,Inconel Alloy |
| Service | Cutting, Polishing, Hairline Finishing |
| MOQ | 200 Kgs |
| Packing | standard packing for export |
| Application | Industrial , food , medical, househould |
Alloy 20 contains niobium for stabilization which enhances its corrosion resistance. The alloy is an iron-base, austenitic alloy with excellent corrosion resistance to a wide range of media.
With the high nickel content, Alloy 20 shows good resistance to chloride-induced stress corrosion cracking. In addition the alloy also has good resistance to pitting and crevice corrosion.
In the chemical process market, key applications of Alloy 20 are in sulphuric, phosphoric and nitric acid environments.
The alloy is also commonly used in the food industry for the manufacture of food preservatives (phosphorus oxychloride and phosphorus trichloride).
Features of Alloy 20
- • Excellent basic corrosion resistance to sulfuric acid
- • Excellent protection to chloride stress rust cracking
- • Excellent mechanical qualities and fabricability
- • Minimal carbide precipitation for the duration of welding
- • Excels in resisting corrosion to very hot sulfuric acids
Alloy 20 Pipe sizes
Alloy 20 Seamless Pipe
- Size: 4 - 406mm
- Thickness : 0.5 - 50mm
- Length: Single, Double Random & Cut Length
Incoloy Alloy 20 Welded Pipe
- Size: 5.0 - 1219.2 mm
- Thickness : 0.5 - 20mm
- Length: Single, Double Random & Cut Length
ASME SB729 Alloy 20 Pipe Mechanical Properties
| Density | Melting Range | Yield Stress (0.2%Offset) | Tensile Stress | Elongation |
| 8.1 g/cm3 | 1443 °C (2430 °F) | Psi - 35000 , MPa - 241 | Psi - 80000 , MPa - 551 | 30 % |
Alloy 20 EN 2.4660 Pipe Chemical Composition
| Ni | C | Mo | Mn | Si | Fe | Cu | S | P | Cr |
| 32 - 38 | 0.02 max | 2 - 3 | 1 - 2 | 0.7 max | Bal | 3 - 4 | 0.005 max | 0.02 max | 19 - 21 |
Alloy 20 Equivalent
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Alloy 20 | N08020 | 2.4660 | Z2NCUD31-20AZ | NiCr20CuMo | - | - | - |
Alloy 20 can be used in a variety of applications including:
- Sulphuric acid pickling tanks, racks and heating coils
- Phosphate coating drums and racks
- Heat exchangers
- Process piping
- Tanks
- Pumps and valves
- Gaskets
- Mechanical seals
- Process equipment for manufacture of bullet-proof fibre, Kevlar
