Alloy 20 Nickel Alloy Seamless Pipe / UNS N08020 Stainless Steel Pipe Tube for Chemical Industrial
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Alloy 20 |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-5000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | N08020 Stainless Steel Pipe | Grade | Alloy 20 |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Heat Exchanger | Packing | Wooden Box Or PP Bag |
| Highlight | Stainless Steel Round Tubing,Ss Round Tube,Ss Round Pipe |
||
Product Description
Alloy 20 Nickel Alloy Seamless Pipe / UNS N08020 Stainless Steel Pipe Tube for Chemical Industrial
| Products Name | Alloy 20 Stainless Steel Pipe |
| Pipe Type | Seamless Pipe . Welded Pipe |
| Surface | Pickling , polishing |
| Out Diameter | 6 - 508mm |
| Wall Thickness | 1.0 - 50.0mm |
| Length | 6m or cutting any length as request |
| Standard | ASTM / GB / EN / DIN / JIS / BS / BIS |
| Mainly Grade | 304 304L 304H 309S 310S 316L 316Ti 317L 321 347 2205 2507 904L 254SMO 800/800H Alloy20 ,Hastelloy Alloy, Monel Alloy,Inconel Alloy |
| Service | Cutting, Polishing, Hairline Finishing |
| MOQ | 200 Kgs |
| Packing | standard packing for export |
| Application | Industrial , food , medical, househould |
About Alloy 20 Pipes, Alloy 20 Seamless Pipe
Alloy 20 Pipes is the chromium, iron-based, and nickel iron-based austenitic material. Alloy 20 Pipes is developed and manufactured for encouraging the resistance to acid attack predominantly sulfuric acid. This Alloy 20 Round Pipe is having very good general corrosion resistance ability and durability. Also, it is having the resistance ability to crevice corrosion and fitting into the chemical-containing atmosphere around industries. Alloy 20 Seamless Pipe effectively resists phosphoric acid and nitric acid and, many more other acids. Also, ASTM B729 Alloy 20 Seamless Pipes is containing niobium for stabilization against sensitization. Alloy 20 Pipes are available in different shapes and sizes and quantities as per their demand.
Alloy 20 Pipes Chemical Composition
| Alloy 20 | Ni | C | Mo | Mn | Si | Fe | Cu | S | P | Cr |
| 32 – 38 | 0.02 max | 2 – 3 | 1 – 2 | 0.7 max | Bal | 3 – 4 | 0.005 max | 0.02 max | 19 – 21 |
Alloy 20 Pipe Mechanical Properties
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.1 g/cm3 | 1443 °C (2430 °F) | Psi – 35000, MPa – 241 | Psi – 80000, MPa – 551 | 30 % |
Equivalent Grades for 20 Alloy Pipe
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN |
| Alloy 20 | N08020 | 2.4660 | Z2NCUD31-20AZ | NiCr20CuMo |
Alloy 20 Pipe Application and Uses
- Alloy 20 Pipe Uses in Textile machinery
- Alloy 20 Pipe Uses in the Oil and gas industry
- Alloy 20 Pipe Uses in Medical Gas Pipeline Systems
- Alloy 20 Pipe Uses in Pharmaceutical processing industry
- Alloy 20 Pipe Uses in Fluid piping.
- Alloy 20 Pipe Uses in Modern architecture.
- Alloy 20 Pipe Uses in Water waste projects
Alloy 20 Pipe Additional Information
- Alloy 20 Pipe Payment Modes: 30% TT in advance, 70% TT balance against copy of B/L
- Alloy 20 Pipe Packaging: Alloy 20 Pipe are packaged with caution and ety so they reach our client’s as good as they would expect. Packaging Charges Extra.
- Alloy 20 Pipe Port of Dispatch: Shanghai Port,China
