TP310S Stainless Steel Pipe ASTM A312 Seamless Stainless Steel Tube for Boiler
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 304L 316L 316LN 316Ti 317L 321 310S 309S 347 2205 2507 904L 254SMO S32760 410S.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-5000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | TP310S Stainless Steel Pipe | Grade | 304 304L 410s 316L 316Ti 316ln 321 317L 2205 S32760 254smo 2507 310S 347 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Heat Exchanger | Packing | Wooden Box Or PP Bag |
| Highlight | ASTM Stainless Steel Pipe,ASTM Stainless Steel Tube,Stainless Steel Round Pipe |
||
Product Description
TP310S Stainless Steel Pipe ASTM A312 Seamless Stainless Steel Tube for Boiler
| Products Name | TP310S Stainless Steel Pipe |
| Pipe Type | Seamless Pipe . Welded Pipe |
| Surface | Pickling , polishing |
| Out Diameter | 6 - 508mm |
| Wall Thickness | 1.0 - 50.0mm |
| Length | 6m or cutting any length as request |
| Standard | ASTM / GB / EN / DIN / JIS / BS / BIS |
| Mainly Grade | 304 304L 304H 309S 310S 316L 316Ti 317L 321 347 2205 2507 904L 254SMO 800/800H Alloy20 ,Hastelloy Alloy, Monel Alloy,Inconel Alloy |
| Service | Cutting, Polishing, Hairline Finishing |
| MOQ | 200 Kgs |
| Packing | standard packing for export |
| Application | Industrial , food , medical, househould |
TP310S,1.4845, UNS S31008, UNS S31000, X8CrNi25-21, EN10095
SAE 310S stainless steel is the low carbon version of 310 and is suggested for applications where sensitization, and subsequent corrosion by high temperature gases or condensates during shutdown may pose a problem.
SAE 310 stainless steel is a highly alloyed austenitic stainless steel used for high temperature application. The high chromium and nickel content give the steel excellent oxidation resistance as well as high strength at high temperature. This grade is also very ductile and has good weldability enabling its widespread usage in many applications.
310/310S find wide application in all high-temperature environments where scaling and corrosion resistance, as well as high temperature strength and good creep resistance are required.
SAE 310 stainless steel is a highly alloyed austenitic stainless steel used for high temperature application. The high chromium and nickel content give the steel excellent oxidation resistance as well as high strength at high temperature. This grade is also very ductile and has good weldability enabling its widespread usage in many applications.
310/310S find wide application in all high-temperature environments where scaling and corrosion resistance, as well as high temperature strength and good creep resistance are required.
Chemical Composition of 310S Stainless Steel
| SAE | C | Mn | P | S | Si | Cr | Mo | Ni |
| 310H | 0.04-0.08 | ≤2.0 | ≤0.045 | ≤0.03 | ≤1.5 | 24.0–26.0 | 19.0–22.0 | |
| 310S | ≤0.08 | ≤2.0 | ≤0.75 | 19.0–22.0 |
Mechanical Properties of 310S Stainless Steel
| Tensile strength | Yield strength | Elastic modulus | Poisson’s ratio | Elongation | Reduction of area | Hardness |
| ≥515Mpa | ≥205Mpa | 190-210 GPa | 0.27-0.30 | 40% | 50% | ≤95 |
Applications
• Cryogenic Components
• Food Processing
• Furnaces—burners, doors, fans, piping, and recuperators
• Fluidized Bed Furnaces—coal combustors, grids, piping, wind boxes
• Ore Processing/Steel Plants—smelter and steel melting equipment, continuous casting equipment
• Petroleum Refining—catalytic recovery systems, flares, recuperators, tube hangers
• Power Generation—coal gasifier internals, pulverized coal burners, tube hangers
• Sintering/Cement Plants—burners, burner shields, feeding and discharging systems, wind boxes
• Thermal Processing—annealing covers and boxes, burner grids, doors, fans, muffles and retorts, recuperators, walking beams
Material Summary
SAE 310S stainless steel is the low carbon version of 310 and is suggested for applications where sensitization, and subsequent corrosion by high temperature gases or condensates during shutdown may pose a problem.
SAE 310 stainless steel is a highly alloyed austenitic stainless steel used for high temperature application. The high chromium and nickel content give the steel excellent oxidation resistance as well as high strength at high temperature. This grade is also very ductile and has good weldability enabling its widespread usage in many applications.
310/310S find wide application in all high-temperature environments where scaling and corrosion resistance, as well as high temperature strength and good creep resistance are required.
