Stainless Steel Chequered Plate & Sheet Thickness 3mm 4mm 5mm for Floor
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 316L |
| Minimum Order Quantity | 500 kgs |
| Price | 2800 -3200 USD/Ton |
| Packaging Details | wooden pallets + waterproof paper |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Chequered Plate | Grade | 304 316L |
|---|---|---|---|
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm | Thickness | 0.6- 10.0mm |
| Brand | TISCO BAOSTEEL POSCO LISCO | Loading Port | Shanghai Port |
| MOQ | 500 Kgs | Packing | Wooden Pallets + Waterproof Paper |
| Highlight | stainless steel chequered plate,stainless steel checker plate,stainless checker plate |
||
Product Description
Stainless Steel Chequered Plate & Sheet Thickness 3mm 4mm 5mm for Floor
More Informations of our Products
| Item | Stainless Steel Checker Plate/Stainless Steel Chequered Plate |
| Raw Material | Stainless steel sheet (hot rolled and cold rolled) |
| Grades | 201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, etc. |
| Thickness | 0.6mm-10mm |
| Stock Thickness | 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10mm |
| Width | 600mm – 1,800mm |
| Pattern | Chequered pattern, diamond pattern, lentils pattern, leaves pattern, etc. |
| Finish | 2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc. |
| Package | Standard export package |
Stainless Steel Chequered Plate Supplier, Stockist Of Stainless Steel Chequer Sheet, 304 Stainless Steel Tread Plate in Mumbai, SS Chequered Sheet, Jindal Stainless Diamond Plate, SS Checker Sheet, Price List Chequered Steel Plate, 6mm Chequered Plate Price, Chequered Steel Plate in KG, SS Tear Plate Dealer
Stainless Steel Checkered Plate Manufacturers, Polished Stainless Steel Checkered Plate, Supplier of SS Checker Plate, Checkered Sheet Price, Stainless Diamond Chequer Plate
Stainless Steel Chequered Sheet Chemical Composition
| GRADE | C | MN | P | S | SI | CR | N | NI | FE |
|---|---|---|---|---|---|---|---|---|---|
| SS CHEQUERED 304 PLATES | 0.07max | 2.0max | 0.045max | 0.03max | 0.75max | min: 18.0 max: 20.0 | - | min: 8.0 max: 10.5 | - |
| SS CHEQUERED 304L SHEETS | 0.03max | 2.0max | 0.045max | 0.03max | 0.75max | min: 18.0 max: 20.0 | 0.10 max | min: 8.0 max: 12.0 | - |
| SS CHEQUERED 304H PLATE | min: 18.0 max:20.0 | min: 8.0 max: 10.5 | 0.75 max | 2.0 max | min: 0.04 max:0.10 | 0.045 max | 0.10 max | 0.03 max | - |
| SS CHECKERED 316 SHEETS | MIN | - | - | 0 | - | - | 10.0 | 16.0 | - |
| MAX | 0.08 | 0.75 | 0.045 | 2.0 | 0.03 | 14.0 | 18.0 | 0.10 | |
| SS CHECKER 316L PLATES | MIN | - | - | - | - | - | 10.0 | 16.0 | - |
| MAX | 0.03 | 0.75 | 0.045 | 2.0 | 0.03 | 14.0 | 18.0 | 0.10 | |
| SS CHEQUERED 316H SHEET | MIN | 0.04 | 0 | - | 0.04 | - | 10.0 | 16.0 | - |
| MAX | 0.10 | 0.75 | 0.045 | 0.10 | 0.03 | 14.0 | 18.0 | - |
Stainless Steel Checkered Plate Mechanical Properties
| Grade | Density | Yield Strength (0.2%Offset) | Tensile Strength | Melting Point | Elongation |
| Stainless Steel 304 / 304L Checkered Plate | 8.0 g/cm3 | Psi 30000, MPa 205 | Psi 75000, MPa 515 | 1400 °C (2550 °F) | 35 % |
| Stainless Steel 304H Checkered Sheet | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 1400 °C (2550 °F) | 40 % |
| Stainless Steel 310 Checker Plate | 7.9 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 1402 °C (2555 °F) | 40 % |
| Stainless Steel 316 Checkered Sheet | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 1400 °C (2550 °F) | 35 % |
| Stainless Steel 316L Checker Plate | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 1399 °C (2550 °F) | 35 % |
| Stainless Steel 317 Checker Sheets | 7.9 g/cm3 | Psi 30000, MPa 205 | Psi 75000, MPa 515 | 1400 °C (2550 °F) | 35 % |
| Stainless Steel 321 Checkered Plates | 8.0 g/cm3 | Psi 30000, MPa 205 | Psi 75000, MPa 515 | 1457 °C (2650 °F) | 35 % |
| Stainless Steel 347 Checker Sheets | 8.0 g/cm3 | Psi 30000 , MPa 205 | Psi 75000 , MPa 515 | 1454 °C (2650 °F) | 35 % |
| Stainless Steel 904L Checker Plate | 7.95 g/cm3 | Psi 32000, MPa 220 | Psi 71000, MPa 490 | 1350 °C (2460 °F) | 35 % |
Equivalent Grades of 304 SS Chequered Steel Plate
| STANDARD | UNS | WERKSTOFF NR. | BS | JIS | EN | GOST |
| SS 304 | S30400 | 1.4301 | 304S31 | SUS 304 | X5CrNi18-10 | 08Х18Н10 |
| SS 304L | S30403 | 1.4306 / 1.4307 | 3304S11 | SUS 304L | X2CrNi18-9 / X2CrNi19-11 | 03Х18Н11 |
| SS 304H | S30409 | 1.4301 | - | - | - | - |
| SS 310 | S31000 | 1.4841 | 310S24 | SUS 310 | X15CrNi25-20 | 20Ch25N20S2 |
| SS 310S | S31008 | 1.4845 | 310S16 | SUS 310S | X8CrNi25-21 | 20Ch23N18 |
| SS 310H | S31009 | - | - | - | - | - |
| SS 316 | S31600 | 1.4401 / 1.4436 | 316S31 / 316S33 | SUS 316 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 | - |
| SS 316L | S31603 | 1.4404 / 1.4435 | 316S11 / 316S13 | SUS 316L | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 | 03Ch17N14M3 / 03Ch17N14M2 |
| SS 316H | S31609 | 1.4401 | - | - | - | - |
| SS 316Ti | S31635 | 1.4571 | 320S31 | SUS 316Ti | X6CrNiMoTi17-12-2 | 08Ch17N13M2T |
| SS 317 | S31700 | 1.4449 | - | SUS 317 | - | - |
| SS 317L | S31703 | 1.4438 | - | SUS 317L | X2CrNiMo18-15-4 | - |
| SS 321 | S32100 | 1.4541 | - | SUS 321 | X6CrNiTi18-10 | - |
| SS 321H | S32109 | 1.4878 | - | SUS 321H | X12CrNiTi18-9 | - |
| SS 347 | S34700 | 1.4550 | - | SUS 347 | X6CrNiNb18-10 | 08Ch18N12B |
| SS 347H | S34709 | 1.4961 | - | SUS 347H | X6CrNiNb18-12 | - |
| SS 904L | N08904 | 1.4539 | 904S13 | SUS 904L | X1NiCrMoCu25-20-5 | STS 317J5L |
Types of Stainless Steel Chequered Sheet
• SS Checkered Sheet
• SS Chequer Sheet
• Stainless Steel Checkered Plate
• 316 SS Chequer Plate
• Stainless Steel Checkered Plate
• Stainless Steel Checker Plate
• 304 Stainless Steel Tread Plate
• SS Diamond Chequer Plate
• Stainless Steel Checkered Sheet
• 304 SS Chequered Plates
• Stainless Steel Tear Plate
• SS Floor Plate in China
• Stainless Steel Diamond Plate
• Stainless Steel Tread Plate
• Stainless Steel Checker Plate
• Stainless Steel Checker Sheet
• Metal Checkered Plate
• Stainless Steel Checker Plate
• 316 Stainless Steel Checkered Sheet
• Stainless Steel Chequer Sheet
• Stainless Steel Checker Sheet
• Stainless Steel Tear Plate
• Stainless Steel Floor Plate
• SS 304 Diamond Chequer Plate
