S32205 2205 Grade Duplex stainless Steel Seamless Pipes ASTM A790/790M SS Pipe
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 304L 316L 316LN 316Ti 317L 321 310S 309S 347 2205 2507 904L 254SMO S32760 410S.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-5000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Pipe | Grade | 304 304L 410s 316L 316Ti 316ln 321 317L 2205 S32760 254smo 2507 310S 347 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Heat Exchanger | Packing | Wooden Box Or PP Bag |
| Highlight | seamless stainless steel pipe,stainless steel round tube,boiler stainless steel pipe |
||
Product Description
S32205 2205 Grade Duplex stainless Steel Seamless Pipes ASTM A790/790M SS Pipe
Specification of our stainless steel pipe
| Products Name | Stainless Steel pIpe |
| Diameter | DN6 - DN500 |
| Wall Thickness | SCH10S - XXS or unstandard size as request |
| Length | 6m or cutting any length as request |
| Standard | ASTM JIS EN DIN |
| Technique | Hot Rolled / cold drawn |
| Type | Seamless Pipe / Welded Pipe |
| Surface | Bright Polished, Pickling |
| Main Grade | 201 304 304L 309S 310S 316L 316Ti 316LMod 317L 321 347 410 904L 254SMO 253MA 2205 2507 654SMO 926 400 c276 c22 C4 600 625 800 825.etc |
| MOQ | 500 kgs |
| Loading Port | Shanghai Port |
| Packing | wooden box or ppbag |
About Duplex 2205 Stainless Steel
Duplex 2205 is a two-phase, ferritic, austenitic 22% chromium, 3% molybdenum, 5 to 6% nickel alloyed stainless steel. It is the most widely used duplex stainless steel grade and is characterized by high yield strength, double that of the standard austenitic stainless steel grades. It also demonstrates good fatigue strength, as well as outstanding resistance to stress corrosion cracking, crevice, pitting, erosion, and general corrosion in severe environments.
- A790/A790 M S32205 2205 Stainless steel seamless pipes dimention
- O.D : 1/8" NB TO 32" NB, (10.29MM-812.80MM)
- W.T: SCH 10S, SCH 40S, SCH 80S, SCH160, SCH XXS.
- A790/A790 M S32205 2205 Stainless Steel Seamless Pipe
- Annealed and Picked
- 100% PMI TESTED
- EN10204.3.1B MILL TEST CERTIFICATE
- THIRD PARTY INSPECTION ACCEPTED
- A790/A790 M S32205 2205 Stainless steel seamless pipes Packing.
- With plastic caps to both ends, Wrapped with Poly bags,pack into bundles. Or pack into plywood boxes as required.
S32205 2205 Seamless Pipe Chemical Composition:
| HEAT NO. | CHEMICAL COMPOSITION (%) | ||||||||||||
| C | Mn | P | S | Si | Ni | Cr | Mo | N | |||||
| STAND. | MIN. | 4.5 | 22.00 | 3.0 | 0.14 | ||||||||
| MAX. | 0.03 | 2.00 | 0.03 | 0.020 | 1.00 | 6.5 | 23.00 | 3.5 | 0.2 | ||||
S32205 2205 Seamless Pipe Mechanical Properties:
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) | Brinell (HB) | ||||
| S32205 2205 | 515 | 205 | 35 | 90 | 187 |
APPLICATIONS:
- Chemical processing, transport and storage – pressure vessels, tanks, piping, and heat exchangers
- Oil and gas exploration and processing equipment – piping, tubing, and heat exchangers
- Marine and other high chloride environments
- Effluent scrubbing systems
- Pulp and paper industry – digesters, bleaching equipment, and stock-handling systems
- Cargo tanks for ships and trucks
- Food processing equipment
- Biofuels plants
