S32750 2507 Grade Ss Smls Pipe Hot Rolled Custom Cutting Any Length
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 304L 316L 316LN 316Ti 317L 321 310S 309S 347 2205 2507 904L 254SMO S32760 410S.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-5000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Pipe | Grade | 304 304L 410s 316L 316Ti 316ln 321 317L 2205 S32760 254smo 2507 310S 347 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Heat Exchanger | Packing | Wooden Box Or PP Bag |
| Highlight | S32750 ss smls pipe,Custom Length ss smls pipe |
||
Product Description
S32750 (2507) Grade Duplex Stainless Steel Seamless Pipes Hot Rolled SMLS Pipe Custom Cutting Any Length
Specification of our stainless steel pipe
| Products Name | Stainless Steel pIpe |
| Diameter | DN6 - DN500 |
| Wall Thickness | SCH10S - XXS or unstandard size as request |
| Length | 6m or cutting any length as request |
| Standard | ASTM JIS EN DIN |
| Technique | Hot Rolled / cold drawn |
| Type | Seamless Pipe / Welded Pipe |
| Surface | Bright Polished, Pickling |
| Main Grade | 201 304 304L 309S 310S 316L 316Ti 316LMod 317L 321 347 410 904L 254SMO 253MA 2205 2507 654SMO 926 400 c276 c22 C4 600 625 800 825.etc |
| MOQ | 500 kgs |
| Loading Port | Shanghai Port |
| Packing | wooden box or ppbag |
About Duplex 2507 Stainless Steel Pipe
Duplex 2507 (UNS S32750) is a super duplex stainless steel with 25% chromium, 4% molybdenum, and 7% nickel designed for demanding applications which require exceptional strength and corrosion resistance, such as chemical process, petrochemical, and seawater equipment. The steel has excellent resistance to chloride stress corrosion cracking, high thermal conductivity, and a low coefficient of thermal expansion. The high chromium, molybdenum, and nickel levels provide excellent resistance to pitting, crevice, and general corrosion.
Specification of duplex 2507 Stainless Steel Pipe
- A790/A790 M S32750 (2507) Stainless steel seamless pipes dimention
- O.D : 1/8" NB TO 32" NB, (10.29MM-812.80MM)
- W.T: SCH 10S, SCH 40S, SCH 80S, , SCH160, SCH XXS.
- A790/A790 M S32750 (2507) Stainless Steel Seamless Pipe
- Annealed and Picked
- 100% PMI TESTED
- EN10204.3.1B MILL TEST CERTIFICATE
- THIRD PARTY INSPECTION ACCEPTED
- A790/A790 M S32750 (2507) Stainless steel seamless pipes Packing.
- With plastic caps to both ends, Wrapped with Poly bags,pack into bundles. Or pack into plywood boxes as required.
S32750 (2507) Seamless Pipe Chemical Composition:
| HEAT NO. | CHEMICAL COMPOSITION (%) | ||||||||||||
| C | Mn | P | S | Si | Ni | Cr | Mo | N | |||||
| STAND. | MIN. | 6.0 | 24.00 | 3.0 | 0.24 | ||||||||
| MAX. | 0.03 | 1.20 | 0.035 | 0.020 | 0.80 | 8.0 | 26.00 | 5.0 | 0.32 | ||||
S32750 (2507) Seamless Pipe Mechanical Properties:
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) | Brinell (HB) | ||||
| S32750 (2507) | 515 | 205 | 35 | 90 | 187 |
Application of Duplex 2507 Stainless Steel Pipe
- Oil and gas industry equipment
- Offshore platforms, heat exchangers, process and service water systems, fire-fighting systems, injection and ballast water systems
- Chemical process industries, heat exchangers, vessels, and piping
- Desalination plants, high pressure RO-plant and seawater piping
- Mechanical and structural components, high strength, corrosion-resistant parts
- Power industry FGD systems, utility and industrial scrubber systems, absorber towers, ducting, and piping
