TP317/TP317L Stainless Steel Pipe Tube DN6-DN400 SMLS Pipe in 6m Length
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 304L 316L 316LN 316Ti 317L 321 310S 309S 347 2205 2507 904L 254SMO S32760 410S.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-5000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | 253ma Stainless Steel Pipe | Grade | 304 304L 410s 316L 316Ti 316ln 321 317L 2205 S32760 254smo 2507 310S 347 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Heat Exchanger | Packing | Wooden Box Or PP Bag |
| Highlight | seamless stainless steel pipe,stainless steel round tube,boiler stainless steel pipe |
||
Product Description
TP317/TP317L Stainless Steel Pipe Tube DN6-DN400 SMLS Pipe in 6m Length
Specification of our stainless steel pipe
| Products Name | Stainless Steel pIpe |
| Diameter | DN6 - DN500 |
| Wall Thickness | SCH10S - XXS or unstandard size as request |
| Length | 6m or cutting any length as request |
| Standard | ASTM JIS EN DIN |
| Technique | Hot Rolled / cold drawn |
| Type | Seamless Pipe / Welded Pipe |
| Main Grade | 201 304 304L 309S 310S 316L 316Ti 316LMod 317L 321 347 410 904L 254SMO 253MA 2205 2507 654SMO 926 400 c276 c22 C4 600 625 800 825.etc |
| MOQ | 500 kgs |
| Loading Port | Shanghai Port |
| Packing | wooden box or ppbag |
317/317L Stainless Steel Pipe
317L stainless steel pipe, also known as UNS S31703 and Grade 317L SS pipe, it is a low carbon high grade stainless steel pipe, with a good corrosion resistance and machine work performance. Compare to 317L, 317 stainless steel has a higher carbon content, it means that 317 stainless steel has a better heat resistance. Kaysuns supply both 317 and 317L stainless steel pipe, and dual grade 317/317L is available based on the requirement to ASTM A312 or EN10216-5 etc.
Chemical Composition of 317L Stainless Steel Tubing ASTM A312, ASTM A269, ASTM A213
| Grade | C | Mn | P | S | Si | Ni | Cr | Mo | Weight % |
| TP317 | 11.00 | 18.00 | 3.00 | Min. | |||||
| 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 14.00 | 20.00 | 4.00 | Max. | |
| TP317L | 11.00 | 18.00 | 3.00 | Min. | |||||
| 0.035 | 2.00 | 0.045 | 0.03 | 1.00 | 15.00 | 20.00 | 4.00 | Max. |
Mechanical Properties of 317L Stainless Steel Tubing ASTM A269, ASTM A213, ASTM A312
| Grade | Tensile Strength, Min. Mpa | Yield Strength, Min. Mpa | Longitudinal |
| TP317 | 515 | 205 | 35 |
| TP317L | 515 | 205 | 35 |
Available Manufacturing and Dimension for 317L Stainless Steel Pipe
ASTM A312, ASTM A269, ASTM A213, ASTM A249, ASTM A358, EN10216-5, EN10217-7, DIN 17456, DIN 17455, GOST 9941, JIS G3459, JIS G3463 etc.
Features of 317/317L Stainless Steel Tubes
317/317L Stainless Steel Pipes PMI Test
- In the point of chemical composition, the chromium, nickel and molybdenum contents of 317L stainless steel pipe are increased by 2%, 1%, and 1% compare to 316L stainless steel pipe. The threes are the main elements that determine the performance of stainless steel pipe. Reflected in the Pitting corrosion resistance, the performance of 317L stainless steel is better than 304L and 316L stainless steel.
- The corrosion resistance of 317L stainless steel is similar to 316L stianless steel . The high molybdenum content ensures that it has a better resistance to overall and local corrosion for most media – such as sulfuric acid, acid chlorine and phosphoric acid. In strong oxidizing acids such as nitric acid, 317L stainless steel is susceptible to corrosion.
- The performance of the 317L stainless steel is basically the same as 317 stainless steel. Due to the lower carbon content, the welding performance of 317L ss pipe and the intergranular corrosion resistance performance at high temperature (427~816 °C) are better than 317 ss pipe.
Material Comparision of 317/317L Stainless Steel ASTM / EN /JIS
| China – GB | Japan | USA | KS | EN/DIN | AS | CNS | DIN | ||
| Grade | New(GB24511) | JIS | ASTM | UNS | Grade | ||||
| S31708 | 06Cr19Ni13Mo3 | SUS317 | 317 | S31700 | STS317 | 1.4449 | 317 | 317 | X5CrNiMo1713 |
| S31703 | 022Cr19Ni13Mo3 | SUS317L | 317L | S31703 | STS317L | 1.4438 | 317L | 317L | X2CrNiMo18-15-4 |
Application of 317L Stainless Steel
317 & 317L stainless steel are commonly used in flue gas desulfurization systems, chemical and petrochemical processing, food and beverage industries, petroleum refining, condensers for generator equipment, and paper industry etc. Kaysuns provides dual grade 317/317L stainless steel pipes with more than 10 year experiences.
