ASTM A240 Grade 317L Stainless Steel Plate & Sheet Hot Rolled NO.1 Surface 3.0 - 16.0mm Thickness
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 202 218 304 316L 309S 310S 317L 321 347 904L 2205 2507 925 926.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | wooden pallets + waterproof paper |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 5Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet & Plate | Grade | 201 202 218 304 310S 310H 316L 317L 409L 430.etc |
|---|---|---|---|
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm | Thickness | 0.6 - 60.0mm |
| Brand | TISCO BAOSTEEL POSCO LISCO | Loading Port | Shanghai Port |
| MOQ | 500 Kgs | Packing | Wooden Pallets + Waterproof Paper |
| Highlight | stainless plate,ss plate,custom stainless steel plates |
||
Product Description
ASTM A240 Grade 317L Stainless Steel Plate & Sheet Hot Rolled NO.1 Surface 3.0 - 16.0mm Thickness
More Specification of 317L Stainless Steel Plate
| Products | Stainless Steel Plate |
| Thickness | 0.6 - 60.0mm |
| Width | 1000mm 1219mm 1500mm 1800mm 2000mm or other width as request |
| Length | 2000mm 2438mm 3000mm 6000mm or other length as request |
| Grade | 201 202 301 304 304L 304H 309S 310S 310H 316L 316Ti 317L 321 347 409L 410 420 430 431 436L 439 441 443 444 2205 2507 904L 600 625 800 825 718 253MA 254SMO Nitronic 60 925 926.etc |
| Service | Laser Cutting, Surface processing, bending |
| Brand | TISCO BAOSTEEL POSCO LISCO JISCO |
| Standard | ASTM JIS GB DIN EN BS |
| Certificate | ISO MTC C/O F/E |
| Packing | Wooden pallets and waterproof paper |
| Deliver time | 5 - 15 days |
| Loading port | Shanghai Port |
About 317L Stainless Steel Plate
Alloy 317L is a low-carbon, high molybdenum austenitic stainless steel with a higher nickel alloy content than 316L. Developed to resist the attack of sulfuric acid compounds, this alloy combines good corrosion resistance with excellent mechanical properties and ease of fabrication. These alloys are frequently used for flue gas desulfurization services in fossil-fuel power plants. Compared to other austenitic stainless steels, 317L offers a higher creep strength, stress to rupture, and tensile strength at elevated temperatures.
The higher molybdenum and chromium content of 317L provides excellent corrosion resistance compared to stainless steel grades like 304 or 316, and it resists phosphoric acid, sulfuric acid, and chloride pitting/crevice corrosion. The low carbon content of this grade of 317 also provides resistance to sensitization during welding, which allows it to maintain its corrosion resistance at grain boundaries and prevent intergranular stress corrosion cracking.
While 317L cannot be hardened by heat treatment, it can be cold worked.
Standard Inventory Specifications
- UNS S31703 - 317L
- ASTM A 240
- ASTM A182
- ASTM A167
- ASME SA 240
Common Applications of 317L
- Flue gas desulfurization systems found in fossil fuel plants
- Chemical and Petrochemical Processing
- Food and Beverage Processing
- Power Generation — condensers
- Pulp and Paper Processing
- Textiles with acid dyes
Features
- Good corrosion resistance
- Good mechanical properties
- Ease of fabrication
- Produces stronger welds due to lower carbon content
- Resists the attack of sulfuric acid compounds
*The technical data provided is for information only and not for design purposes. It is not warranted or guaranteed.
Stainless Steel 317L Plate Thickness
| Cold rolled ASTM A240 317L thin plate | 0.2-4mm |
| Hot rolled SS 317L medium plate | 4-20mm |
| Hot rolled 317L SS thick plate | 20-60mm |
| Hot rolled AISI 317L extra thick plate | 60-115mm |
317L Material Equivalent
| STANDARD | UNS | WERKSTOFF NR. |
| SS 317L | S31703 | 1.4438 |
ASTM A240 TP 317L Stainless Steel Plate For Sale
| Stainless Steel 317L 10mm Plate | Stainless Steel Type 317L Plasma Cutting Plate |
| 317L Stainless Steel Sheet | Stainless Steel Type 317L Quarto Plate |
| 317L Stainless Steel Foil Rolls | ASTM A240 317L Expanded Sheet |
| ASTM A240 317L Plate | ASTM A240 SS 317L Flat Sheet |
| ASTM A240 Type 317L Coil | A240 Tp 317L Bbq Plate |
| AISI 317L Hot Rolled Plate | SS 317L Diamond Plate |
| ASTM A240 TP 317L Cold Rolled Plate | 317L SS Patterned Sheet |
| SS 317L Clad Plate | Stainless Steel AISI 317L Floor Sheet |
| 317L SS Shim Sheet | ASTM A240 Type 317L Precision Strip |
| AISI 317L Stainless Steel Chequered Plate | AISI 317L Shims |
| Grade 317L Stainless Steel Flat Strip | ASTM A240 317L Thin Plate |
| Stainless Steel 317L Perforated Sheet | Stainless Steel Grade 317L Shim Stock |
| Grade 317L Stainless Steel Plate Mill Finish | AISI 317L Stainless Steel Rolling Plate |
| Stainless Steel Grade 317L Plate Mirror Finish | Grade 317L Stainless Steel Perforated Plate |
| SS 317L Sheet No 4 Finish | ASTM A240 Type 317L Checker Plate |
| 317L SS Sheet Mirror Finish | SS 317L Rolls Sheet |
| AISI 317L Sheet Brushed Finish | 317L SS Chequer Plate |
| Stainless Steel Grade 317L Hot Rolled Sheet | 317L Stainless Steel Tisco Plate |
| Stainless Steel Type 317L Slitting Coils | Stainless Steel 317L Design Sheet |
| ASTM A240 317L Strips | ASTM A240 TP 317L Custom Cut Plate |
| ASTM A240 Grade 317L Cold Rolled Sheet | A240 Tp 317L Tread Plate |
| A240 Tp 317L Foil | Grade 317L Stainless Steel Embossed Plate |
| Stainless Steel AISI 317L Shim Sheets | Stainless Steel Grade 317L 1/4 Inch Plate |
| ASTM A240 SS 317L Chequered Plate | ASTM A240 Grade 317L Hairline Sheet |
| 317L Stainless Steel Polished Plate | AISI 317L Stainless Steel Checkered Plate |
| ASTM A240 Type 317L 2b Finish Sheet | Stainless Steel AISI 317L Corrugated Sheet |
| ASTM A240 TP 317L Sheet Hairline Finish | AISI 317L B. Q. Profile |
| AISI 317L Stainless Steel Plate 2b Finish | ASTM A240 TP 317L Etching Sheet |
| ASTM A240 Grade 317L Plate Brushed Finish | ASTM A240 SS 317L Laser Cut Plate |
Stainless Steel SA 240 Gr 317L Composition
| SS | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| A240 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 - 20.00 | 3.00 - 4.00 | 11.00 - 15.00 | 57.89 min |
Stainless Steel 317L Properties
| Melting Range | Density | Tensile Strength (PSI/MPa) | Yield Strength (0.2%Offset) (PSI/MPa) | Elongation % |
| 1400 °C (2550 °F) | 7.9 g/cm3 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
