Hastelloy C276 Seamless Pipe Tube UNS N10276 Alloy Tubing ASTM EN Standard
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 304L 316L 316LN 316Ti 317L 321 310S 309S 347 2205 2507 904L 254SMO S32760 410S C276.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-5000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Hastelloy C276 | Grade | 304 304L 410s 316L 316Ti 316ln 321 317L 2205 S32760 254smo 2507 310S 347 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Heat Exchanger | Packing | Wooden Box Or PP Bag |
| Highlight | Hastelloy C276 Seamless Pipe Tube,ASTM EN Standard Seamless Pipe,Alloy Tubing Seamless Pipe |
||
Product Description
Hastelloy C276 Seamless Pipe Tube UNS N10276 Alloy Tubing ASTM EN Standard
Alloy C276 is a nickel-molybdenum-chromium-tungsten superalloy, showing excellent resistance to mechanical and chemical degradation. The high nickel and molybdenum content impart remarkable corrosion resistance in reducing environments, while chromium provides the same in an oxidizing media. Molybdenum also provides strong resistance to crevice corrosion and pitting. This alloy gives an excellent performance in a wide range of chemical processing conditions, often where nothing else works. Target applications include those involving strong oxidizers, such as ferric and cupric chlorides and hot
Product Specifications
ASTM B622, B829 / ASME SB622, SB829 / NACE MR0175
Size Range
|
Outside Diameter (OD) |
Wall Thickness |
|
.250”–.500” |
.035”–.065” |
Chemical Requirements
Alloy C276 (UNS N10276)
Composition %
|
Ni |
Cr Chromium |
Mo |
Fe |
W |
C Carbon |
Si |
Co |
Mn |
V |
P Phosphorous |
S |
|
57.0 min |
14.5–16.5 |
15.0–17.0 |
4.0–7.0 |
3.0–4.5 |
0.010 max |
0.08 max |
2.5 max |
1.0 max |
0.35 max |
0.04 max |
0.03 max |
Dimensional Tolerances
|
OD |
OD Tolerance |
Wall Tolerance |
|
.250"–.500" |
+.004”/-.005” |
± 15% |
Mechanical Properties
|
Yield Strength: |
41 ksi min |
|
Tensile Strength: |
100 ksi min |
|
Elongation (min 2"): |
40% |
Industry Applications
-
Chemical Process
C276 is one of the premier alloys in the chemical processing industry utilized for its excellent resistance against corrosion, pitting in high stress, oxidizing and reducing environments. The alloy is seen in applications in wastewater treatment, transfer tubing, wet chlorine and hypochlorites environments.
-
Oil & Gas
C276 is an excellent choice for flare applications where hydrofluoric acid is prevalent due its superior performance against stress corrosion cracking. Alloy C276 is used in recovery systems of sour natural gas and oil wells.
-
Power Generation
The addition of molybdenum and tungsten, combined with a high chromium content, makes C276 the material of choice for some of the most severe corrosive environments, particularly in pollution control and flue gas desulfurization. See power generation for more information.
