Super Austenitic 317L Stainless Steel Pipe AISI316L / UNS S31703 Stainless Tube Seamless Pipe
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 304 304L 316L 316LN 316Ti 317L 321 310S 309S 347 2205 2507 904L 254SMO S32760 410S.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 4000-5000 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | 253ma Stainless Steel Pipe | Grade | 304 304L 410s 316L 316Ti 316ln 321 317L 2205 S32760 254smo 2507 310S 347 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
| Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
| Type | Seamless Pipe | Service | Cutting, Polishing |
| Application | Heat Exchanger | Packing | Wooden Box Or PP Bag |
| Highlight | seamless stainless steel pipe,stainless steel round tube,boiler stainless steel pipe |
||
Product Description
Super Austenitic 317L Stainless Steel Pipe AISI316L / UNS S31703 Stainless Tube Seamless Pipe
317L Stainless Steel Tubing
Similar in composition to 316L and 304L, alloy 317L is an austenitic molybdenum, chromium, nickel stainless alloy. Due to the higher moly content, 317L provides enhanced resistance to pitting and stress corrosion cracking particularly in chloride or halide-rich environments. 317L has higher creep, stress-to-rupture, and tensile strength than its 316L and 304L counterparts which makes it a great solution to demanding applications found offshore, in pulp & paper mills and in chemical processing plants.
Products Specification of 317L Stainless Steel Pipe
| Products Name | 317L Stainless Steel pIpe |
| Diameter | DN6 - DN500 |
| Wall Thickness | SCH10S - XXS or unstandard size as request |
| Length | 6m or cutting any length as request |
| Standard | ASTM JIS EN DIN |
| Technique | Hot Rolled / cold drawn |
| Type | Seamless Pipe / Welded Pipe |
| Other Grade | 201 304 304L 309S 310S 316L 316Ti 316LMod 317L 321 347 410 904L 254SMO 253MA 2205 2507 654SMO 926 400 c276 c22 C4 600 625 800 825.etc |
| MOQ | 500 kgs |
| Loading Port | Shanghai Port |
| Packing | wooden box or ppbag |
Chemical Composition of 317L Stainless Steel Pipe
Chemical Requirements
ASTM TP317L (UNS S31703)
Composition %
|
C Carbon |
Mn |
P |
S |
Si |
Cr |
Ni Nickel |
Mo |
|
0.030 max |
2.00 max |
0.045 max |
0.030 max |
1.00 max |
18.0–20.0 |
11.0–15.0 |
3.0–4.0 |
Dimensional Tolerances
|
OD |
OD Tolerance |
Wall Tolerance |
|
≤ .500” |
± .005" |
± 10% |
|
.500”–1.5” excl |
± .005” |
± 10% |
Size Range
|
Outside Diameter (OD) |
Wall Thickness |
|
6 - 508mm |
SCH10S SCH40S SCH80S SCH160 |
APPLICATIONS
Alloy 317L is commonly used to handle sulfur, pulp liquor, acid dyestuffs, acetylating and nitrating mixtures, bleaching solutions, severe coal and oil, and many chemical compounds. Some other applications that use alloy 317L include:
- Paper and pulp handling equipment
- Chemical and petrochemical processing equipment
- Condensers in fossil and nuclear fueled power generation stations
- Food processing equipment
- Textile equipment
