EN 10088 1.4571 Stainless Steel Sheet Plate 316Ti SS Sheet Cold Rolled 0.6 - 3.0mm Thickness
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 309S 310S 321 347 904L 2205 2507.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | wooden pallets + waterproof paper |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 5Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet & Plate | Grade | 201 304 316L 430.etc |
|---|---|---|---|
| Standard Size | 1000*2000mm 1219*2438mm | Thickness | 0.3- 3.0mm |
| Brand | TISCO BAOSTEEL POSCO LISCO | Loading Port | Shanghai Port |
| MOQ | 500 Kgs | Packing | Wooden Pallets + Waterproof Paper |
| Highlight | cold rolled stainless steel sheet,stainless steel cold rolled sheet,cold rolled steel sheet |
||
Product Description
EN 10088 1.4571 Stainless Steel Sheet Plate 316Ti SS Sheet Cold Rolled 0.6 - 3.0mm Thickness
316ti is a titanium stabilized stainless steel. The 316ti Stainless Steel Plate is designed with a superior chemical concentration of chromium, nickel, and molybdenum. The excellent concentration allows these modules to have enhanced corrosion and oxidation resistance properties. SS 316ti plate offers enhanced resistance to pitting by chlorides in seawater.
These high-grade components show higher creep-rupture and stress-rupture properties. A 316ti Stainless Steel Sheet shows resistance to sensitization at temperatures up to 900 degrees F due to the presence of titanium in its composition. Designed with outstanding mechanical properties and strength, the SS 316ti sheet can suffice in a range of stress-induced environments.
Grade Specification of 1.4571 / 316Ti Stainless Steel
| Material Design | 1.4571 |
| AISI/SAE | 316 Ti |
| EN Material Symbol | X6CrNiMoTi17-12-2 |
| UNS | S 31635 |
| AFNOR | Z 6 CNDT 17.12 |
| B.S. | 320 S 17, 320 S18, 320 S31 |
| Norm | VdTUEV 454 |
Chemical composition of 1.4571
| C | Si | Mn | P | S | Cr | Mo | Ni | Ti |
| ≤ % | ≤ % | ≤ % | ≤ % | ≤ % | % | % | % | ≤ % |
| 0.08 | 1,0 | 2,0 | 0,045 | 0,015 | 16,5-18,5 | 2,0-2,5 | 10,5-13,5 | 5 x C ≤ 0.70 |
Characteristics of 1.4571
| Temperature Range | Density kg/dm3 | Hardness HB |
| Up to 550° C | 8.0 | 30 |
Specification of 316Ti Stainless Steel Sheet
|
specifications
|
ASTM A240 / ASME SA240, EN 10088-2 |
|---|---|
|
Stainless Steel 316ti Sheet Standard
|
ASME, ASTM, DIN, BS, EN |
|
Thickness
|
1 to 200mm |
|
Length
|
2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
|
Surface
|
2B, etching, BA,, NO.4, NO.8, Brush, NO.1, mirror, 8K, hair line, embossed, 2D, checkered, sand blast, etc |
|
Origin
|
China |
|
Technique
|
Cold Rolled and Hot Rolled |
|
Width
|
1000mm, 1219mm, 1500mm, 1800mm, 2000mm.etc |
|
Stainless Steel 316 Sheet Finish
|
Cold rolled sheet (CR), SATIN (Met with Plastic Coated), BA NO(8), Hot rolled plate (HR), 2B, 2D |
|
MTC
|
Available as per EN 10204 3.1, Mill Test Certificate |
|
Brand Name
|
TISCO BAOSTEEL POSCO LISCI JISCO |
|
Container
|
40ft HC: 12032m |
|
Form
|
Coils, Foils, Shim Sheets, Rolls, Plain Sheets, Ring (Flange), Strip, Perforated Sheets, Blank (Circle), Chequered Plate, Flats, etc. |
| Price term | CFR, Ex-Work, FOB, CNF, CIF |
|
Size
|
40ft GP: 12032mm x 2352mm x 2393mm |
| 20ft GP: 5898mm x 2352mm x 2393mm |
