316L Stainless Steel Channel Bar U Shape Stainless Steel Channels in 6m Length
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 321 309S 310S 2205 17-4PH 2507 |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Angle Bar / Channel Bar | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 309S 310S 321 2205 2507.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | Custom As Request |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | stainless steel round bar,stainless steel bar stock,steel round bar |
||
Product Description
316L Stainless Steel Channel Bar U Shape Stainless Steel Channels in 6m Length
| Specifications | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 316 Angle | 5mm to 9mm |
| SS 316 Channel | 40mm*20mm~300mm*300mm |
| SS 316 Beam | 3″ thru 12.31″ |
| SS 316 Chain | 1/8 inch – 1/2 inch Diameter |
| Thickness | 3.0mm – 120mm |
| Length | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
Types of Stainless Steel 316/316L Angle, Channel, Beam, Chain
 |
Stainless Steel 316/316L Angle | SS 316L Architectural Angles 316 SS Equal Leg Angle Stainless Steel 316L Unequal Leg Angle SS UNS S31603 Hot Rolled Steel Angle SS WERKSTOFF NR. 1.4404 Angle Bar ASTM A276 316L Stainless Steel Angle |
 |
Stainless Steel 316/316L Channel | SS 316L C Channel 316 SS C Channel 316L Stainless Steel U Channel SS UNS S31600 U Channel ASTM A276 316 Stainless Steel U Channel |
 |
Stainless Steel 316/316L H Beam | SS 316 H Beam 316L SS H Beam 316 Stainless Steel H Beam SS UNS S31603 H Beam ASTM A479 316L Stainless Steel H Beam |
 |
Stainless Steel 316/316L I Beam | SS 316L I Beam 316 SS I Beam 316L Stainless Steel I Beam SS UNS S31600 I Beam SS WERKSTOFF NR. 1.4401 I Beam ASTM A276 316 Stainless Steel I Beam |
 |
Stainless Steel 316/316L T Beam | SS 316 T Beam 316L SS T Beam 316 Stainless Steel T Beam SS UNS S31603 T Beam SS WERKSTOFF NR. 1.4404 T Beam ASTM A276 316L Stainless Steel T Beam |
 |
Stainless Steel 316/316L Chains | SS 316L Anchor Chain 316 SS Industrial Chain 316L Stainless Steel Lifting Chain SS UNS S31600 NACM Chain SS WERKSTOFF NR. 1.4401 Lifting Chain ASTM A476 316L Stainless Steel Twist Link Chain |
316/316L Stainless Steel Angle, Channel, Beam, Chain Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316 | 0.015 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 16.0-18.0 | 2.0-3.0 | 11.0-14.0 | 67.845 min |
| SS 316L | 0.035 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 16.0-18.0 | 2.0-3.0 | 10.0-14.0 | 68.89 min |
Stainless Steel 316/316L Angle, Channel, Beam, Chain Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Equivalent Grades for 316/316L Stainless Steel Angle, Channel, Beam
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | X5CrNiMo17-12-2 |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | X2CrNiMo17-12-2 |
SS 316/316L Angle, Channel, Beam, Chain Application Industries
- Off-Shore Oil Drilling Companies
- Power Generation
- Petrochemicals
- Gas Processing
- Specialty Chemicals
- Pharmaceuticals
- Pharmaceutical Equipment
- Chemical Equipment
- Sea Water Equipment
- Heat Exchangers
- Condensers
- Pulp and Paper Industry
