17-4PH Stainless Steel Bright Bar / Grade 17-4 Stainless Steel Shaft Diameter 4 - 100mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 316Ti 317L 321 309S 310S 2205 17-4PH XM-19 |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Round | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 316Ti 309S 310S 317L 321 329 2205 2507.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | Custom As Request |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | stainless steel round bar,stainless steel bar stock,steel round bar |
||
Product Description
17-4PH Stainless Steel Bright Bar / Grade 17-4 Stainless Steel Shaft Diameter 4 - 100mm
| Products | Stainless Steel Bar |
| Grade | 17-4PH |
| Diameter | 5 - 350mm |
| Length | 6m or custom cutting any length as request |
| Finishing | Bright Bar / Black Surface |
| Heat Treatment | Solid Solution , ageing |
| Surface Process | Polishing , Peeling |
| Other Grade |
201 303 304 304L 309S 310S 316L 316Ti 317L 321 347 410 420 430 431 2205 2507 904L 254SMO 416 431 440A/B/C.etc |
| MOQ | 500 Kgs |
| Loading Port | Shanghai Port |
| Processing | Cutting |
| Packing | Wooden box or wrapping by PP bag |
This grade of stainless steel has a typical density of 7.75kg/dm³ and can be magnetised. 17 4PH finds specific use in applications where a combination of unusually high strength and moderate corrosion resistance is a determining factor. The alloy has similar corrosion resistance characteristics when compared to 304 stainless steel.
Chemical Composition of 17-4PH Stainless Steel
| Carbon | 0.07% (Max) |
| Silicon | 1.00% (Max) |
| Manganese | 1.00% (Max) |
| Phosphorous | 0.040% (Max) |
| Sulfur | 0.030% (Max) |
| Chromium | 15%-17.5% |
| Molybdenum | 0.50% (Max) |
| Nickel | 3%-5% |
| Copper | 3%-5% |
Physical Properties of 17-4PH Stainless Steel
| Condition | Tensile | Yield | Enlongation | Reduction of Area | Hardness |
|---|---|---|---|---|---|
| H900 | 190KSI | 170KSI | 10% | 35% | 35 HRC |
| H1025 | 155KSI | 145KSI | 12% | 45% | 40 HRC |
| H1075 | 145 | 125 | 13 | 45 | 33-39 HRC |
| H1150 | 135 | 105 | 16 | 50 | 28-37 HRC |
| H1150D | 125 | 105 | 16 | 50 | 25-33 HRC |
17-4 Stainless Steel Processing
Achieve superior hardness from welding after heat treatment. Machining conditions differ with the firmness of the element. Different levels of strength and hardness can be achieved depending on the temperature it is heat treated at. The ASTM designation is A564 and common conditions are H900, H1025, H1075, H1150, and H1150D.
TYPICAL APPLICATIONS
17-4 stainless steel is known for its high strength, corrosion resistance, and toughness. Because of these traits, it is often used in the aerospace, medical, and food processing industries, as well as in construction, oil and gas, and transportation.
Additionally, 17-4 PH stainless steel is often used in the manufacturing of gears, valves, pumps, and fasteners, as well as in the production of molds and dies. The alloy's high strength and corrosion resistance properties make it an ideal material for use in harsh and demanding environments.
About Our company
We are a world-class supplier ofstainless steel raw materials. Our objective is to provide all our customers, from the small machine shop to the large multi-national corporation, a supply path that continuously delivers the highest levels of service, quality and value.
