316L Stainless Steel Angle Bar / Channel Bar / Round Bar for Chemical Application SA276 SS Bar
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 321 309S 310S 2205 17-4PH 2507 |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Angle Bar / Channel Bar | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 309S 310S 321 2205 2507.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | Custom As Request |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | stainless angle bar,ss angle bar,angle bar stainless |
||
Product Description
316L Stainless Steel Angle Bar / Channel Bar / Round Bar for Chemical Application SA276 SS Bar
| Products | Stainless Steel Angle Bar / Stainless Steel Channel Bar |
| Grade | 201 304 304L 310S 316L 2205.etc |
| Finishing | Hot rolled |
| Diameter | 30*30*3- 120*120*12 |
| Length | 6m or custom cutting as request |
| Service | Cutting |
| MOQ | 500 Kgs |
| Deliver time | 10 - 15 Days based on the quantity |
| Packing | wooden box, or packing as request |
| Loading Port | Shanghai Port. Ningbo Port |
| Other Shape | Round, Square, Flatness, Hexagonal , Angle, Channel |
| Company Type | Factory |
Stainless Steel 316L Angle Bar, ASTM A276 Stainless Steel 316 Channel, SS UNS S31635 Beam, Austenitic Stainless Steel 316L Chains Suppliers, SS 316 Angle Dealer in Mumbai, Steel 316 Channel Bar
Stainless Steel Equal Leg Angle, Suppliers of ASTM A484 Stainless Steel 316 U Channel, 316L SS Anchor Chain Exporter, SS 316 Angle Price, Stainless Steel 316 H Beam, SS WERKSTOFF NR.1.4571 I Beam Manufacturer
316 Stainless Steel Angles are manufactured using high-grade steel, which contains chromium, nickel, and additional molybdenum, niobium, titanium, and nitrogen. These additional elements offer excellent tensile strength, high surface finish, outstanding corrosion & oxidation resistance, and good mechanical properties. We offered these SS Angles in various types like Stainless Steel 316L Unequal Angles, Stainless Steel Equal Angles, etc.
we have a large stock of 316 Stainless Steel Channels in different types such as Stainless Steel C Channels, 316L Stainless Steel U Channels and more. Also, we are a specialist in manufacturing 316L Stainless Steel Flats in types like Stainless Steel 316L Brush Polished Flat, etc.
316 Stainless Steel Angles, SS 316 Channels Bar and 316 Flat Bar are widely used in paper & pulp, construction, piping, water treatment applications, raceways, braces and frames for machinery and housing in corrosive environments, etc.
Hot Rolled Steel 316L Equal Leg Angle, Steel 316 Angle Bar Price, SS 316 T Beam, 316 SS Lifting Chain, Specialist Distributor of ASTM A276 SS 316 Twist Link Chain, Stainless Steel 316 Flat Bar Price List, Stainless Steel GOST 03Ch17N14M3 C Channel, 316L Stainless Steel Beams
| Specifications | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 316 Angle | 5mm to 9mm |
| SS 316 Channel | 40mm*20mm~300mm*300mm |
| SS 316 Beam | 3″ thru 12.31″ |
| SS 316 Chain | 1/8 inch – 1/2 inch Diameter |
| Thickness | 3.0mm – 120mm |
| Length | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | Angle Bar, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
SS 316 Flat Bar, Stainless Steel 316 Channel Bar & SS 316 Angle Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316 | 0.015 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 16.0-18.0 | 2.0-3.0 | 11.0-14.0 | 67.845 min |
| SS 316L | 0.035 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 16.0-18.0 | 2.0-3.0 | 10.0-14.0 | 68.89 min |
Mechanical Properties of 316 SS Angle Bar, SS 316 Channel, Steel 316 Flat Bar
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000, MPa – 515 | Psi – 30000, MPa – 205 | 35 % |
Equivalent Grades of Stainless Steel 316 Angle, SS 316 Channel Bar, SS 316 Flat Bar
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Types of Stainless Steel 316 Angle, Stainless 316 Flat Bar & Channel Bar
• SS 316 Architectural Angles
• SS 316L C Channel
• 316 SS Equal Leg Angle
• 316 Stainless Steel U Channel
• 316L Stainless Steel Flats
• SS UNS S31603 H Beam
• SS 316 H Beam
• SS 316L I Beam
• SS 316 L T Beam
• SS 316 Anchor Chain
• 316L SS Industrial Chain
• 316 Stainless Steel Lifting Chain
• SS UNS S31603 NACM Chain
• SS UNS S30403 NACM Chain
• SS WERKSTOFF NR. 1.4404 T Beam
• SS WERKSTOFF NR. 1.4307 I Beam
•SS UNS S31603 H Beam
• SS UNS S31603 U Channel
