ASTM A276 304 316L Stainless Steel Angle Bar Equal Angle / Stainless Steel U Channel Bars
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 321 309S 310S 2205 17-4PH 2507 |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Angle Bar / Channel Bar | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 309S 310S 321 2205 2507.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | Custom As Request |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | stainless angle bar,ss angle bar,angle bar stainless |
||
Product Description
ASTM A276 304 316L Stainless Steel Angle Bar Equal Angle / Stainless Steel U Channel Bars
| Products | Stainless Steel Angle Bar / Stainless Steel Channel Bar |
| Grade | 201 304 304L 310S 316L 2205.etc |
| Finishing | Hot rolled |
| Diameter | 30*30*3- 120*120*12 |
| Length | 6m or custom cutting as request |
| Service | Cutting |
| MOQ | 500 Kgs |
| Deliver time | 10 - 15 Days based on the quantity |
| Packing | wooden box, or packing as request |
| Loading Port | Shanghai Port. Ningbo Port |
| Other Shape | Round, Square, Flatness, Hexagonal , Angle, Channel |
| Company Type | Factory |
Stainless Steeel Equal Leg Angle, Suppliers of ASTM A484 Stainless Steel 304L U Channel, 304L SS Anchor Chain Exporter, Stainless Steel 304 Angle Price, Stainless Steel 304L H Beam, SS WERKSTOFF NR. 1.4306 I Beam Manufacturer, SS 304L Channel Bar
Stainless Steel Angles are manufactured using high-grade steel, which contains chromium, nickel, and additional molybdenum, niobium, titanium, and nitrogen. These additional elements offer excellent tensile strength, high surface finish, outstanding corrosion & oxidation resistance, and good mechanical properties. We offered these SS Angles in various types like Stainless Steel Unequal Angles, Stainless Steel Equal Angles, etc.
imilarly, we have a large stock of 304 Stainless Steel Channels in different types such as Stainless Steel C Channels, 304L Stainless Steel U Channels and more. Also, we are a specialist in manufacturing 304L Stainless Steel Flats in types like Stainless Steel 304L Brush Polished Flat, etc. All these Stainless Steel products are available in various material grades including 304, 304L, 310, 310S, 321, 321H, 347, 347H, and 904L.
304 Stainless Steel Angles, Channels and Flats are widely used in paper & pulp, construction, piping, water treatment applications, raceways, braces and frames for machinery and housing in corrosive environments, etc. If you want to buy these Stainless Steel Products at most affordable prices
304 Stainless Steel Angle, SS 304 Channel & Flat Bar Specification :
| Specifications | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 304L Channel | 40mm*20mm~300mm*300mm |
| SS 304L Angle | 5mm to 9mm |
| SS 304L Beam | 3″ thru 12.31″ |
| SS 304L Chain | 1/8 inch – 1/2 inch Diameter |
| Thickness | 3.0mm – 120mm |
| Length | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
SS 304 Angle, Channel Bar, Steel 304 Flat Bar Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304/304L | 0.035 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 13 | – |
Mechanical Properties of SS 304 Channel Bar, 304 Angle, SS 304 Flat Bar
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000, MPa – 515 | Psi – 30000, MPa – 205 | 35 % |
Equivalent Grades of Stainless Steel 304 Flat Bar, 304 Angle & SS 304 Channel Bar
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS304/304L | 1.4306/1.4307 | S30403 | SUS 304L | 3304S11 | 03Х18Н11 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 |
