Alloy 926 Nickel Alloy Stainless Steel Plate & Sheet UNS N08926 ASTM A240 Thk 3.0-20.0mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 202 218 304 316L 309S 310S 317L 321 347 904L 2205 2507 925 926.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | wooden pallets + waterproof paper |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 5Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Sheet & Plate | Grade | 201 202 218 304 310S 310H 316L 317L 430.etc |
|---|---|---|---|
| Standard Size | 1000*2000mm 1219*2438mm 1500*6000mm | Thickness | 0.6 - 60.0mm |
| Brand | TISCO BAOSTEEL POSCO LISCO | Loading Port | Shanghai Port |
| MOQ | 500 Kgs | Packing | Wooden Pallets + Waterproof Paper |
| Highlight | Alloy 926 Stainless Steel Plate,UNS N08926 Stainless Steel Plate |
||
Product Description
Alloy 926 Nickel Alloy Stainless Steel Plate & Sheet UNS N08926 ASTM A240 Thk 3.0-20.0mm
| Products | Stainless Steel Plate |
| Thickness | 0.6 - 60.0mm |
| Width | 1000mm 1219mm 1500mm 1800mm 2000mm or other width as request |
| Length | 2000mm 2438mm 3000mm 6000mm or other length as request |
| Grade | 201 202 301 304 304L 304H 309S 310S 310H 316L 316Ti 317L 321 347 409L 410 420 430 431 436L 439 441 443 444 2205 2507 904L 600 625 800 825 718 253MA 254SMO Nitronic 60 925 926.etc |
| Service | Laser Cutting, Surface processing, bending |
| Brand | TISCO BAOSTEEL POSCO LISCO JISCO |
| Standard | ASTM JIS GB DIN EN BS |
| Certificate | ISO MTC C/O F/E |
| Packing | Wooden pallets and waterproof paper |
| Deliver time | 5 - 15 days |
| Loading port | Shanghai Port |
Alloy 926 is a super-austenitic molybdenum stainless steel that exhibits excellent resistance to a variety of highly corrosive environments. The combination of molybdenum and nitrogen in its composition resists pitting and crevice corrosion, while copper improves sulfuric acid resistance, and nitrogen improves yield and tensile strengths.
Alloy 926 Sheet and Plate Manufacturer - Equivalent Grades:
| STANDARD | WERKSTOFF NR. | UNS |
| 926 | 1.4529 | N08926 |
Chemical Composition of UNS N08926/1.4529
| Standards | Steel Grades | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Chemical Composition % | ||||||||||
| C: | Mn: | Si: | P: | S: | Cr: | Ni: | Mo: | Cu: | N: | |
| EN | X1NiCrMoCuN25-20-7 - X1CrNiMoCuN25-20-7 - 1.4529 | |||||||||
| <0.02 | <1.0 | <0.5 | <0.03 | <0.01 | 19.0 - 21.0 | 24.0 - 26.0 | 6.0 - 7.0 | 0.5 - 1.5 | 0.10 - 0.25 | |
| ASTM | UNS N08926 - 26-3 Mo - 6 Mo - Alloy 926 | |||||||||
| <0.02 | <2.0 | <0.5 | <0.03 | <0.01 | 19.0 - 21.0 | 24.0 - 26.0 | 6.0 - 7.0 | 0.5 - 1.5 | 0.15 - 0.25 | |
Mechanical Properties of Alloy 926
The mechanical properties of alloy 926 are outlined in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | ≥648 MPa | ≥94000 psi |
| Yield strength | ≥296 MPa | ≥43000 psi |
| Modulus of elasticity | 192 GPa | 27800 ksi |
| Elongation at break | ≥35 % | ≥35 % |
| Rockwell B hardness | ≤86 | ≤86 |
Main Features of Incoloy 926 (N08926)
Main features of Incoloy 926 (N08926) nickel base alloy are listed as below.
- 1) Incoloy 926 (N08926) features high resistance to pitting and crevice corrosion in halide media and acidic media containing H2S.
- 2) It can effectively resist chloride ion stress corrosion cracking (SCC) in practical applications.
- 3) It is resistant to various corrosions in the usual oxidation and reduction environments.
- 4) It has enhanced mechanical performance in contrast to Cronifer 1925 LC-Alloy 904L.
- 5) It features improved metallurgical stability compared with Ni18 alloys.
- 6) It is certified to the application of pressure vessel manufacturing (VdTUV-196 ~ 400 °C and ASME certification).
Incoloy 926 Applications
- 1) Reverse osmosis seawater desalination device, seawater heat exchanger, capacitor tube, etc.;
- 2) Pulp and paper industry, various bleaching devices, etc.;
- 3) Resin production device, reaction containers for drugs, piping, etc.;
- 4) Firefighting systems, seawater purification systems, hydraulic and perfusion piping;
- 5) Systems in marine engineering;
- 6) Hose system in marine engineering;
- 7) Pipes, joints, airflow systems, etc. in the production of acid gases;
- 8) Parts in flue gas desulfurization systems;
- 9) Evaporators, heat exchangers, filters, mixers, etc. in the production of phosphoric acid;
- 10) Sulfuric acid separation and condensation system;
- 11) Cooling-water pipe systems in Power plant;
- 12) Storage tank for corrosive chemical transportation;
- 13) Halogen acid catalyzed organic production equipment;
- 14) Others.
