440C Stainless Bar ASTM A276 SS Bar OD5 - 350mm UNS S44004 Stainless Steel Rod
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 316Ti 317L 321 309S 310S 2205 17-4PH XM-19 |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Round | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 316Ti 309S 310S 317L 321 329 2205 2507.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | Custom As Request |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | stainless steel round bar,stainless steel bar stock,steel round bar |
||
Product Description
440C Stainless Bar ASTM A276 SS Bar OD5 - 350mm UNS S44004 Stainless Steel Rod
| Products | Stainless Steel Bar |
| Grade | 440C |
| Diameter | 5 - 350mm |
| Length | 6m or custom cutting any length as request |
| Finishing | Bright Bar / Black Surface |
| Heat Treatment | Solid Solution , ageing |
| Surface Process | Polishing , Peeling |
| Other Grade |
201 303 304 304L 309S 310S 316L 316Ti 317L 321 347 410 420 430 431 2205 2507 904L 254SMO 416 431 440A/B/C.etc |
| MOQ | 500 Kgs |
| Loading Port | Shanghai Port |
| Processing | Cutting |
| Packing | Wooden box or wrapping by PP bag |
Stainless Steel 440C ( 1.4125 ) is capable of attaining, after heat treatment, the highest strength, hardness and wear resistance of all the stainless alloys. Its very high carbon content is responsible for these characteristics, which make SS440C particularly suited to such applications as ball bearings and valve parts.
- Hardenable high-carbon chromium steels designed to provide stainless properties with maximum hardness
- Have maximum hardness together with high strength and corrosion resistance in the hardened and stress relieved condition
- Always used in the hardened or hardened and stress relieved conditions
- None of the alloys has its full corrosion resistance either in the annealed or in the hardened and tempered condition
- Wide applications where good corrosion resistance along with high hardness or abrasion resistance is required
Standard of 440C Stainless Steel and Equivalent Steel Grades
| Country | USA | BS & DIN | Japan |
| Standard | ASTM A276 | EN 10088 | JIS G4303 |
| Grades | S44004/440C | X105CrMo17/1.4125 | SUS440C |
ASTM 440C Stainless Steel Mechanical Properties
| Tempering Temperature (°C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (% in 50mm) | Hardness Rockwell (HRC) | Impact Charpy V (J) |
| Annealed* | 758 | 448 | 14 | 269HB max# | – |
| 204 | 2030 | 1900 | 4 | 59 | 9 |
| 260 | 1960 | 1830 | 4 | 57 | 9 |
| 316 | 1860 | 1740 | 4 | 56 | 9 |
| 371 | 1790 | 1660 | 4 | 56 | 9 |
Applications of stainless Steel 440C
- Used in numerous applications in areas where a very hard and abrasion resistant stainless is called for
- Applications include pivot pins, dental and surgical instruments, cutlery valve parts, ball bearings, nozzles, hardened steel balls and seats for oil well pumps, plus valve parts
Will 440C rust?
These stainless steels have good corrosion resistance in the hardened and stress relieved conditions. Hence, they should, usually, be used only in that condition. These steels are resistant to such conditions as fresh water, steam, crude oil, gasoline, perspiration, and alcohol.
| 440c stainless steel Composition | |||
| Property | SS 440A | SS 440B | SS 440C |
| Carbon | .60 – .75 | .75 – .95 | .95 – 1.2 |
| Manganese | 1.00 max | 1.00 max | 1.25 max |
| Silicon | 1.00 max | 1.00 max | 1.00 max |
| Phosphorus | .04 max | .04 max | .04 max |
| Sulfur | .03 max | .03 max | .04 max |
| Chromium | 16.0 – 18.0 | 16.0 – 18.0 | 16.5 – 18.0 |
| Molybdenum | .75 max | .75 max | .75 max |
| Nickel | .50 max | NA | NA |
| Mechanical Properties | ||||||
| SS440A | SS440B | SS440C | ||||
| Property | Annealed | Hardened & Stress Relieved | Annealed | Hardened & Stress Relieved | Annealed | Hardened & Stress Relieved |
| Ultimate tensile strength, psi | 105,000 | 260,000 | 107,000 | 280,000 | 110,000 | 285,000 |
| 0.2% Yield strength, psi | 60,000 | 240,000 | 62,000 | 270,000 | 65,000 | 275,000 |
| Elongation, % in 2? | 20 | 5 | 18 | 3 | 14 | 2 |
| Reduction of area, % | 45 | 20 | 35 | 15 | 25 | 10 |
| Rockwell hardness | B95 | C51 | B96 | C55 | B97 | C57 |
| Impact strength Izod V-Notch, ft-lbs | NA | 3-6 | NA | 2-5 | NA | 1-5 |
IS 440C stainless steel good for knives?
440C is a high carbon martensitic stainless steel that belongs to the 440 steel series. … This steel is loved by both knife makers and knife users due to its really high corrosion resistance. It also takes and holds a great mirror-like finish longer and requires very minimal care.
What hardness is 440C stainless steel?
440C (UNS designation S44004) is a martensitic 400 series stainless steel, and is the highest carbon content from 400 stainless steel series. It is usually heat treated to reach hardness of 56–58 HRC. It is a bearing steel, and used in rolling contact stainless bearings, e.g. ball bearings and roller bearings.
IS 440C stainless steel magnetic?
Type 440C Stainless Steel is widely used in antifriction bearings, in valves and in many other applications where high hardness and reasonable corrosion resistance is required. This material is much more resistant to abrasion and wear than others stainless steel. sus440c is strongly attracted by a magnetic field.
