Hot Rolled AOD 440B Stainless Steel Round Bar High Hardness Stainless Steel Bars in 6m Length
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 316Ti 317L 321 309S 310S 2205 17-4PH XM-19 |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Round | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 316Ti 309S 310S 317L 321 329 2205 2507.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | Custom As Request |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | stainless steel round bar,stainless steel bar stock,steel round bar |
||
Product Description
Hot Rolled AOD 440B Stainless Steel Round Bar High Hardness Stainless Steel Bars in 6m Length
| Products | Stainless Steel Bar |
| Grade | 440B |
| Diameter | 5 - 350mm |
| Length | 6m or custom cutting any length as request |
| Finishing | Bright Bar / Black Surface |
| Heat Treatment | Solid Solution , ageing |
| Surface Process | Polishing , Peeling |
| Other Grade |
201 303 304 304L 309S 310S 316L 316Ti 317L 321 347 410 420 430 431 2205 2507 904L 254SMO 416 431 440A/B/C.etc |
| MOQ | 500 Kgs |
| Loading Port | Shanghai Port |
| Processing | Cutting |
| Packing | Wooden box or wrapping by PP bag |
About 440B Stainless Steel
It is a high carbon, martensitic stainless steel product with good overall strength and moderate corrosion resistance in the hardened and tempered condition. The alloy must be free of scale and foreign particles if optimum corrosion resistance is to be achieved. 440B annealed product also offers similar machining characteristics when compared with high speed annealed steel grades. With such excellent hardness, the alloy also promotes good wear resistance. A hardness value of 60 HRC is achievable after heat treatment.
Technical Data Sheet
| Chemical Composition Limits | ||||||
| Weight % | C | S | Cr | Mo | Vanadium | Fe |
| CHRONIFER M-17B | 0.85-0.95 | 0.03 max | 17-19 | 0.90-1.30 | 0.07-0.12 | Rem |
| Other Chemically similar Specifications | ||||||
| Weight % | C | S | Cr | Mo | Vanadium | Fe |
| WS 1.4112 | 0.85-0.95 | 0.03 max | 17-19 | 0.90-1.30 | 0.07-0.12 | Rem |
| X 90 CrMoV 18 | 0.85-0.95 | 0.03 max | 17-19 | 0.90-1.30 | 0.07-0.12 | Rem |
| AISI 440B~ | 0.85-0.95 | 0.03 max | 17-19 | 0.90-1.30 | 0.07-0.12 | Rem |
Alloy 440B Stainless Steel is a high carbon chromium steel which is manufactured in rod, bar and coil. (AISI 440B ~ Stainless Steel).
Material Properties
This steel is designed to provide stainless properties with excellent hardness. In some respects it behaves similarly to tool steel. Chronifer M 17B resists corrosion from mild atmospheres, fresh water steam, ammonia, many petroleum products and organic materials and several mild acid environments.
Availability
- Bars Ø5-50mm: Cold drawn and polished
- Bars Ø 10.00-350mm: Cold drawn, ground and polished
- Bars Length : 2m- 6m. Surface roughness N5-N6
Standard Tolerances
- Diameter: 5-350mm
- Out of roundness/cylindricity :1/2 of dia tolerance
- Tolerance in length : +50/-0mm
Corrosion Resistance
This grade is used in the hardened and tempered condition for a good corrosion resistance. For optimum, corrosion resistance, surfaces must be free of scale and foreign particles.
Heat Treatment
- Soft annealing: 750-800ºC
- Slow furnace cooling (2-4 hours)
- Hardening: 1000-1080ºC
- Max obtainable hardness 57-59 HRC
Cutting Rate
20-35m/min (approx value, depending on the lubrication oil, the cutting tools, the shape of parts)
Stock Range
Standard dimensions from Ø 0.80 to 24.00mm with many intermediate dimensions.
TYPICAL APPLICATIONS
Commercial applications for this engineering material include:
- Valve seats
- Cutting tools and knife blades
- Bearings
- Surgical instruments
